Bently Nevada 170180-01-05 Relay Output Board | Replacement, Equivalent & Selection Guide
The Bently Nevada 170180-01-05 is a Relay Output Board designed for use within the Bently Nevada 3500 Series machinery protection system. It provides relay-based alarm and trip outputs for critical rotating machinery monitoring applications. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams.
Technical Specifications
- Part Number / SKU: 170180-01-05
- Manufacturer: Bently Nevada (Baker Hughes)
- Series: 3500 Machinery Protection System
- Module Type: Relay Output Board
- Output Type: Relay (dry contact)
- Form Factor: Rack-mount module card
- Weight: 280 g (approx.)
- Application: Vibration monitoring, machinery protection, alarm/trip relay output
- Compatibility: Bently Nevada 3500 Series rack system
Compatible Replacement & Equivalent Models
The following models may serve as direct or functional replacements for the 170180-01-05 depending on your system configuration. Always verify firmware and rack compatibility before substitution:
- 170180-01-01 – Earlier revision of the same relay output board series
- 170180-01-02 – Intermediate revision; functionally equivalent in most 3500 rack configurations
- 170180-01-03 – Compatible relay output board, minor hardware revision
- 170180-01-04 – Predecessor revision; verify relay contact ratings before use
- 3500/32 – 4-Channel Relay Output Module (alternative relay output solution within 3500 system)
- 3500/33 – 16-Channel Relay Output Module (expanded relay capacity alternative)
Note: Revision suffix (-05) indicates a specific hardware revision. Confirm compatibility with your 3500 rack firmware version before ordering a different revision.
Why Choose the Original Model
- Factory-certified hardware revision ensuring full compatibility with 3500 Series racks
- Validated relay contact ratings and timing characteristics for machinery protection
- Traceable manufacturing documentation for safety-critical installations
- Supported by Bently Nevada / Baker Hughes technical service and calibration
- Preferred for SIL-rated and API 670-compliant installations
Typical Applications
- Steam turbine and gas turbine protection systems
- Compressor and pump vibration alarm/trip relay outputs
- Rotating machinery health monitoring in oil & gas, power generation, and petrochemical plants
- Integration with DCS/SCADA systems via relay dry contacts
- Critical machinery protection panels requiring certified relay output modules
System Compatibility
- Primary System: Bently Nevada 3500 Series Machinery Protection Rack
- Rack Slots: Compatible with standard 3500 I/O module slots
- Communication: Relay dry contact output; integrates with external PLC/DCS alarm inputs
- Power Supply: Powered via 3500 rack backplane
- Standards: Designed for API 670 machinery protection applications
Selection Guide
Use the following criteria to confirm the correct relay output board for your application:
- Step 1 – Identify your rack: Confirm you have a Bently Nevada 3500 Series rack (not 3300 or 1900 series).
- Step 2 – Check relay channel count: 170180-01-05 provides standard relay outputs; for expanded channels consider 3500/33.
- Step 3 – Verify revision compatibility: Check your rack firmware documentation for supported relay board revisions.
- Step 4 – Confirm contact ratings: Match relay contact voltage/current ratings to your alarm/trip circuit requirements.
- Step 5 – Compliance requirements: For SIL or API 670 installations, use only the specified original part number and revision.
Quality Assurance & Sourcing
- All units sourced from verified industrial automation supply channels
- Pre-shipment functional inspection available on request
- Original manufacturer packaging preserved where available
- Traceability documentation provided for critical installations
- Konmask.com specializes in industrial automation components for B2B procurement
How to Order
- Online: Add to cart directly on this page
- Email: support@konmask.com with your PO or RFQ
- Phone/WhatsApp: +0086 19859288691
- Lead Time: Contact us for current stock status and lead time
- Bulk / OEM Orders: Volume pricing available — contact us for a quote
Replacement & Compatibility FAQ
Q: Can I use a different revision (e.g., -01-03) instead of -01-05?
A: In many cases yes, but you must verify compatibility with your specific 3500 rack firmware version. Contact us or refer to Bently Nevada’s revision compatibility matrix.
Q: Is the 170180-01-05 compatible with the 3300 Series rack?
A: No. The 170180 series relay output boards are designed exclusively for the 3500 Series rack system.
Q: Do you offer repair or exchange services?
A: Yes. Contact support@konmask.com to discuss repair, exchange, or refurbished unit options.
Q: What is the warranty on this module?
A: Please contact us for warranty terms applicable to your order.
Q: Can this board be used as a direct drop-in replacement?
A: The -05 revision is a direct replacement for the same revision. Cross-revision substitution requires engineering verification.
