HMS ANYBUS AB7697-F Fieldbus Gateway | Replacement, Equivalent & Selection Guide
The ANYBUS AB7697-F is a compact, DIN-rail-mounted Fieldbus-to-Fieldbus gateway manufactured by HMS Networks. It transparently bridges PROFIBUS DP (slave) on one side to DeviceNet (slave) on the other, enabling seamless data exchange between two otherwise incompatible industrial networks — without requiring a PLC or additional programming logic.
At Konmask.com, we supply the AB7697-F as a genuine, sourced-from-authorized-channels unit, backed by pre-shipment inspection and full traceability documentation.
Technical Specifications
- Part Number: AB7697-F
- Manufacturer: HMS Networks (ANYBUS brand)
- Series: Anybus Communicator
- Function: Fieldbus-to-Fieldbus Gateway (transparent data bridge)
- Network Side A: PROFIBUS DP – Slave, up to 12 Mbit/s, 9-pin D-Sub
- Network Side B: DeviceNet – Slave, 125 / 250 / 500 kbit/s, 5-pin open-style connector
- Data Exchange: Up to 244 bytes IN / 244 bytes OUT (PROFIBUS); up to 128 bytes IN / 128 bytes OUT (DeviceNet)
- Configuration: Via built-in web server (Ethernet service port) or ABC Config Tool
- Power Supply: 24 V DC ± 20%, max 200 mA
- Mounting: DIN rail (EN 50022)
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: −25 °C to +85 °C
- Protection Rating: IP20
- Dimensions (W × H × D): 27 × 127 × 117 mm
- Weight: approx. 700 g (with packaging)
- Certifications: CE, UL, cUL, ATEX Zone 2 (optional)
- Firmware: Field-upgradeable via Ethernet service port
Compatible Replacement & Equivalent Models
If the AB7697-F is unavailable or you are evaluating alternatives, the following models offer comparable PROFIBUS DP ↔ DeviceNet bridging functionality:
- HMS ANYBUS AB7697 – Non-F variant; functionally identical, different housing revision. Direct drop-in replacement in most installations.
- HMS ANYBUS ABC4090 – Anybus Communicator AC; supports PROFIBUS DP slave to DeviceNet slave with similar I/O capacity. Requires ABC Config Tool setup.
- Moxa MGate 5105-MB-EIP – Different protocol pair (Modbus ↔ EtherNet/IP), but comparable gateway architecture for cross-protocol bridging projects.
- Hilscher netTAP NT 100-RE-DP – PROFIBUS DP slave to various networks; consult datasheet for DeviceNet slave support.
- ProSoft Technology PLX31-EIP-DFNT – EtherNet/IP to DeviceNet gateway; suitable if the PROFIBUS side can be replaced with EtherNet/IP.
Note: Always verify I/O byte counts, baud rate support, and connector pinouts before substituting. Contact [email protected] for a free compatibility check.
Why Choose the Original AB7697-F
- Proven interoperability: Certified PROFIBUS and DeviceNet conformance testing ensures plug-and-play integration with Siemens, Rockwell, Omron, and other major PLCs.
- Zero-programming bridge: Transparent data mapping requires no ladder logic or function blocks — reducing commissioning time significantly.
- Web-based configuration: Built-in HTTP server allows parameter setup from any browser without proprietary software.
- Long-term availability: HMS Networks maintains active production and spare-parts support for the Communicator series.
- Compact DIN-rail form factor: 27 mm wide — fits in tight control cabinet layouts.
Typical Applications
- Integrating legacy PROFIBUS DP devices (drives, sensors, I/O blocks) into DeviceNet-based control systems
- Connecting Rockwell/Allen-Bradley DeviceNet scanners to Siemens PROFIBUS DP networks
- Brownfield automation upgrades where replacing existing fieldbus wiring is cost-prohibitive
- Multi-vendor machine lines requiring cross-protocol data sharing without a master PLC
- OEM machine builders standardizing on one gateway SKU across mixed-protocol customer sites
System Compatibility
- PROFIBUS DP Masters (Side A): Siemens S7-300/400/1500, Siemens ET 200, Beckhoff TwinCAT, Schneider Modicon Premium/Quantum
- DeviceNet Scanners (Side B): Allen-Bradley 1756-DNB, 1769-SDN, 1747-SDN; Omron CJ1W-DRM21; Moxa DN-1000
- Configuration Software: HMS ABC Config Tool (free download), standard web browser (Chrome, Firefox, Edge)
- GSD File: Available from HMS Networks for PROFIBUS DP master configuration
- EDS File: Available from HMS Networks for DeviceNet scanner configuration
Selection Guide
Use this guide to confirm the AB7697-F is the right gateway for your project:
- Step 1 – Identify your networks: Confirm Side A is PROFIBUS DP (slave role) and Side B is DeviceNet (slave role). If roles are reversed (master-to-master), a different model is required.
- Step 2 – Check I/O data size: Verify your process data fits within 244 bytes IN/OUT (PROFIBUS) and 128 bytes IN/OUT (DeviceNet).
- Step 3 – Confirm baud rates: PROFIBUS side auto-detects up to 12 Mbit/s. DeviceNet side supports 125 / 250 / 500 kbit/s — set via DIP switch.
- Step 4 – Cabinet space: Allocate 27 mm DIN-rail width and 24 V DC power supply.
- Step 5 – Certifications: For ATEX Zone 2 environments, confirm the -F suffix variant is required (consult HMS datasheet).
Not sure? Send your network topology diagram to [email protected] and our engineers will recommend the correct model.
Quality Assurance & Sourcing
- Units sourced from authorized HMS Networks distributors or verified secondary-market channels with full traceability
- Pre-shipment inspection: visual check, label verification, firmware version confirmation
- Anti-counterfeit measures: hologram label, serial number cross-check with HMS database where applicable
- Packaging: original HMS retail box or ESD-safe anti-static bag with foam insert
- Warranty: 12 months from shipment date (DOA replacement within 7 days)
How to Order
- Online: Add to cart directly on this page — stock status shown in real time
- Email RFQ: [email protected] — include quantity, required delivery date, and destination country
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Lead time: In-stock orders ship within 1–3 business days; out-of-stock sourcing typically 7–21 business days
- Payment: T/T (bank transfer), PayPal, credit card via Shopify Payments
- Export: We ship worldwide with DHL, FedEx, UPS, and sea freight options
Replacement & Compatibility FAQ
Q: Is the AB7697-F the same as the AB7697?
A: The -F suffix denotes a specific hardware or firmware revision. In most applications they are functionally interchangeable, but always verify the HMS datasheet for your firmware version requirements.
Q: Can the AB7697-F act as a PROFIBUS master?
A: No. The AB7697-F operates as a PROFIBUS DP slave only. For master-side bridging, consult HMS for the appropriate Communicator master variant.
Q: Does it support PROFIBUS PA?
A: No. The AB7697-F supports PROFIBUS DP only. PROFIBUS PA requires a separate DP/PA coupler upstream.
Q: What is the maximum cable length?
A: PROFIBUS DP cable length depends on baud rate (e.g., up to 1200 m at 93.75 kbit/s, 100 m at 12 Mbit/s). DeviceNet cable length follows the DeviceNet specification (up to 500 m trunk at 125 kbit/s).
Q: Can I get a GSD/EDS file?
A: Yes — available free from HMS Networks’ website or upon request from Konmask.com.
Q: Do you offer a warranty?
A: Yes, 12 months from shipment. DOA units are replaced within 7 business days.
