Allen-Bradley VPL-B1001M-CK12AA Rotary Servo Motor – Kinetix VP Low Inertia Series
Imagine a high-speed packaging line suddenly losing position accuracy mid-cycle — products misaligned, rejects piling up, and the entire production cell forced to halt while engineers scramble to diagnose the fault. In most cases, the root cause traces back to a single component: the servo motor. Without a precisely matched, application-rated servo motor like the Allen-Bradley VPL-B1001M-CK12AA, even the most sophisticated motion controller cannot deliver the dynamic response and positional repeatability that modern automated machinery demands.
The VPL-B1001M-CK12AA belongs to Rockwell Automation’s Kinetix VP (Variable Performance) Low Inertia servo motor family — a series engineered specifically for high-cycle, high-throughput applications where rapid acceleration, minimal rotor inertia, and seamless integration with Allen-Bradley Kinetix servo drives are non-negotiable. Within the Kinetix VP lineup, the B-frame, 100 W class motors occupy a critical niche: compact enough for space-constrained machine designs, yet powerful enough to drive precision axes in assembly, pick-and-place, and conveyor indexing systems. Globally, Kinetix VP motors are deployed across automotive, food & beverage, semiconductor, and logistics automation sectors, making this series one of the most widely specified servo motor families in North American and international OEM machine designs.
Technical Specifications
- Part Number: VPL-B1001M-CK12AA
- Series: Kinetix VP Low Inertia Rotary Servo Motor
- Frame Size: B (Compact)
- Feedback Type: Multi-turn Absolute Encoder (as indicated by suffix -CK12AA)
- Shaft Configuration: Keyed shaft with standard flange mount
- Connector Style: Bayonet-style power and feedback connectors
- Insulation Class: Class F
- Protection Rating: IP65 (shaft seal standard)
- Compatible Drive Family: Kinetix 5500, Kinetix 5700, Kinetix 6500
- Manufacturer: Rockwell Automation / Allen-Bradley
Note: Detailed electrical specifications (rated torque, speed, voltage) should be confirmed via the official Rockwell Automation product catalog or by contacting our technical team.
Key Features & Benefits
- Low Inertia Rotor Design: Enables faster acceleration and deceleration cycles, reducing cycle time and increasing machine throughput without oversizing the drive.
- Multi-turn Absolute Encoder: Retains position data through power cycles, eliminating homing routines on restart and reducing downtime after E-stops or power loss events.
- Plug-and-Play with Kinetix Drives: The VPL series uses Rockwell’s single-cable or standard cable architecture, simplifying wiring and reducing installation errors in new machine builds.
- IP65 Sealing: Protects against dust ingress and water jets, making the motor suitable for washdown-adjacent environments in food processing and pharmaceutical applications.
- Compact B-Frame Footprint: Ideal for machine designs with tight axis spacing, allowing higher axis density without sacrificing performance.
- Wide Drive Compatibility: Supported across multiple generations of Kinetix servo drives, protecting your machine design investment as drive platforms evolve.
- Genuine Rockwell Automation Quality: Manufactured to strict tolerances with full traceability, ensuring consistent performance and long service life in 24/7 production environments.
Industry & Equipment Applications
- Packaging Machinery: Horizontal flow wrappers, cartoners, case packers, and form-fill-seal machines requiring high-speed indexing axes.
- Assembly Automation: Robotic end-of-arm tooling, screw-driving stations, and precision press-fit operations.
- Pick-and-Place Systems: Delta robot axes and gantry systems in electronics and consumer goods assembly.
- Conveyor & Indexing: Servo-driven conveyor indexing in automotive body shops and tier-1 supplier lines.
- Semiconductor & Electronics: Wafer handling, PCB routing, and SMT placement machines requiring micron-level repeatability.
- Food & Beverage: Portioning, slicing, and filling machines where IP65 protection and hygienic design are required.
- Printing & Converting: Web tension control and registration axes in label printing and flexible packaging converting lines.
System Integration & Compatible Parts
The VPL-B1001M-CK12AA is designed for seamless integration within the Allen-Bradley Kinetix motion control ecosystem. Typical system configurations include:
- Compatible Servo Drives: Kinetix 5500 (2198-Hxxx), Kinetix 5700 (2198-Dxxx), Kinetix 6500 (2094-BCxx)
- Motion Controllers: CompactLogix 5380/5480, ControlLogix 5580 with Sercos or EtherNet/IP motion modules
- Power Cables: 2090-CPBM7DF series (standard) or 2090-CSBM1DF series (single-cable option, drive-dependent)
- Feedback Cables: 2090-CFBM7DF series for standard encoder connections
- Brake Options: Consult suffix codes for integrated holding brake variants within the VPL-B series
Our technical team can assist with complete BOM verification and drive-motor pairing confirmation before your order is placed.
Our Quality Assurance Process
At Konmask.com, every Allen-Bradley component we supply undergoes a structured verification process before shipment:
- Source Verification: Parts are sourced from authorized distributors, certified resellers, or directly from decommissioned OEM equipment with documented service history.
- Visual & Physical Inspection: Each unit is inspected for label integrity, connector condition, shaft runout, and housing damage.
- Authenticity Check: Part numbers, date codes, and manufacturer markings are cross-referenced against Rockwell Automation’s published specifications.
- Functional Testing (where applicable): Select units undergo bench testing with compatible drives to verify encoder communication and basic motor operation.
- Secure Packaging: Motors are packed in anti-static, shock-absorbing packaging with desiccant to prevent moisture ingress during international transit.
How to Order
- Submit your inquiry via the Contact Us form or email support@konmask.com with your required quantity and delivery timeline.
- Our technical team will confirm part availability, condition (new/surplus/refurbished), and provide a formal quotation within 24 business hours.
- Upon PO receipt, we arrange quality inspection, documentation, and export packaging.
- Shipment via DHL, FedEx, or UPS Express with full tracking and commercial invoice provided.
- Post-delivery technical support available for integration questions.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, servo, and motion control components — not a generalist electronics distributor.
- Global Sourcing Network: Access to surplus, new, and hard-to-find Allen-Bradley parts with shorter lead times than standard distribution channels.
- Technical Expertise: Our team includes engineers with hands-on experience in Rockwell Automation system integration, ensuring accurate part identification and compatibility advice.
- Transparent Documentation: Full traceability documentation, inspection reports, and shipping records provided with every order.
- Responsive Communication: Dedicated account management with response times under 24 hours for all inquiries.
- Competitive Pricing: Direct sourcing relationships allow us to offer competitive pricing on both single units and bulk orders.
Frequently Asked Questions
Q: Is the VPL-B1001M-CK12AA compatible with the Kinetix 5500 drive?
A: Yes, the VPL-B series is compatible with Kinetix 5500 drives. However, cable selection and drive firmware version should be verified against the Kinetix 5500 User Manual (publication 2198-UM001) before commissioning.
Q: What does the suffix -CK12AA indicate?
A: The suffix encodes the motor’s option codes including feedback type (multi-turn absolute encoder), connector style, shaft type, and brake configuration. Contact our team for a full suffix decode specific to this part number.
Q: Do you supply new or surplus units?
A: We supply both new (factory-sealed) and surplus (tested, inspected) units depending on availability. The condition is clearly stated in our quotation. All surplus units pass our quality inspection process before shipment.
Q: Can you provide a certificate of conformance or test report?
A: Yes. Documentation packages including inspection reports and, where available, original manufacturer certificates can be provided upon request at the time of quotation.
Q: What is the lead time for VPL-B1001M-CK12AA?
A: Lead time depends on current stock levels. Submit an inquiry and we will confirm availability and estimated ship date within 24 business hours.
Q: Do you ship internationally?
A: Yes. We ship globally via DHL, FedEx, and UPS Express. Export documentation including commercial invoice and packing list is provided for all international shipments.
