Beckhoff CP6606-0001-0020 7-Inch Economy Panel PC | Replacement, Equivalent & Selection Guide
The Beckhoff CP6606-0001-0020 is a compact 7-inch Economy Panel PC designed for cost-effective HMI and control applications in industrial automation. Built on the Beckhoff CP66xx series platform, it integrates a fanless embedded PC with a resistive touchscreen display, making it ideal for machine-level visualization and control tasks. Konmask.com supplies genuine and compatible units with full technical support.
Technical Specifications
- Model: CP6606-0001-0020
- Brand: Beckhoff Automation
- Series: CP66xx Economy Panel PC
- Display: 7-inch TFT LCD, 800 × 480 px, resistive touchscreen
- Processor: Intel Atom E3827 (1.75 GHz, dual-core)
- Memory: 2 GB DDR3L RAM (onboard)
- Storage: 8 GB CFast card (industrial grade)
- Operating System: Windows Embedded Standard 7 / CE (configurable)
- Interfaces: 2× USB 2.0, 1× DVI-D, 1× RJ45 (EtherCAT/LAN), 1× RS232
- Power Supply: 24 V DC (−15% / +20%)
- Protection Rating: IP65 (front panel)
- Operating Temperature: 0 °C to +55 °C
- Dimensions (W × H × D): 214 × 158 × 45 mm
- Mounting: Panel cut-out, VESA 75
- Certifications: CE, UL, cULus
Compatible Replacement & Equivalent Models
When the CP6606-0001-0020 is unavailable or cost-prohibitive, the following models offer functional equivalence or direct drop-in replacement potential:
- Beckhoff CP6606-0001-0000 — Same platform, standard CFast configuration; direct variant swap
- Beckhoff CP6607-0001-0020 — 7-inch, higher-spec CPU; upward-compatible upgrade path
- Beckhoff CP6600-0001-0020 — 5.7-inch predecessor; downgrade option for space-constrained panels
- Siemens SIMATIC IPC277E (6AV7422-0AA00-0AC0) — 7-inch Panel PC; alternative brand with comparable I/O
- Advantech TPC-1070H — 7-inch fanless Panel PC; compatible with TwinCAT via OPC-UA
- Kontron KP07 — 7-inch industrial panel; suitable for non-EtherCAT environments
Note: Always verify electrical, mechanical, and software compatibility before substitution. Contact Konmask for a free compatibility assessment.
Why Choose the Original Model
- Native TwinCAT 3 Integration: Seamless runtime support without additional licensing or driver configuration
- EtherCAT Master Ready: Direct EtherCAT port eliminates the need for an external coupler
- IP65 Front Panel: Suitable for wash-down and dusty environments without additional enclosure
- Fanless Design: Zero moving parts — reduced maintenance and extended MTBF in harsh conditions
- Beckhoff Ecosystem Compatibility: Plug-and-play with EL/EK terminals, AX5000 drives, and AM8000 motors
- Long-term Availability: Beckhoff industrial lifecycle policy ensures parts availability for 10+ years
Typical Applications
- Machine-level HMI visualization on packaging and printing lines
- Decentralized control panels in food & beverage processing
- Operator terminals for conveyor and material handling systems
- Building automation control stations (HVAC, access control)
- OEM machine builders requiring compact, cost-effective panel integration
- Retrofit projects replacing legacy operator panels
System Compatibility
- Software: TwinCAT 2 / TwinCAT 3, CODESYS, WinCC (via OPC), LabVIEW (via OPC-UA)
- Fieldbus: EtherCAT (native), PROFINET (via EL6631), EtherNet/IP (via EL6652), Modbus TCP
- I/O Terminals: Beckhoff EL/KL/EP series, compatible third-party EtherCAT slaves
- SCADA: Inductive Automation Ignition, Wonderware, Citect (via OPC-DA/UA)
- Cloud/IIoT: MQTT, OPC-UA, Azure IoT Hub (with TF6701 license)
Selection Guide
Use the table below to select the correct CP66xx variant for your application:
- Display size 5.7″: CP6600-0001-0020 — entry-level, minimal I/O
- Display size 7″ (standard): CP6606-0001-0020 ← This model — balanced cost/performance
- Display size 7″ (high-performance): CP6607-0001-0020 — faster CPU, more RAM
- Display size 12″: CP6612-0001-0020 — large-format operator station
- Display size 15″: CP6615-0001-0020 — supervisory HMI, multi-touch
For multi-axis motion control or real-time requirements below 250 µs, consider upgrading to the CP6607 or CP6902 series.
Quality Assurance & Sourcing
- All units sourced from authorized Beckhoff distribution channels or verified surplus stock
- Pre-shipment functional test: power-on, display, USB, LAN, and touchscreen verification
- Original packaging preserved where available; anti-static ESD packaging for all shipments
- Traceability documentation (batch number, production date) provided on request
- 12-month warranty on new units; 90-day warranty on refurbished/surplus units
How to Order
- Part Number: CP6606-0001-0020
- Add to cart directly on this page for in-stock units
- For bulk orders (>5 units) or custom configurations, email support@konmask.com
- Lead time: 1–3 business days (stock); 4–8 weeks (factory order)
- Shipping: DHL Express / FedEx International Priority worldwide
- Payment: T/T, PayPal, credit card (Visa/Mastercard)
Replacement & Compatibility FAQ
Q: Can the CP6606-0001-0020 replace an older CP6606-0000-0020?
A: Yes. The -0001- suffix denotes the second hardware revision with improved EMC performance. It is backward-compatible with all TwinCAT 2/3 projects.
Q: Is TwinCAT 3 pre-installed?
A: The unit ships with Windows Embedded Standard 7. TwinCAT 3 runtime must be licensed and installed separately (TC1000 or TC1200 license required).
Q: Can I use a third-party CFast card as a replacement?
A: Beckhoff recommends industrial-grade CFast cards (SLC NAND). Consumer-grade cards may cause instability. Konmask supplies validated replacement CFast cards.
Q: What is the difference between CP6606-0001-0020 and CP6606-0001-0000?
A: The last four digits denote the CFast card size. -0020 = 8 GB; -0000 = no CFast included. Functionally identical otherwise.
Q: Is this unit compatible with EtherCAT terminals from other vendors?
A: Yes, provided the third-party terminals are EtherCAT conformance-tested (ETG certified). Beckhoff EL-series terminals are natively supported.
