ALPHA CPCI-2IPC-6U – CompactPCI 6U Bus Motherboard Module | ALPHA Industrial Platform
Engineering Background
The ALPHA CPCI-2IPC-6U is a 6U-form-factor CompactPCI (CPCI) bus motherboard module engineered for high-reliability industrial computing environments. Designed to IEEE 1101.10/1101.11 mechanical standards and compliant with the PICMG 2.0 CompactPCI specification, this backplane module serves as the passive interconnect backbone for multi-slot IPC chassis deployments in process control, power automation, and transportation infrastructure.
Product Positioning
Targeted at procurement engineers and system integrators who require a proven, slot-compatible backplane for ALPHA-series CompactPCI single-board computers and peripheral cards. The CPCI-2IPC-6U provides a deterministic, noise-immune bus architecture that outperforms passive VME and ISA alternatives in EMI-dense industrial environments.
Complete Technical Specifications
- Part Number / SKU: CPCI-2IPC-6U
- Form Factor: 6U CompactPCI (CPCI)
- Bus Standard: PICMG 2.0 CompactPCI, 32-bit / 33 MHz PCI bus
- Slot Configuration: 2 IPC slots (system slot + peripheral slot)
- Connector Type: 2mm Hard Metric IEC 61076-4-101 (J1/J2)
- Board Dimensions: 6U (233.35 mm × 160 mm) per IEEE 1101.1
- Weight: 380 g
- Operating Temperature: -20°C to +70°C (industrial grade)
- Storage Temperature: -40°C to +85°C
- Humidity: 5% to 95% RH, non-condensing
- Power Supply: +5 V, +3.3 V, ±12 V via backplane power connector
- Vibration Resistance: IEC 60068-2-6 compliant
- EMC Compliance: CE / FCC Class A
- Country of Origin: China
- HS Code: 8537.10
Proven Application Environments
- Power grid SCADA and substation automation (IEC 61850 systems)
- Railway signaling and trackside control cabinets
- Oil & gas DCS expansion chassis
- Factory automation and motion control racks
- Telecommunications network equipment shelves
- Military and aerospace ground support equipment (COTS deployments)
Engineering Advantages
- Passive Backplane Architecture: No active components on the bus plane — eliminates single-point failure risk and simplifies MTBF calculations for SIL-rated systems.
- Hot-Swap Ready: Supports CompactPCI hot-swap (PICMG 2.1) when paired with compliant SBCs, enabling live maintenance without system shutdown.
- High EMI Immunity: Ground plane isolation and shielded connector shrouds suppress conducted and radiated interference in high-voltage switchgear environments.
- Compact 2-Slot Density: Optimized for space-constrained 6U chassis where a full 8-slot backplane is unnecessary, reducing BOM cost and chassis depth.
- Long-Term Availability: ALPHA maintains multi-year production commitments for industrial platforms, supporting 10+ year system lifecycles.
System Architecture & Signal Flow
The CPCI-2IPC-6U implements a star-topology PCI bus with the system slot (slot 1) acting as the bus arbiter host. The peripheral slot (slot 2) connects via the J1 (32-bit PCI) and J2 (user-defined I/O) connectors. Power distribution rails (+5 V / +3.3 V / ±12 V) are routed through dedicated copper planes with decoupling capacitor arrays at each slot position. The backplane accepts standard 6U CompactPCI cards with front-panel I/O extraction handles per IEEE 1101.11.
Signal integrity is maintained through controlled-impedance traces (50 Ω ± 10%) and series termination resistors on all PCI clock and data lines, ensuring clean bus transitions at 33 MHz across the full industrial temperature range.
Sourcing & Quality Verification
- Source: Authorized distributor and surplus channel — all units inspected before shipment.
- Authenticity: Each module ships with original ALPHA labeling and traceable lot codes.
- Inspection: Visual inspection, connector integrity check, and dimensional verification performed on 100% of stock.
- Packaging: Anti-static bag + foam-lined carton; conforms to JEDEC JESD625 ESD handling requirements.
- Warranty: 12-month replacement warranty against manufacturing defects.
Procurement Process
- Submit RFQ via support@konmask.com or add to cart directly.
- Receive proforma invoice with lead time confirmation within 1 business day.
- Payment via T/T (wire transfer), PayPal, or credit card.
- Shipment via DHL / FedEx / UPS with full tracking; export documentation (commercial invoice, packing list, COO) included.
- Post-delivery technical support available via email or WhatsApp.
Technical FAQ
Q: Is the CPCI-2IPC-6U compatible with 64-bit CompactPCI cards?
A: The backplane implements a 32-bit PCI bus. 64-bit CPCI cards can be installed in the peripheral slot but will operate at 32-bit width.
Q: Can this backplane be used with non-ALPHA SBCs?
A: Yes. Any PICMG 2.0-compliant CompactPCI single-board computer will be electrically compatible. Mechanical fit depends on the chassis vendor.
Q: What is the maximum power dissipation per slot?
A: The backplane is rated for up to 25 W per slot at +5 V, subject to chassis cooling capacity.
Q: Do you provide datasheet or test reports?
A: Yes. Contact support@konmask.com to request the ALPHA CPCI-2IPC-6U datasheet and available test documentation.
