Semiconductor Process Control Solution — Applied Materials AS00800-10-1 | SG25SA-P01U3 Series
Where This Product Is Used
The Applied Materials AS00800-10-1 (P/N 0190-47445) PCB Board — also referenced as SG25SA-P01U3 / SGMP-01U314M — is a critical control and signal-processing assembly deployed inside Applied Materials CVD (Chemical Vapor Deposition) and PVD (Physical Vapor Deposition) semiconductor fabrication systems. Typical installation environments include:
- 300 mm wafer fab process chambers (AMAT Centura, Producer, and Endura platforms)
- MKS Instruments gas delivery and pressure control subsystems (cross-referenced: MKS A 10 TTT)
- Etch and deposition tool mainframes requiring precision analog/digital I/O control
- Semiconductor OEM equipment maintenance and refurbishment lines
- Spare-parts inventory for Tier-1 foundries and IDMs (Integrated Device Manufacturers)
Technical Specifications
- Manufacturer: Applied Materials (AMAT)
- Primary Part Number: AS00800-10-1
- Alternate / Cross-Reference P/N: 0190-47445
- Assembly Reference: SG25SA-P01U3 / SGMP-01U314M
- MKS Cross-Reference: A 10 TTT
- Component Type: Printed Circuit Board (PCB) Assembly
- Form Factor: OEM-specific card assembly
- Application: Process control signal I/O, gas flow / pressure management interface
- Condition: New / Refurbished / Tested (specify at inquiry)
- Weight: ~20 g (bare board; packaging weight varies)
Why Engineers Specify This Model
- OEM-Matched Performance: Designed to Applied Materials’ exact electrical and mechanical tolerances — no field re-calibration required on drop-in replacement.
- Multi-Platform Compatibility: Validated across Centura, Producer SE, and Endura mainframes; MKS subsystem cross-compatibility confirmed.
- Reduced Downtime Risk: Stocking this board as a critical spare eliminates unplanned tool downtime caused by PCB failure — a common root cause in aging CVD/PVD chambers.
- Traceable Sourcing: Each unit ships with full part-number traceability documentation, supporting ISO 9001 and SEMI S2 compliance audits.
Complete System Bill of Materials
This PCB board is commonly sourced alongside the following complementary components for full subsystem restoration:
- MKS Instruments pressure transducer / controller (A 10 TTT series)
- Applied Materials gas box manifold assemblies (Centura / Producer platform)
- RF match network interface boards
- Chamber I/O interface cables and harness assemblies
- Replacement fuse kits and connector hardware for PCB card cage
Contact us for bundled BOM sourcing — we can consolidate multi-line orders into a single shipment.
Compliance & Industry Standards
- SEMI S2 / S8 Environmental, Health & Safety guidelines
- RoHS / WEEE compliance documentation available on request
- ISO 9001:2015 supply-chain traceability
- ESD-safe packaging (ANSI/ESD S20.20)
- Export classification: ECCN EAR99 (verify with your compliance team for destination-specific controls)
Quality Assurance & Sourcing
All PCB assemblies sourced through Konmask.com undergo a structured verification process:
- Visual inspection against OEM reference imagery
- Part-number label and date-code verification
- Functional bench test where applicable (specify requirement at order)
- Anti-static, moisture-barrier packaging with desiccant
- Certificate of Conformance (CoC) issued with each shipment
How to Source This Part
- Confirm your part number — cross-check AS00800-10-1 against your tool’s BOM or service manual (P/N 0190-47445 / SG25SA-P01U3 / SGMP-01U314M are accepted equivalents).
- Submit a quote request — email [email protected] with your required quantity, condition preference (new/refurbished/tested), and target delivery date.
- Receive lead-time & pricing — typical response within 24 business hours; expedited sourcing available.
- Place order & confirm shipping — DHL / FedEx / UPS international express; EXW Xiamen or CIF terms available.
Application-Specific FAQ
Q: Is AS00800-10-1 compatible with both Centura and Producer platforms?
A: Yes. This board is used across multiple AMAT platform generations. Confirm your tool’s service manual revision before installation.
Q: What is the difference between AS00800-10-1 and 0190-47445?
A: These are dual part-number references for the same assembly — AS00800-10-1 is the AMAT internal engineering number; 0190-47445 is the field-service / spare-parts catalog number.
Q: Can you supply a tested/functional unit?
A: Yes. Specify “tested” condition at inquiry. Functional test reports are available for an additional lead time of 3–5 business days.
Q: Do you offer volume pricing for fab spare-parts programs?
A: Yes. Contact us for annual blanket-order pricing and consignment stocking programs.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. Sourced units typically require 5–15 business days depending on global availability.
