Allen-Bradley 2711P-T12W22D9P-B SER B – 12″ Widescreen Touch Screen HMI Terminal | PanelView Plus 7 Standard Platform
Engineering Background: The PanelView Plus 7 Standard series represents Rockwell Automation’s flagship operator interface platform, engineered for demanding industrial environments where reliable human-machine interaction is mission-critical. The 2711P-T12W22D9P-B SER B is the 12-inch widescreen variant, delivering high-resolution visualization and seamless integration with Allen-Bradley control architectures including ControlLogix, CompactLogix, and MicroLogix families.
Product Positioning: Designed for procurement engineers and system integrators sourcing certified HMI terminals for process control, discrete manufacturing, and infrastructure automation. This unit supports FactoryTalk View ME runtime software and is fully compatible with Studio 5000 Logix Designer ecosystems. Konmask.com supplies this module as a verified, tested replacement and new-stock component with full traceability documentation available upon request.
Complete Technical Specifications
- Part Number: 2711P-T12W22D9P-B
- Series: B (SER B)
- Platform: PanelView Plus 7 Standard
- Display Size: 12.1″ Widescreen TFT LCD
- Resolution: 1280 × 800 pixels (WXGA)
- Touch Technology: Analog Resistive Touch Screen
- Brightness: 400 cd/m²
- Operating System: Windows Embedded Compact 7
- Processor: 1 GHz ARM Cortex-A8
- RAM: 512 MB DDR3
- Flash Storage: 2 GB internal
- Communication Ports: Dual Ethernet (10/100 Mbps), USB 2.0 Host × 2, USB 2.0 Device × 1, RS-232
- Network Protocol: EtherNet/IP, DF1
- Power Supply: 24 VDC (18–32 VDC range)
- Power Consumption: 30 W typical
- Operating Temperature: 0°C to +55°C
- Storage Temperature: -20°C to +70°C
- Humidity: 5% to 95% RH (non-condensing)
- Protection Rating: NEMA 4/4X, 12, 13 (front panel); IP65 (front panel)
- Certifications: UL Listed, CE Marked, cUL, RCM
- Mounting: Panel cutout, landscape orientation
- Dimensions (H × W × D): 232 mm × 340 mm × 68 mm
- Weight: 2.45 kg
- Runtime Software: FactoryTalk View ME v9.0+
- Catalog Number: 2711P-T12W22D9P-B
Proven Application Environments
- Discrete Manufacturing: Automotive assembly lines, robotic cell operator stations, conveyor control panels
- Process Industries: Water/wastewater treatment SCADA interfaces, chemical dosing control, oil & gas wellhead monitoring
- Food & Beverage: Hygienic washdown environments (NEMA 4X rated front panel), batch process control
- Building Automation: HVAC system control, energy management dashboards
- Infrastructure: Power distribution substations, tunnel ventilation control, rail signaling operator panels
- Packaging: Form-fill-seal machine HMI, labeling line operator interface
Engineering Advantages
- Dual Ethernet Ports: Enables Device Level Ring (DLR) topology for fault-tolerant network redundancy without additional switches
- High-Resolution WXGA Display: 1280×800 resolution supports complex mimic diagrams and multi-window FactoryTalk View ME applications
- Windows Embedded Compact 7: Deterministic OS with long-term support lifecycle, compatible with legacy and current FactoryTalk ME projects
- IP65 / NEMA 4X Front Panel: Suitable for washdown and outdoor-rated enclosure installations without additional sealing
- USB Host Ports: Supports USB barcode scanners, printers, and project transfer drives natively
- Backward Compatibility: Accepts FactoryTalk View ME projects from PanelView Plus 6 with minimal migration effort
- Compact Depth Profile: 68 mm panel depth reduces enclosure size requirements
System Architecture & Signal Flow
The 2711P-T12W22D9P-B SER B operates as an EtherNet/IP Class 1 and Class 3 messaging node. In a typical ControlLogix architecture, the HMI connects via Ethernet to the L7x or L8x controller backplane through a 1756-EN2T or equivalent Ethernet bridge module. Tag-based communication is handled natively through FactoryTalk View ME’s direct tag browsing, eliminating the need for OPC middleware in standard deployments.
For DLR ring topologies, both Ethernet ports are configured as ring participants, with the PLC acting as ring supervisor. The USB Device port supports direct PC connection for project download and diagnostics via FactoryTalk View ME Studio. RS-232 provides legacy DF1 connectivity to MicroLogix and SLC 500 controllers where Ethernet is unavailable.
Sourcing & Quality Verification
- Source: Authorized distribution channels and verified industrial surplus with full chain-of-custody documentation
- Inspection Protocol: Each unit undergoes visual inspection, power-on functional test, and firmware version verification prior to shipment
- Firmware: Units shipped with factory-default or customer-specified FactoryTalk View ME runtime version upon request
- Packaging: Anti-static ESD packaging with original or equivalent protective foam insert
- Warranty: 12-month Konmask operational warranty; OEM warranty terms apply to new-stock units
- Counterfeit Prevention: All units verified against Rockwell Automation catalog markings, date codes, and serial number format standards
Procurement Process
- Inquiry: Submit your part number, required quantity, and delivery timeline to support@konmask.com or via the product page inquiry form
- Quote: Receive a formal quotation within 24 business hours including unit price, lead time, and shipping options (DHL Express, FedEx International Priority, sea freight)
- Order Confirmation: Purchase order accepted via email; proforma invoice issued for prepayment or net terms (approved accounts)
- Quality Check & Dispatch: Pre-shipment inspection report and packing list provided; tracking number issued within 1 business day of dispatch
- After-Sales Support: Technical assistance available for installation, firmware configuration, and FactoryTalk View ME project compatibility queries
Technical FAQ
Q: Is the 2711P-T12W22D9P-B SER B compatible with FactoryTalk View ME v8.x projects?
A: Yes. FactoryTalk View ME projects created in v8.x are forward-compatible with the SER B runtime. Minor display scaling adjustments may be required for WXGA resolution optimization.
Q: What is the difference between SER A and SER B?
A: Series B introduced updated processor firmware, improved USB host compatibility, and enhanced DLR ring recovery performance compared to Series A. SER B is the current production revision.
Q: Can this HMI communicate with non-Rockwell PLCs?
A: Natively, the 2711P-T12W22D9P-B supports EtherNet/IP and DF1 protocols. Third-party PLC communication requires a FactoryTalk Linx Gateway or compatible OPC server configuration.
Q: What panel cutout dimensions are required?
A: The required panel cutout is 318 mm (W) × 210 mm (H). Refer to Rockwell Automation installation instruction 2711P-IN006 for full mounting specifications.
Q: Is a replacement touch screen digitizer available separately?
A: Yes. Konmask.com stocks replacement touch screen assemblies and display modules for the PanelView Plus 7 12″ series. Contact support@konmask.com for availability.
