Allen-Bradley 5069-AENTR EtherNet/IP Adapter Module – CompactLogix 5380 Series
Imagine a high-speed automated production line suddenly losing network communication between its remote I/O chassis and the main controller. Without a reliable EtherNet/IP adapter, the entire system goes blind — operators lose real-time diagnostics, safety interlocks may trip, and unplanned downtime costs mount by the minute. The Allen-Bradley 5069-AENTR is the critical bridge that prevents this scenario, delivering deterministic, high-bandwidth EtherNet/IP connectivity for distributed CompactLogix 5380 I/O systems.
The 5069-AENTR occupies a flagship position within Rockwell Automation’s CompactLogix 5380 (Compact 5000) I/O platform — the most scalable and cybersecurity-hardened distributed I/O architecture in the Allen-Bradley portfolio. Designed for demanding discrete, process, and hybrid applications, this adapter is trusted by system integrators and OEMs across automotive, food & beverage, oil & gas, and semiconductor manufacturing worldwide.
Technical Specifications
- Catalog Number: 5069-AENTR
- Series: CompactLogix 5380 / Compact 5000 I/O
- Communication Protocol: EtherNet/IP (CIP)
- Network Ports: Dual RJ-45 (supports linear/ring DLR topology)
- Device Level Ring (DLR): Supported
- IP Address Configuration: BOOTP, DHCP, or static
- Backplane Compatibility: Compact 5000 I/O (5069-series) backplane
- Power Supply: Sourced from system power via backplane
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% non-condensing
- Enclosure Rating: Open type (IP20)
- Certifications: UL, CE, RCM, KC
- Weight: Approx. 300 g
Key Features & Benefits
- Dual-port DLR support — enables Device Level Ring topology for network resiliency without additional switches, minimizing single-point-of-failure risk.
- High-speed deterministic communication — ensures real-time I/O data exchange critical for motion-coordinated and safety-integrated systems.
- Seamless Studio 5000 integration — auto-discovery and Add-On Profile (AOP) support dramatically reduce commissioning time.
- CIP Security ready — supports encrypted communications to meet modern industrial cybersecurity standards (IEC 62443).
- Hot-swap capable — modules can be replaced under power, reducing maintenance downtime in live production environments.
- Compact form factor — fits within the space-efficient Compact 5000 chassis for panel-space-constrained installations.
- Diagnostic LEDs — onboard status indicators for network health, module status, and I/O faults enable rapid field troubleshooting.
Industry & Equipment Applications
- Automotive Manufacturing: Body welding lines, paint shop conveyors, and assembly robot cells requiring distributed I/O over EtherNet/IP.
- Food & Beverage: Hygienic packaging lines and filling machines with remote I/O drops in washdown zones.
- Oil & Gas: Remote wellhead monitoring and pipeline SCADA systems with ring-topology network redundancy.
- Semiconductor & Electronics: Cleanroom automation with strict EMI and communication reliability requirements.
- Water & Wastewater: Distributed pump station control with geographically separated I/O nodes.
- Material Handling: Warehouse sortation systems and conveyor networks with multiple remote I/O chassis.
System Integration & Compatible Parts
The 5069-AENTR is designed to work within the broader Allen-Bradley Compact 5000 ecosystem. Compatible and commonly paired components include:
- Controllers: 5069-L306ER, 5069-L310ER, 5069-L320ER (CompactLogix 5380 controllers)
- Power Supplies: 5069-PA4, 5069-PB4 (Compact 5000 I/O power supplies)
- Digital I/O: 5069-IB16, 5069-OB16 (16-point digital input/output modules)
- Analog I/O: 5069-IF8, 5069-OF8 (8-channel analog input/output modules)
- Safety I/O: 5069-IB8S, 5069-OBV8S (safety-rated I/O for SIL 2 / PLd applications)
- Network Infrastructure: Stratix 5400/5700 managed switches for larger EtherNet/IP topologies
Our Quality Assurance Process
At Konmask.com, every Allen-Bradley 5069-AENTR unit undergoes a rigorous multi-stage inspection before shipment:
- Visual Inspection: Examination of PCB, connectors, and housing for physical damage or counterfeit indicators.
- Firmware Verification: Confirmation of authentic Rockwell Automation firmware revision where applicable.
- Functional Testing: Power-on and communication handshake tests performed on compatible test benches.
- Authenticity Check: Cross-referenced against Rockwell Automation authorized distributor documentation and serial number databases.
- Packaging: ESD-safe anti-static bags, foam cushioning, and double-wall cartons for international freight.
How to Order
- Submit your inquiry via the Contact / RFQ form on this page with your required quantity and delivery timeline.
- Our technical sales team will respond within 24 business hours with availability, lead time, and a formal quotation.
- Upon PO confirmation, we arrange export documentation, freight, and customs clearance support.
- Tracking information is provided upon shipment; typical international delivery is 5–10 business days via DHL/FedEx.
Why Choose Konmask.com?
- ✅ Specialized in industrial automation components — Allen-Bradley, Siemens, Schneider, ABB, and more.
- ✅ Global B2B supply — serving system integrators, MRO teams, and OEMs in 50+ countries.
- ✅ Competitive pricing — new, surplus, and refurbished options to fit every project budget.
- ✅ Technical support — our engineers can assist with compatibility verification and system design questions.
- ✅ Secure transactions — T/T, L/C, and escrow payment options for international buyers.
- ✅ Export compliance — full documentation including CO, packing list, and commercial invoice.
Frequently Asked Questions
Q: What is the difference between 5069-AENTR and 5069-AENTRXT?
A: The 5069-AENTRXT is the extreme-temperature variant rated for -20°C to 70°C operation, designed for harsh environment installations. The standard 5069-AENTR is rated 0°C to 60°C for typical industrial environments.
Q: Can the 5069-AENTR be used with ControlLogix controllers?
A: No. The 5069-AENTR is exclusively designed for the Compact 5000 I/O backplane and is not compatible with ControlLogix (1756-series) or CompactLogix 5370 (1769-series) systems.
Q: Does the 5069-AENTR support Device Level Ring (DLR) topology?
A: Yes. The dual RJ-45 ports support DLR, allowing the adapter to participate in a ring network for automatic fault recovery without requiring a managed switch.
Q: What Studio 5000 version is required for the 5069-AENTR?
A: Studio 5000 Logix Designer v31.00 or later is recommended. Always verify the specific firmware revision compatibility in the Rockwell Automation Product Compatibility and Download Center (PCDC).
Q: Do you provide a warranty on surplus 5069-AENTR units?
A: Yes. All units sold through Konmask.com carry a minimum 90-day functional warranty. Extended warranty options are available upon request.
