Applied Materials 0090-20429 Panel Assembly | Replacement, Equivalent & Selection Guide
The Applied Materials 0090-20429 Panel Assembly (also referenced as MICR-8226-TR-0554480-0161-098, 4S015-164, NK-C441-1, and 4S015-166-2) is a critical control panel assembly used in Applied Materials E-CLEAN semiconductor processing equipment. This guide covers technical specifications, compatible replacements, and selection criteria to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Manufacturer: Applied Materials (AMAT)
- Part Number: 0090-20429
- Cross-Reference / Alternate P/N: MICR-8226-TR-0554480-0161-098 | 4S015-164 | NK-C441-1 | 4S015-166-2
- Assembly Type: Panel Assembly (CH D, 4, 3 configuration)
- Platform: E-CLEAN Series
- Weight: Approx. 2.6 kg
- Condition: New / Refurbished Available
- Origin: USA (Applied Materials OEM)
Compatible Replacement & Equivalent Models
The following part numbers are confirmed compatible or functionally equivalent to the Applied Materials 0090-20429 Panel Assembly:
- MICR-8226-TR-0554480-0161-098 — Direct OEM cross-reference
- 4S015-164 — Alternate assembly designation (CH D,4,3)
- 4S015-166-2 — Revised revision equivalent
- NK-C441-1 — Sub-assembly panel reference
Always verify firmware revision and connector pinout before substituting. Contact our team for compatibility confirmation.
Why Choose the Original Model
- OEM-certified design ensures full compatibility with Applied Materials E-CLEAN process chambers
- Precision-engineered panel layout minimizes integration risk during replacement
- Validated against AMAT’s internal quality standards for semiconductor-grade environments
- Reduces downtime risk compared to third-party alternatives with unverified tolerances
Typical Applications
- Applied Materials E-CLEAN chamber control systems
- Semiconductor wafer cleaning and surface preparation equipment
- Fab maintenance and spare parts inventory for AMAT platforms
- OEM equipment refurbishment and upgrade projects
System Compatibility
- Platform: Applied Materials E-CLEAN (MICR-8226 series)
- Configuration: CH D, 4, 3 panel slot
- Interface: Compatible with standard AMAT backplane and wiring harness for this series
- Revision Notes: Covers revisions referenced under 4S015-164 and 4S015-166-2; confirm revision level with your system documentation
Selection Guide
Use the following criteria to select the correct panel assembly for your system:
- Step 1 — Identify your platform: Confirm your equipment is an Applied Materials E-CLEAN MICR-8226 series
- Step 2 — Verify slot configuration: Confirm CH D, position 4, sub-position 3 matches your chassis layout
- Step 3 — Cross-check part numbers: Match against 0090-20429, 4S015-164, NK-C441-1, or 4S015-166-2
- Step 4 — Confirm revision: Check your system BOM or engineering drawing for revision suffix
- Step 5 — Contact us: If uncertain, send your system serial number or BOM to [email protected] for expert verification
Quality Assurance & Sourcing
- All units sourced from authorized distributors or directly from OEM-certified supply chains
- Each assembly undergoes visual inspection and functional verification prior to shipment
- Packaging complies with ESD-safe standards for sensitive electronic assemblies
- Traceability documentation available upon request (CoC, test reports)
How to Order
- Online: Add to cart directly on this page
- Email: [email protected] — include your part number, quantity, and delivery location
- Phone/WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 1–3 business days; special orders 5–15 business days
- Payment: T/T, PayPal, credit card accepted
Replacement & Compatibility FAQ
Q: Is 4S015-164 a direct replacement for 0090-20429?
A: Yes, 4S015-164 is an alternate part number for the same panel assembly used in the CH D,4,3 slot of the E-CLEAN MICR-8226 platform.
Q: Can NK-C441-1 be used as a substitute?
A: NK-C441-1 references a sub-assembly panel component. Confirm full assembly vs. sub-assembly requirement before ordering.
Q: Do you supply refurbished units?
A: Yes. Refurbished units are available with full test reports. Please specify when ordering.
Q: What is the warranty?
A: New OEM units carry standard manufacturer warranty. Refurbished units carry a 90-day functional warranty from Konmask.
Q: Can you ship internationally?
A: Yes. We ship worldwide via DHL, FedEx, and UPS with full export documentation.
