Allen-Bradley 2711P-RDT7C PanelView Plus 7 Standard 7″ Touch Screen | Replacement, Equivalent & Selection Guide
The Allen-Bradley 2711P-RDT7C is a 7-inch color touch screen terminal from the PanelView Plus 7 Standard series by Rockwell Automation. Designed for demanding industrial HMI applications, it delivers reliable operator interface performance with seamless integration into Allen-Bradley PLC and ControlLogix/CompactLogix control systems. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make the right choice.
Technical Specifications
- Part Number: 2711P-RDT7C
- Series: PanelView Plus 7 Standard
- Manufacturer: Allen-Bradley / Rockwell Automation
- Display Size: 7 inches (diagonal)
- Display Type: Color TFT LCD, Touch Screen
- Resolution: 800 × 480 pixels (WVGA)
- Touch Technology: Resistive analog touch
- Operating System: Windows Embedded Standard 7 (WES7)
- Communication: Ethernet (10/100 Mbps), USB Host × 2, USB Device × 1
- Input Voltage: 24V DC
- Power Consumption: Approx. 18 W
- Operating Temperature: 0 °C to 55 °C
- Storage Temperature: −20 °C to 70 °C
- Humidity: 5% to 95% RH (non-condensing)
- Protection Rating: NEMA 4/4X, 12, 13; IP65 (front panel)
- Weight: Approx. 1.14 kg
- Certifications: UL, CE, cUL
- Programming Software: FactoryTalk View Studio ME
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the 2711P-RDT7C. Always verify firmware, communication protocol, and mounting cutout compatibility before substitution.
- 2711P-RDT7C (Original) — PanelView Plus 7 Standard, 7″, resistive touch, 24V DC
- 2711P-RDT7CS — Same series, stainless steel bezel variant for hygienic environments
- 2711P-T7C21D8S — PanelView Plus 7 Standard 7″, newer catalog suffix, direct functional equivalent
- 2711P-T7C4D8 — PanelView Plus 7 Standard 7″, DC power, comparable display and I/O
- 2711-T10C8 (PanelView 1000) — Legacy predecessor; requires application migration
- 6AV2124-0GC01-0AX0 (Siemens KTP700 Basic) — Cross-brand alternative; requires full application rewrite
Note: Cross-brand replacements require complete HMI application redevelopment. Consult your system integrator before substituting.
Why Choose the Original 2711P-RDT7C
- Native Rockwell Integration: Plug-and-play with ControlLogix, CompactLogix, and MicroLogix PLCs via EtherNet/IP — no gateway required.
- FactoryTalk Ecosystem: Full compatibility with FactoryTalk View Studio ME, FactoryTalk Alarms & Events, and FactoryTalk Diagnostics.
- Proven Reliability: IP65-rated front panel withstands washdowns, dust, and industrial contaminants.
- Long-Term Support: Rockwell Automation provides extended lifecycle support and spare parts availability.
- Regulatory Compliance: UL, CE, and cUL listed for global deployment.
Typical Applications
- Automotive assembly line operator panels
- Food & beverage processing control stations
- Pharmaceutical batch monitoring terminals
- Water/wastewater SCADA local HMI nodes
- Material handling and conveyor control interfaces
- Oil & gas field operator workstations
- Machine tool and CNC operator panels
System Compatibility
- PLC Platforms: ControlLogix (1756), CompactLogix (1769), MicroLogix 1100/1400, SLC 500 (via DH+ gateway)
- Network Protocols: EtherNet/IP (primary), DH-485 (via adapter), DF1 (via serial adapter)
- Software: FactoryTalk View Studio ME v8.0 and above; RSLinx Classic / RSLinx Enterprise
- Power Supply: 24V DC (requires external 24V DC power supply, e.g., 1606-XLP series)
- Panel Cutout: 192 mm × 138 mm (standard 2711P 7″ cutout)
Selection Guide
Use the following criteria to confirm the 2711P-RDT7C is the right model for your application:
- Screen Size: 7″ — suitable for compact panels with limited door space
- Touch Type: Resistive — ideal for gloved-hand operation or stylus use
- Power: 24V DC — confirm your panel has a 24V DC rail available
- Communication: Ethernet only — if serial (RS-232/RS-485) is required, consider 2711P-RDT7C with a serial communication module (2711P-RN15S)
- Environment: IP65 front — suitable for washdown; for full IP69K, consider stainless variant 2711P-RDT7CS
- Display Color: Full color — if monochrome is acceptable, legacy 2711 series may reduce cost
- Upgrade Path: Migrating from PanelView Plus 6 (2711P-RDT7C4)? The 2711P-RDT7C is the direct successor with the same cutout dimensions.
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels with full traceability.
- Each unit undergoes visual inspection, power-on test, and communication verification before shipment.
- Original factory packaging preserved where available; anti-static packaging used for all shipments.
- Certificate of conformance (CoC) available upon request.
- Warranty: 12 months from date of shipment against manufacturing defects.
How to Order
- Step 1: Confirm your part number: 2711P-RDT7C (check nameplate on existing unit or engineering BOM).
- Step 2: Specify quantity and required delivery timeline.
- Step 3: Contact us via email or phone for a formal quotation — typically within 2 business hours.
- Step 4: Submit PO or pay via secure online checkout.
- Step 5: Receive tracking information within 1 business day of payment confirmation.
For urgent requirements or large-volume orders, please contact us directly for priority processing.
Replacement & Compatibility FAQ
Q: Is the 2711P-RDT7C compatible with PanelView Plus 6 applications?
A: Yes, with minor migration steps using FactoryTalk View Studio ME. The application file (.MER) can be converted and re-downloaded to the 2711P-RDT7C.
Q: Can I replace a 2711P-RDT7C with a 2711P-T7C21D8S?
A: Yes — the 2711P-T7C21D8S is the current catalog equivalent. Same mounting cutout, same 24V DC power, same Ethernet communication. Application transfer is straightforward.
Q: Does the 2711P-RDT7C support Wi-Fi?
A: No. The standard unit uses wired Ethernet only. For wireless, a separate Wi-Fi adapter or infrastructure-level wireless bridge is required.
Q: What is the difference between 2711P-RDT7C and 2711P-RDT7CS?
A: The “S” suffix denotes a stainless steel bezel, designed for hygienic or corrosive environments. Functionally identical.
Q: Can Konmask provide a tested used unit if new stock is unavailable?
A: Yes. We offer factory-tested refurbished units with a 90-day warranty. Please inquire at the time of order.
