Industrial Logic Control Solution – Beckhoff 0024105677D1321 | CX Series Binary Calculation Module
Where This Product Is Used
The Beckhoff 0024105677D1321 Binary Calculation Module is deployed across demanding industrial environments where deterministic binary logic processing is critical. Typical application scenarios include:
- Discrete Manufacturing Automation – Coordinating multi-axis conveyor sequencing, part detection, and reject logic in automotive assembly lines.
- Machine Tool Control – Executing high-speed Boolean operations for CNC spindle interlocks, tool-change sequences, and safety gate monitoring.
- Packaging & Filling Lines – Managing fill-level comparisons, cap-torque verification, and label-presence detection via binary I/O logic.
- Building Automation & HVAC – Handling binary status signals from damper actuators, VAV controllers, and fire-suppression interlocks within a Beckhoff CX-based BMS.
- Process Industry (Oil & Gas / Chemical) – Integrating with EtherCAT I/O terminals for valve open/close status, pump run/fault logic, and emergency shutdown (ESD) sequences.
- Renewable Energy & Power Distribution – Supporting binary state monitoring in wind turbine pitch control cabinets and solar inverter protection relay logic.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | 0024105677D1321 |
| Manufacturer | Beckhoff Automation |
| Series | CX Series Embedded PC / Calculation Module |
| Module Type | Binary Calculation Module |
| Communication Interface | EtherCAT (primary); compatible with TwinCAT 2/3 runtime |
| Logic Processing | Deterministic binary (Boolean) computation |
| Operating Voltage | 24 V DC (nominal) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -25 °C to +85 °C |
| Protection Rating | IP20 (panel-mount installation) |
| Weight | 220 g |
| Mounting | DIN rail (35 mm) |
| Certifications | CE, UL (refer to Beckhoff datasheet for full listing) |
Note: Specifications are based on Beckhoff published data. Always verify against the official Beckhoff datasheet for your revision.
Why Engineers Specify This Model
- Seamless CX Ecosystem Integration – Plugs directly into the Beckhoff CX Series backplane, eliminating external wiring between the CPU and calculation layer.
- TwinCAT 3 Native Support – Fully programmable in IEC 61131-3 languages (LD, FBD, ST, IL, SFC) within TwinCAT 3 XAE, reducing engineering time.
- Deterministic Cycle Times – EtherCAT-synchronized execution ensures sub-millisecond binary logic updates, critical for safety-rated and motion-critical applications.
- Compact DIN-Rail Form Factor – Minimizes control cabinet footprint without sacrificing processing capability.
- Long-Term Availability – Beckhoff’s modular architecture ensures backward compatibility and long product lifecycle support.
Complete System Bill of Materials
For a complete Beckhoff CX-based control system incorporating this module, engineers typically specify:
- Beckhoff CX Series Embedded PC (e.g., CX5130, CX5140) – Main CPU
- 0024105677D1321 – Binary Calculation Module (this item)
- Beckhoff EL1008 / EL1809 – 8/16-channel digital input terminals
- Beckhoff EL2008 / EL2809 – 8/16-channel digital output terminals
- Beckhoff EL6001 – Serial communication terminal (RS-232) if legacy device integration required
- Beckhoff EL9011 – Bus end terminal (required at end of EtherCAT terminal block)
- 24 V DC DIN-rail power supply (e.g., Phoenix Contact QUINT series)
- TwinCAT 3 Engineering License (TC1200 PLC or higher)
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive and EMC Directive
- IEC 61131-3 – Programming language standard for industrial PLCs
- IEC 61000-4 – EMC immunity standards for industrial environments
- UL Listed – Recognized for use in North American industrial control panels (verify specific UL file with Beckhoff)
- RoHS Compliant – Restriction of Hazardous Substances Directive (EU 2011/65/EU)
Quality Assurance & Sourcing
At Konmask.com, every Beckhoff module is sourced through verified industrial supply channels. Our quality process includes:
- Visual inspection and label verification against Beckhoff OEM packaging standards
- Functional power-on verification prior to shipment where applicable
- Anti-static packaging with humidity indicator cards for sensitive electronics
- Traceability documentation available upon request for MRO and OEM procurement teams
How to Source This Part
Ready to order the Beckhoff 0024105677D1321? Here’s how:
- Online: Add to cart directly on this page. We accept T/T bank transfer, PayPal, and major credit cards.
- RFQ / Bulk Orders: Email support@konmask.com with your quantity and required delivery date for a competitive quote.
- Lead Time: In-stock units ship within 1–3 business days. Out-of-stock items: contact us for ETA.
- Export & Cross-Border: We ship globally. DDP, DAP, and EXW Incoterms available. HS Code: 8537.10 (programmable controllers).
Application-Specific FAQ
Q: Is the 0024105677D1321 compatible with TwinCAT 3?
A: Yes. This module is designed for the Beckhoff CX Series ecosystem and is fully supported under TwinCAT 3 (TC3) runtime environments.
Q: Can this module be used as a standalone PLC?
A: No. It functions as a calculation/logic module within a CX Series system and requires a CX Embedded PC as the host CPU.
Q: What is the warranty on this product?
A: Konmask.com provides a 90-day functional warranty on all modules. Extended warranty and service contracts are available — contact us for details.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes, CoC documentation is available upon request for OEM and MRO procurement requirements.
Q: Can I return the module if it doesn’t fit my application?
A: Please contact support@konmask.com within 7 days of receipt. Returns are accepted for unused, unopened items in original packaging.
