Industrial Process Temperature Sensing Solution – BASF Catalysts EHK15-TW1 | 91090028 F977-R-10″
Where This Product Is Used
The BASF Catalysts EHK15-TW1 Thermocouple Probe (P/N 91090028, cross-references: 802-0051-00 / 502-0051-01 / 602-0051) is engineered for demanding temperature measurement in high-temperature, chemically aggressive industrial environments. Typical deployment scenarios include:
- Catalytic reactor beds – continuous monitoring of exothermic reaction zones in petrochemical and refining processes
- Chemical process vessels – precise temperature profiling inside reactors, autoclaves, and distillation columns
- Emissions control systems – SCR (Selective Catalytic Reduction) and oxidation catalyst units requiring stable, long-life probes
- Polymer & specialty chemical plants – polymerization reactors where temperature uniformity is critical to product quality
- Pharmaceutical manufacturing – validated temperature measurement in GMP-regulated process equipment
- Power generation – boiler and heat exchanger monitoring in utility and co-generation facilities
Technical Specifications
| Part Number | 91090028 |
| Model / Series | EHK15-TW1 |
| Drawing / Config Code | F977-R-10″ |
| Cross-Reference P/Ns | 802-0051-00 | 502-0051-01 | 602-0051 |
| Sensor Type | Thermocouple Probe (Thermowell-mounted) |
| Probe Length | 10 inches (254 mm) insertion length |
| Manufacturer | BASF Catalysts LLC |
| Country of Origin | Germany (DE) |
| HS Code | 9025.19 |
| Weight | 360 g |
| Shipping | Physical item – requires shipping |
Why Engineers Specify This Model
- OEM-grade accuracy – manufactured to BASF Catalysts’ internal process control standards, ensuring tight temperature tolerances in catalyst bed applications
- Multi-reference compatibility – single physical part covers four P/N variants (91090028, 802-0051-00, 502-0051-01, 602-0051), simplifying procurement and spare-parts management
- Thermowell-ready design – F977-R-10″ configuration fits standard thermowell installations, enabling hot-swap replacement without process shutdown
- Chemically resistant construction – materials selected for compatibility with catalyst slurries, process gases, and cleaning agents
- Long service life – robust sheath and junction design minimizes drift and extends calibration intervals in continuous-duty service
Complete System Bill of Materials
For a complete temperature measurement loop using the EHK15-TW1, engineers typically specify:
- EHK15-TW1 Thermocouple Probe (this item) – P/N 91090028
- Matching thermowell (10″ insertion, process-rated flange or NPT connection)
- Thermocouple extension cable (matching thermocouple type, shielded)
- Temperature transmitter or DCS/PLC analog input module
- Terminal head / connection head assembly
- Compression fitting or flange adapter (per process connection standard)
Compliance & Industry Standards
- Designed in accordance with IEC 60584 thermocouple tolerance classes
- Compatible with NAMUR NE 43 signal range conventions for process instrumentation
- Suitable for use in facilities operating under ISO 9001 quality management systems
- HS Code 9025.19 – instruments for measuring temperature (other than thermometers)
- Country of origin: Germany – eligible for applicable trade preference programs
Quality Assurance & Sourcing
Konmask.com sources industrial automation components directly from authorized distributors and verified surplus channels. Every unit undergoes:
- Visual and dimensional inspection against OEM drawings
- Part number and label verification (P/N, date code, country of origin)
- Packaging integrity check prior to dispatch
All items are shipped with original manufacturer packaging where available. Certificates of conformance (CoC) and test reports can be provided upon request.
How to Source This Part
To place an order or request a quote for the BASF Catalysts EHK15-TW1 Thermocouple Probe (91090028):
- Online: Add to cart directly on this page – we accept T/T, PayPal, and major credit cards
- Email RFQ: [email protected] – include quantity, required delivery date, and destination port
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Bulk / project orders: Contact us for volume pricing and lead-time commitments
Application-Specific FAQ
Q: Is the EHK15-TW1 a Type K or Type J thermocouple?
A: The EHK15 designation indicates a Type K (Chromel-Alumel) thermocouple element, suitable for temperatures up to approximately 1260 °C in oxidizing atmospheres. Please confirm with your process datasheet before installation.
Q: Can this probe replace 802-0051-00 directly?
A: Yes. P/Ns 802-0051-00, 502-0051-01, and 602-0051 are all cross-references to the same physical assembly (91090028 / F977-R-10″). Verify thermowell bore diameter and insertion length before installation.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. For out-of-stock situations, typical lead time is 2–4 weeks. Contact us for real-time availability.
Q: Do you provide calibration certificates?
A: Calibration certificates from the OEM or a third-party NIST-traceable lab can be arranged upon request at additional cost.
Q: Is this part RoHS compliant?
A: BASF Catalysts components are manufactured for industrial process use. RoHS compliance documentation can be requested – contact our technical team for the latest compliance declaration.
