Thin Film Deposition Solution — Applied Materials 0240-20592 | Endura PVD Series
Where This Product Is Used
The Applied Materials 0240-20592 PVD Chamber Integration Kit is engineered for physical vapor deposition (PVD) process chambers used in front-end semiconductor wafer fabrication. Typical deployment environments include:
- Logic & Memory Fabs — barrier/seed layer deposition for Cu interconnects (28 nm–3 nm nodes)
- MEMS & Power Device Manufacturing — metal stack deposition on silicon substrates
- Flat Panel Display (FPD) Lines — ITO and metal thin-film sputtering chambers
- Advanced Packaging — UBM (Under Bump Metallization) and RDL seed layer processes
- R&D & Pilot Lines — process development on Applied Materials Endura platform tools
Technical Specifications
| Attribute | Detail |
|---|---|
| Part Number (Primary) | 0240-20592 |
| Associated Part Numbers | 2214-25ML | 0190-12138 | PV2A015SMT1P50-1 |
| Description | PVD Chamber Integration Kit |
| OEM / Manufacturer | Applied Materials (AMAT) |
| Platform Compatibility | Endura PVD Series (confirmed); consult datasheet for additional platforms |
| Kit Contents | Multi-component integration assembly (seals, fittings, and chamber interface hardware) |
| Weight | 1,450 g (approx.) |
| Condition | New / Refurbished — specify at inquiry |
| Lead Time | Subject to stock; contact for availability |
Why Engineers Specify This Model
- OEM-Matched Tolerances — Dimensional and material specs align with Applied Materials chamber design, minimizing process drift after PM.
- Multi-PN Cross-Reference — Covers 2214-25ML, 0190-12138, and PV2A015SMT1P50-1 under a single kit, reducing BOM complexity.
- Reduced Downtime Risk — Pre-kitted components eliminate sourcing delays for individual sub-parts during scheduled preventive maintenance windows.
- Verified Sourcing — Konmask.com traces each unit through documented supply channels with full traceability records available on request.
Complete System Bill of Materials
This kit is typically used alongside the following components in a PVD chamber PM cycle:
- Target assembly / backing plate
- Chamber shield set (deposition ring, cover ring, shadow ring)
- Elastomer seal kit (O-rings, foreline seals)
- RF match network components
- Wafer lift pin assembly
- Cryopump / turbopump service kit
Contact Konmask for cross-referenced part numbers and bundle pricing on complete PM kits.
Compliance & Industry Standards
- Designed for use in SEMI S2/S8-compliant equipment environments
- Compatible with SEMI F47 voltage sag immunity requirements (tool-level)
- RoHS status: confirm with Konmask at time of order for specific lot
- ESD-safe packaging and handling per ANSI/ESD S20.20
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation and semiconductor process equipment components. Every unit of the 0240-20592 kit is:
- Inspected against OEM dimensional references prior to shipment
- Stored in a climate-controlled, ESD-safe warehouse
- Accompanied by a Konmask inspection certificate upon request
- Traceable to documented supply chain records
How to Source This Part
- Submit a quote request via Konmask.com with your required quantity and delivery timeline.
- Receive a formal quotation within 1 business day.
- Confirm order — payment via T/T, PayPal, or trade terms for qualified accounts.
- Shipment via DHL / FedEx / sea freight with full tracking and export documentation.
📧 [email protected] | 📞 +0086 19859288691
Application-Specific FAQ
Q: Is the 0240-20592 compatible with both 200 mm and 300 mm Endura platforms?
A: Platform compatibility depends on the specific chamber configuration. Please provide your tool model and chamber type when requesting a quote so we can confirm fitment.
Q: Can I order individual sub-components from this kit separately?
A: Yes. Konmask can source individual sub-parts (cross-referenced by PN 2214-25ML, 0190-12138, PV2A015SMT1P50-1) separately. Contact us with your specific requirement.
Q: What is the typical shelf life / storage requirement?
A: Store in a dry, ESD-safe environment at 15–30 °C, away from UV and chemical exposure. Elastomeric components should be used within OEM-recommended shelf life windows.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes. A Konmask inspection certificate is available upon request. OEM CoC availability depends on the sourcing channel for each specific lot.
Q: What is the lead time for bulk orders?
A: Standard stock orders ship within 3–5 business days. For bulk or urgent requirements, contact us directly for expedited options.
