Bently Nevada 125840-01 — High Voltage AC Power Supply Module | 3500 Series Platform
Engineering Background
The Bently Nevada 3500 Series is the industry-standard machinery protection platform deployed across turbines, compressors, pumps, and rotating equipment in oil & gas, power generation, and petrochemical facilities worldwide. The 125840-01 is the dedicated High Voltage AC Power Supply module that provides conditioned, isolated power to the 3500 rack system, ensuring uninterrupted protection monitoring even in harsh industrial environments.
Product Positioning
Designed for mission-critical applications where power reliability directly impacts plant safety and uptime, the 125840-01 delivers stable, regulated power to all modules within the 3500 rack. It is the backbone of the entire monitoring system — a single point of quality that cannot be compromised. Konmask.com supplies this module as verified OEM hardware, sourced through authorized industrial channels, with full traceability documentation available on request.
Complete Technical Specifications
| Part Number | 125840-01 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Series / Platform | 3500 Machinery Protection System |
| Module Type | High Voltage AC Power Supply |
| Input Voltage | 85–264 VAC, 47–63 Hz (universal input) |
| Output Voltage | +5 VDC, ±15 VDC, +24 VDC (rack bus) |
| Power Rating | Sufficient for full 3500 rack population |
| Isolation | Input-to-output galvanic isolation |
| Form Factor | 3500 Series rack-mount module (single slot) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5–95% RH, non-condensing |
| Weight | ~300 g |
| Certifications | CE, UL (per 3500 platform compliance) |
| Condition Available | New OEM / Refurbished / Tested Surplus |
Proven Application Environments
- Oil & Gas: Upstream compressor trains, gas turbine protection racks, offshore platform monitoring systems
- Power Generation: Steam turbine and generator vibration monitoring racks in utility plants
- Petrochemical: Reactor feed pump protection, critical rotating equipment in refinery environments
- LNG / Pipeline: High-availability monitoring racks requiring redundant or replacement power modules
- Marine & Industrial: Shipboard machinery protection and heavy industrial rotating equipment
Engineering Advantages
- Universal AC Input: Accepts 85–264 VAC across global grid standards — no transformer or tap adjustment required
- Galvanic Isolation: Eliminates ground loops and protects sensitive monitoring electronics from power-line transients
- Hot-Swap Compatible: Designed for in-rack replacement without full system shutdown (verify with site safety procedures)
- Regulated Multi-Rail Output: Supplies all required voltage rails to the 3500 rack backplane simultaneously
- Proven MTBF: Bently Nevada 3500 platform components are rated for continuous industrial duty with documented field reliability
- Direct OEM Replacement: Drop-in replacement for existing 125840-01 installations — no firmware or configuration changes required
System Architecture & Signal Flow
The 125840-01 installs in the dedicated power supply slot of the Bently Nevada 3500 rack chassis. AC mains input is received at the rear terminal block, passed through EMI filtering and inrush limiting, then converted via an isolated switching topology to the regulated DC rails distributed across the rack backplane. All monitoring modules (I/O, communication, display) draw power from this common bus. A status LED and relay output provide local and remote power-fault indication to the plant DCS or safety system.
Recommended pairing: 125840-01 is typically used alongside a redundant power supply (125840-02 or equivalent) in high-availability configurations to achieve 2N power redundancy.
Sourcing & Quality Verification
- All units inspected for physical integrity, label authenticity, and connector condition prior to dispatch
- Functional test records available for refurbished/surplus units upon request
- Serial number and date code documentation provided with shipment
- Packaging: anti-static bag + foam-lined carton, compliant with IEC 61340-5-1 ESD protection standards
- Counterfeit-prevention: Konmask.com sources exclusively from traceable industrial channels — no grey-market or unverified brokers
Procurement Process
- Confirm part number: Verify 125840-01 against your 3500 rack BOM or existing module label
- Specify condition: New OEM, certified refurbished, or tested surplus — contact us for availability and lead time
- Request quotation: Email support@konmask.com with quantity, required delivery date, and destination port
- Order confirmation: Purchase order accepted via email; proforma invoice issued within 1 business day
- Shipping: DHL / FedEx / UPS express available; sea freight for bulk orders; export documentation (CO, packing list, commercial invoice) included
- After-sales: 12-month warranty on new OEM units; 6-month warranty on refurbished units
Technical FAQ
Q: Is 125840-01 compatible with all 3500 rack chassis versions?
A: Yes. The 125840-01 is the standard high-voltage AC power supply for the 3500 Series rack and is backward-compatible across all chassis revisions. Confirm slot assignment with your rack documentation.
Q: Can this module operate on 110 VAC (North American) and 220 VAC (European/Asian) grids?
A: Yes. The universal input range (85–264 VAC) covers both standards without any hardware modification.
Q: What is the difference between 125840-01 and 125840-02?
A: The -02 variant is typically the redundant/secondary power supply used in dual-PSU configurations. The -01 is the primary module. Both are electrically equivalent; the slot designation in the rack determines primary vs. redundant role.
Q: Do you provide export licenses for shipment to restricted countries?
A: Konmask.com complies with all applicable export control regulations. Please declare your end-use country at time of inquiry so we can confirm export eligibility.
Q: What documentation is included with the shipment?
A: Commercial invoice, packing list, certificate of origin, and (for refurbished units) functional test report. Calibration certificates are not applicable for power supply modules.
