Allen-Bradley MFIXSUP0601 193112 – Repair Support Circuit Board | Rockwell Automation Platform
Engineering Background
The Allen-Bradley MFIXSUP0601 (Catalog No. 193112) is a factory-original repair support circuit board engineered by Rockwell Automation for use within Allen-Bradley industrial control and motor protection systems. Designed to exacting OEM tolerances, this PCB assembly serves as a critical internal replacement component for field repair and depot-level maintenance of AB drive and protection modules.
Product Positioning
Procurement engineers and MRO specialists sourcing genuine AB repair parts will find the MFIXSUP0601 / 193112 board essential for restoring failed units to OEM specification — eliminating the cost and lead time of full module replacement. Konmask.com supplies this component from verified industrial channels with full traceability documentation available upon request.
Complete Technical Specifications
- Manufacturer: Allen-Bradley / Rockwell Automation
- Part Number: MFIXSUP0601
- Catalog / Series Number: 193112
- Component Type: Repair Support Circuit Board (PCB Assembly)
- Form Factor: Internal PCB — OEM replacement
- Weight: 40 g (bare board)
- Compatibility: Allen-Bradley motor protection / drive repair platforms (confirm parent unit catalog number before ordering)
- Condition: New / Surplus New (specify at inquiry)
- RoHS Compliance: Per Rockwell Automation product line standards
- Country of Origin: USA (Rockwell Automation manufacturing)
Proven Application Environments
- Depot and field repair of Allen-Bradley motor protection relays and drives
- MRO (Maintenance, Repair & Operations) spare parts programs for AB-equipped facilities
- OEM repair centers performing board-level restoration of AB control modules
- Automotive, food & beverage, oil & gas, and discrete manufacturing plants running Rockwell Automation infrastructure
- Utility and water treatment facilities with legacy AB protection systems
Engineering Advantages
- OEM Authenticity: Factory-original Rockwell Automation PCB — not a third-party clone or reverse-engineered substitute
- Precision Fit: Designed to exact mechanical and electrical tolerances of the parent module — no field modification required
- Cost Efficiency: Board-level repair cost is typically 20–40% of full module replacement list price
- Reduced Downtime: In-stock availability enables same-day or next-day dispatch versus 8–20 week OEM lead times for new modules
- Traceability: Lot and date code documentation available for regulated industries
System Architecture & Signal Flow
The MFIXSUP0601 board functions as a support/interface PCB within the parent Allen-Bradley module’s internal architecture. It typically handles auxiliary signal conditioning, power supply support, or communication interface functions depending on the parent unit. Installation requires removal of the parent module from the panel, ESD-safe handling, and board-level swap per Rockwell Automation service documentation. Refer to the parent module’s service manual (available from Rockwell Automation Literature Library) for torque specs, connector pinouts, and re-commissioning procedures.
Sourcing & Quality Verification
- All units sourced from authorized industrial distributors or verified surplus channels
- Visual inspection and basic functional screening performed prior to dispatch
- Original manufacturer packaging preserved where available
- Certificate of Conformance (CoC) available upon request for regulated procurement
- Anti-static packaging standard on all PCB shipments
- Photos of actual stock available pre-shipment upon request
Procurement Process
- Confirm Compatibility: Verify the MFIXSUP0601 / 193112 is the correct repair board for your specific parent module serial and revision
- Request Quote: Contact support@konmask.com for volume pricing, lead time, and CoC availability
- Place Order: Purchase directly via this listing or via PO for B2B accounts
- Receive & Inspect: All shipments include packing list; inspect upon receipt and report discrepancies within 48 hours
- Install & Commission: Follow Rockwell Automation service documentation; contact us for technical support during installation
Technical FAQ
Q: Is this a new or refurbished board?
A: We stock both new/surplus-new and professionally refurbished units. Condition is confirmed at time of order. Refurbished units carry a 90-day functional warranty.
Q: Which parent modules use the MFIXSUP0601 / 193112?
A: Please provide your parent module catalog number and serial number to our technical team for confirmation before ordering.
Q: Can you provide a datasheet or service manual?
A: Rockwell Automation service documentation is available via the RA Literature Library. We can assist in locating the correct document — contact support@konmask.com.
Q: Do you ship internationally?
A: Yes. We ship worldwide with DHL, FedEx, and UPS. Export documentation and EAR99 classification available upon request.
Q: What is the warranty?
A: New/surplus-new units: 12-month warranty against manufacturing defects. Refurbished units: 90-day functional warranty. Warranty void if board is damaged during installation.
