Allen-Bradley 2711P-RN10C – DeviceNet Communication Module | PanelView Plus Platform
Engineering Background
The Allen-Bradley 2711P-RN10C is a plug-in DeviceNet (DNet) communication module designed exclusively for the PanelView Plus family of operator interface terminals. It extends the native communication capability of PanelView Plus HMIs by enabling direct participation on a DeviceNet network — a widely deployed, open-standard fieldbus used throughout discrete manufacturing, material handling, and process automation environments. This module allows the PanelView Plus terminal to function as a DeviceNet scanner or adapter node, facilitating real-time I/O exchange and explicit messaging with PLCs, drives, sensors, and other DeviceNet-compatible devices.
Product Positioning
Targeted at automation engineers and system integrators who require deterministic, low-latency HMI-to-field communication without routing through a primary PLC backplane, the 2711P-RN10C is the factory-authorized solution for DeviceNet connectivity on PanelView Plus 6, PanelView Plus 6 Compact, and legacy PanelView Plus terminals. It is the preferred choice for brownfield upgrades where existing DeviceNet infrastructure must be preserved while modernizing the operator interface layer.
Complete Technical Specifications
- Part Number: 2711P-RN10C
- Manufacturer: Allen-Bradley / Rockwell Automation
- Module Type: DeviceNet (DNet) Communication Module
- Compatible Platform: PanelView Plus, PanelView Plus 6, PanelView Plus 6 Compact
- Network Protocol: DeviceNet (CAN-based, ISO 11898)
- Data Rate: 125 kbps / 250 kbps / 500 kbps (auto-detect or configurable)
- Node Address: 0–63 (software configurable via FactoryTalk View ME)
- Connector Type: 5-pin open-style DeviceNet connector (V+, CAN_H, Shield, CAN_L, V−)
- Form Factor: Plug-in module (rear-mount slot on PanelView Plus terminal)
- Power Supply: Powered via PanelView Plus terminal backplane (no external power required)
- Operating Temperature: 0 °C to +55 °C (32 °F to 131 °F)
- Storage Temperature: −40 °C to +85 °C
- Relative Humidity: 5% to 95% non-condensing
- Vibration: IEC 60068-2-6 compliant
- Shock: IEC 60068-2-27 compliant
- Certifications: UL Listed, CE Marked, cUL, ODVA Conformance Tested
- Weight: Approx. 120 g
- Firmware: Updated via FactoryTalk View ME Studio
- Catalog Series: C (current production revision)
Proven Application Environments
- Discrete Manufacturing: Assembly lines using DeviceNet I/O blocks (e.g., 1734 POINT I/O, 1756-DNB scanner networks) where the HMI must directly monitor field device status.
- Material Handling & Conveyor Systems: Distributed motor starter and sensor networks requiring operator visibility at the HMI level without PLC intermediary.
- Packaging Machinery: OEM machine builders integrating PanelView Plus terminals into DeviceNet-based machine architectures for compact panel designs.
- Automotive Body Shops: Weld cell and transfer line HMI stations where DeviceNet remains the dominant fieldbus for tooling I/O.
- Brownfield Upgrades: Replacing legacy PanelView 550/900/1000/1400e terminals while retaining existing DeviceNet wiring infrastructure.
- Water & Wastewater: Remote pump station HMIs communicating with DeviceNet-enabled drives and soft starters.
Engineering Advantages
- Native Integration: Factory-designed for PanelView Plus — no third-party gateway, no protocol converter, no additional licensing required.
- Deterministic Communication: DeviceNet’s CSMA/NBA arbitration ensures predictable scan times critical for real-time HMI display accuracy.
- Simplified Wiring: Single 5-wire DeviceNet trunk connection replaces multiple discrete I/O wiring runs to the HMI panel.
- FactoryTalk View ME Integration: Node address and baud rate configured directly within the FactoryTalk View ME project — no separate configuration tool required.
- Hot-Swap Capable: Module can be replaced without full terminal disassembly on supported PanelView Plus models.
- ODVA Conformance: Interoperability with any ODVA-certified DeviceNet device from any manufacturer.
- Compact Form Factor: Rear-mount plug-in design preserves panel depth and front-face aesthetics of the PanelView Plus terminal.
System Architecture & Signal Flow
The 2711P-RN10C installs into the dedicated communication module slot on the rear of the PanelView Plus terminal. Once installed, the module appears as a DeviceNet node on the network trunk. The PanelView Plus terminal’s FactoryTalk View ME runtime communicates with the module via the internal backplane bus, translating tag read/write requests from the HMI application into DeviceNet explicit messages or polled I/O connections.
Typical signal flow: HMI Tag Database → FactoryTalk View ME Runtime → 2711P-RN10C Module → DeviceNet Trunk Cable → Target Device (PLC, Drive, I/O Block)
The module supports both polled (cyclic I/O) and explicit messaging (acyclic parameter read/write) connection types, enabling both real-time process visualization and on-demand device configuration from the HMI.
Sourcing & Quality Verification
- Origin: Genuine Allen-Bradley / Rockwell Automation production unit.
- Condition: New surplus or factory-refurbished units available — condition specified at time of quotation.
- Inspection: Each unit undergoes visual inspection, label verification (catalog number, series, revision), and functional power-on check prior to shipment.
- Packaging: Ships in anti-static ESD bag with original or equivalent protective packaging. Fragile components bubble-wrapped and boxed.
- Traceability: Batch and serial number documentation available upon request for quality-critical procurement.
- Warranty: 12-month Konmask operational warranty covering manufacturing defects and functional failure under normal operating conditions.
Procurement Process
- Submit RFQ: Contact support@konmask.com or call +0086 19859288691 with your required quantity, delivery timeline, and any condition preferences (new / refurbished / surplus).
- Quotation: Receive a formal quotation within 1 business day including unit price, lead time, and shipping options (DHL / FedEx / sea freight for bulk orders).
- Order Confirmation: Purchase order or proforma invoice accepted. T/T bank transfer, PayPal, and trade assurance payment methods supported.
- Quality Check & Dispatch: Pre-shipment inspection completed; tracking number and packing list issued within 24–48 hours of payment clearance.
- After-Sales Support: Technical commissioning support available via email or video call. Warranty claims processed within 5 business days.
Technical FAQ
Q: Is the 2711P-RN10C compatible with PanelView Plus 7?
A: No. PanelView Plus 7 uses a different communication module slot architecture. The 2711P-RN10C is designed for PanelView Plus (catalog 2711P-Txxxx) and PanelView Plus 6 (catalog 2711P-Txxxxxx) terminals only.
Q: Can this module be used as a DeviceNet master (scanner)?
A: The 2711P-RN10C operates as a DeviceNet adapter (slave) node by default when used with FactoryTalk View ME. For scanner (master) functionality, a dedicated 1756-DNB or 1769-SDN scanner module in the PLC rack is required.
Q: What software is required to configure this module?
A: FactoryTalk View ME Studio (v5.0 or later recommended). No separate RSNetWorx for DeviceNet license is required for basic node address and baud rate configuration.
Q: Can I replace this module in the field without powering down the terminal?
A: Hot-swap capability depends on the specific PanelView Plus model. Consult Rockwell Automation publication 2711P-IN009 for model-specific installation guidance. Konmask recommends powering down the terminal before module replacement as a best practice.
Q: What is the maximum cable length for the DeviceNet network?
A: Maximum trunk length depends on baud rate: 500 m at 125 kbps, 250 m at 250 kbps, 100 m at 500 kbps (per ODVA DeviceNet specification). Drop cable maximum is 6 m per drop.
Q: Do you provide EDS files for this module?
A: Yes. The Electronic Data Sheet (EDS) file for the 2711P-RN10C is available from the Rockwell Automation Product Compatibility and Download Center (PCDC). Konmask can assist in locating the correct EDS file upon request.
