Applied Materials 0190-09956 HPM5A2F2A6S307 ADVME1522A PCB Assembly | Replacement, Equivalent & Selection Guide
The Applied Materials 0190-09956 (also referenced as HPM5A2F2A6S307 / ADVME1522A) is a high-precision PCB Assembly designed for use in Applied Materials semiconductor processing equipment. This page provides full technical specifications, compatible replacement options, and a structured selection guide to help engineers and procurement teams make informed sourcing decisions.
Technical Specifications
- Part Number: 0190-09956
- Reference / Sub-PN: HPM5A2F2A6S307 / ADVME1522A
- Description: PCB Assembly (PCB ASSY)
- Manufacturer: Applied Materials (AMAT)
- Product Category: Semiconductor Equipment Spare Parts — PCB / Control Board
- Form Factor: Printed Circuit Board Assembly
- Condition Available: New OEM / Refurbished / Tested Used
- Weight: ~20 g (bare board; actual shipping weight varies with packaging)
- Compliance: RoHS-compatible (verify with OEM datasheet for specific revision)
Compatible Replacement & Equivalent Models
When sourcing a replacement for the Applied Materials 0190-09956, the following part numbers are commonly cross-referenced. Always verify firmware revision and connector pinout before substitution:
- 0190-09956 — Primary OEM part number (Applied Materials)
- HPM5A2F2A6S307 — Internal assembly reference / sub-PN
- ADVME1522A — Board-level identifier (Advantech VME platform derivative)
- Functionally equivalent boards within the same HPM (High-Power Module) family may be evaluated on a case-by-case basis; contact our technical team for cross-reference validation.
Why Choose the Original Model
- OEM-Validated Performance: Designed and qualified by Applied Materials for specific process chambers, ensuring full compatibility with AMAT software and hardware stacks.
- Reduced Qualification Risk: Using the original PN eliminates re-qualification cycles required for third-party alternatives.
- Long-Term Support: OEM part numbers are traceable through Applied Materials’ service and support infrastructure.
- Process Stability: Critical for high-yield semiconductor fabs where board-level variation can impact process repeatability.
Typical Applications
- Applied Materials CVD / PVD / Etch process chambers
- High-Power Module (HPM) control and monitoring subsystems
- Semiconductor wafer fabrication equipment (200 mm / 300 mm platforms)
- Equipment maintenance, spare parts inventory, and emergency replacement programs
- Refurbishment and remanufacturing of AMAT tool sets
System Compatibility
- Platform: Applied Materials semiconductor processing systems utilizing HPM5-series high-power modules
- Board Architecture: VME-compatible (ADVME1522A designation indicates Advantech VME form factor integration)
- Interface: Verify backplane connector type and slot assignment against your specific tool configuration before ordering
- Firmware: Confirm firmware version compatibility with your tool’s software release; contact us for revision-specific guidance
Selection Guide
Use the following checklist to confirm the correct part for your application:
- ✅ Confirm OEM part number on the existing board label: 0190-09956
- ✅ Verify sub-PN / assembly reference: HPM5A2F2A6S307 and/or ADVME1522A
- ✅ Check tool model and process chamber designation (CVD, PVD, Etch, etc.)
- ✅ Identify required board condition: New OEM / Refurbished / Tested Used
- ✅ Confirm firmware revision requirements with your process engineering team
- ✅ Validate lead time requirements — contact us for in-stock availability and expedited shipping options
Quality Assurance & Sourcing
- Inspection: All boards undergo visual inspection and functional verification prior to shipment
- Traceability: Full lot traceability documentation available upon request
- Packaging: ESD-safe anti-static packaging with moisture barrier as standard
- Warranty: Contact us for warranty terms applicable to your selected condition (New / Refurbished / Used)
- Sourcing: Konmask.com sources from authorized distributors and qualified secondary market suppliers; counterfeit-prevention screening applied
How to Order
- Add the item to your cart and proceed to checkout, or
- Contact us directly for bulk orders, custom lead times, or technical pre-sales support:
- 📧 Email: support@konmask.com
- 📞 Phone / WhatsApp: +0086 19859288691
- 🌐 Website: https://Konmask.com
Please include your tool model, current part number, and required quantity when contacting us to expedite your quote.
Replacement & Compatibility FAQ
Q: Is 0190-09956 the same as ADVME1522A?
A: They reference the same physical assembly at different levels — 0190-09956 is the Applied Materials OEM part number, while ADVME1522A is the board-level identifier. Both should be verified against your tool’s BOM.
Q: Can I use a refurbished board in a production environment?
A: Refurbished boards that have been fully tested and certified can be used in production, subject to your fab’s qualification policy. Contact us for test reports and certification documentation.
Q: What is the lead time for this part?
A: Lead time varies by condition and current stock. Contact us at support@konmask.com for real-time availability.
Q: Do you offer a warranty?
A: Yes. Warranty terms depend on the condition of the part supplied. Details are provided at the time of quotation.
Q: Can you cross-reference other AMAT part numbers to this board?
A: Yes — send us your part number or board photo and we will provide a cross-reference analysis at no charge.
