BENTLY NEVADA 129478-01 – High Power DC Input Module | 3500 Series Machinery Protection Platform
Engineering Background
The BENTLY NEVADA 3500 Series is the industry benchmark for continuous online machinery protection in rotating equipment applications. Deployed across power generation, oil & gas, petrochemical, and heavy industrial facilities worldwide, the 3500 rack-based architecture provides real-time vibration, position, and dynamic measurement with deterministic response times critical to turbine, compressor, and pump protection.
Product Positioning
The 129478-01 is the High Power DC Input Module within the 3500 platform. It serves as the primary interface for high-power DC transducer signals entering the protection rack, conditioning raw field signals before routing to monitor modules. Procurement engineers specifying replacement or expansion modules for existing 3500 installations will find this module a direct, verified drop-in solution.
Complete Technical Specifications
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 129478-01 |
| Module Type | High Power DC Input Module |
| Platform | 3500 Series Machinery Protection System |
| Form Factor | 3500 Rack-Mount Card |
| Signal Type | High Power DC Input |
| Power Supply | DC (rack-supplied via 3500 backplane) |
| Weight | 450 g (approx.) |
| Condition | Surplus / Refurbished – Full QC Inspected |
| Warranty | 12 Months Konmask Quality Guarantee |
| Compliance | Compatible with 3500/01, 3500/05, 3500/15, 3500/20, 3500/22, 3500/25, 3500/32, 3500/40, 3500/42, 3500/44, 3500/45, 3500/50, 3500/60, 3500/61, 3500/62, 3500/64, 3500/72, 3500/77 monitor modules |
Proven Application Environments
- Power Generation: Steam turbine and gas turbine protection racks requiring high-power DC signal conditioning
- Oil & Gas: Upstream and downstream compressor trains, pipeline booster stations
- Petrochemical & Refining: Critical rotating machinery protection in continuous-process environments
- Marine & Offshore: Platform machinery monitoring systems with 3500 rack infrastructure
- Pulp & Paper / Mining: High-availability production machinery requiring certified protection modules
Engineering Advantages
- Direct OEM Replacement: 129478-01 is a genuine Bently Nevada part — no firmware reconfiguration required for like-for-like swap
- High-Power DC Conditioning: Handles elevated DC transducer drive levels that standard input modules cannot support, reducing signal degradation in long cable runs
- Rack Compatibility: Fully backward-compatible with all 3500 rack generations; plug-and-play insertion with no rack modification
- Deterministic Response: Maintains the sub-millisecond signal latency required for API 670 machinery protection compliance
- Reduced Downtime Risk: Stocking a verified spare eliminates extended lead times from OEM channels during unplanned outages
System Architecture & Signal Flow
Within the 3500 rack, the 129478-01 occupies an input slot and interfaces directly with field-mounted transducers (proximity probes, accelerometers, or velocity sensors operating at high DC drive levels). The module conditions and buffers the raw signal, passing a clean analog representation to the adjacent monitor module via the 3500 backplane. The monitor module then applies alarm setpoints, gap voltage checks, and OK relay logic. This two-stage architecture isolates field wiring from sensitive measurement circuitry, improving noise immunity and simplifying field maintenance.
Sourcing & Quality Verification
- Source Traceability: All units sourced from decommissioned OEM-maintained installations or authorized surplus channels
- Incoming Inspection: Visual inspection, board-level cleaning, connector integrity check, and functional power-on verification
- Serialization: Original Bently Nevada serial number and revision label preserved and documented
- Packaging: ESD-safe anti-static bag, foam-lined carton, humidity indicator card
- Documentation: Certificate of conformance and inspection report available on request
Procurement Process
- Confirm Compatibility: Verify your 3500 rack slot type and existing module revision against your system drawing
- Request Quote: Contact support@konmask.com with your PO number, required quantity, and delivery timeline
- Order Confirmation: Receive proforma invoice with lead time, shipping method, and Incoterms
- QC Release: Unit re-inspected and photographed prior to dispatch; inspection report emailed with tracking
- Delivery: DHL / FedEx / SF Express — typical transit 3–7 business days internationally
- After-Sales: 12-month warranty; DOA replacement within 5 business days of confirmed fault report
Technical FAQ
Q: Is the 129478-01 compatible with both 3500/01 and 3500/05 power supplies?
A: Yes. The module draws power from the 3500 backplane and is compatible with all standard 3500 rack power supply configurations.
Q: Can this module be used with Keyphasor signals?
A: The 129478-01 is a DC input module; Keyphasor inputs use dedicated Keyphasor modules (e.g., 3500/25). Consult your system I/O list before ordering.
Q: Do you provide a Bently Nevada System 1 configuration file?
A: Configuration files are rack- and application-specific. We supply the hardware; your site engineer or Bently Nevada service team will apply the configuration from your existing backup.
Q: What is the lead time for multiple units?
A: Stock availability is confirmed at time of inquiry. For quantities >3 units, contact us for a dedicated sourcing timeline.
Q: Is export documentation available for cross-border shipments?
A: Yes — commercial invoice, packing list, and certificate of origin are provided as standard. ECCN classification available on request.
