BENTLY NEVADA 330101-00-08-20-02-05 Extension Cable | 3300 Series Proximity System
Engineering Background
The Bently Nevada 3300 Series is the industry benchmark for continuous vibration monitoring in rotating machinery — turbines, compressors, pumps, and motors operating in critical process environments. The extension cable is the precision signal-transmission link between the proximity probe and the proximitor/driver, forming the third leg of the three-component eddy-current sensing chain. Signal integrity across this cable directly determines measurement accuracy, alarm reliability, and machinery protection system performance.
Product Positioning
The 330101-00-08-20-02-05 is an OEM-specified extension cable engineered for the Bently Nevada 3300 Series proximity transducer system. It is designed for procurement engineers and reliability teams who require drop-in replacement parts with full system compatibility — no recalibration, no signal offset correction, no compromise on SIL-rated protection loops.
Complete Technical Specifications
| Part Number | 330101-00-08-20-02-05 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Series | 3300 Proximity Transducer System |
| Component Type | Extension Cable |
| Cable Length | 8 m (26.2 ft) |
| Construction | Shielded coaxial |
| Connector Type | BNC / MIL-spec per 3300 system standard |
| Temperature Range | -55 °C to +125 °C (-67 °F to +257 °F) |
| Impedance | Matched to 3300 Series system (nominally 50 Ohm) |
| Compatibility | 3300 XL 8 mm, 3300 5 mm, 3300 NSv Proximity Systems |
| Approvals | CE, ATEX, IECEx |
| Weight | ~100 g |
| Country of Origin | USA |
Proven Application Environments
- Gas & Steam Turbines — shaft radial vibration and axial position monitoring in power generation
- Centrifugal Compressors — continuous rotor dynamic surveillance in oil & gas processing
- Pumps & Fans — bearing condition monitoring in petrochemical and water treatment plants
- Electric Motors — high-speed rotor eccentricity detection in critical drive trains
- Marine & Offshore — vibration monitoring in classified hazardous area installations
- Nuclear & Power Utilities — safety-instrumented system (SIS) loops requiring certified components
Engineering Advantages
- Zero Recalibration Required — OEM-matched cable capacitance and impedance preserve factory system calibration
- EMI/RFI Immunity — double-shielded coaxial construction rejects electrical noise in VFD-dense environments
- Mechanical Durability — flexible armored jacket rated for continuous flexing, vibration, and chemical exposure
- Drop-In Replacement — identical connector geometry and cable parameters; no system modification required
- Hazardous Area Rated — ATEX/IECEx certified for Zone 1/Zone 2 classified installations
- Wide Temperature Tolerance — qualified from cryogenic to high-temperature process environments
System Architecture & Signal Flow
The 3300 Series proximity transducer system operates as a three-component eddy-current chain:
- Proximity Probe (e.g., 330103 / 330104 series) — generates the high-frequency electromagnetic field at the shaft surface
- Extension Cable 330101-00-08-20-02-05 — transmits the raw oscillator signal from probe tip to proximitor with minimal loss and zero impedance mismatch
- Proximitor / Driver (e.g., 3300 XL proximitor) — conditions the signal and outputs a calibrated -24 VDC linear DC voltage proportional to gap distance
The output signal feeds directly into Bently Nevada 3500 Series rack monitors or equivalent machinery protection systems for alarm, trip, and trending functions.
Sourcing & Quality Verification
- All units sourced from authorized distributors or verified OEM surplus channels
- Each cable inspected for connector integrity, shield continuity, and jacket condition prior to dispatch
- Original manufacturer labeling, date codes, and traceability documentation preserved
- Packaged in anti-static, moisture-barrier materials for long-term storage integrity
- Certificate of Conformance (CoC) available upon request for SIL-loop documentation
Procurement Process
- Confirm Part Number — verify 330101-00-08-20-02-05 matches your system cable length and connector specification
- Request Quote — contact support@konmask.com for volume pricing, lead time, and CoC availability
- Order & Payment — T/T, L/C, and major payment platforms accepted; proforma invoice issued within 24 hours
- Shipping — DHL / FedEx / UPS express worldwide; EXW Xiamen or CIF destination available
- After-Sales — 12-month warranty on OEM parts; technical support from our automation engineering team
Technical FAQ
Q: Can this cable be used with non-Bently Nevada proximitors?
A: Not recommended. The cable is impedance-matched to the 3300 Series system. Use with third-party drivers may introduce calibration errors and void system certification.
Q: What is the maximum cable run for the 3300 Series system?
A: Bently Nevada specifies fixed probe + extension cable combinations. The total system cable length must match the proximitor calibrated range — typically 5 m or 9 m total. Confirm your proximitor calibration range before ordering.
Q: Is this part available with ATEX documentation?
A: Yes. ATEX and IECEx certificates are available upon request. Please specify your installation zone classification when ordering.
Q: Do you offer expedited shipping for shutdown/turnaround situations?
A: Yes. Contact us directly at +0086 19859288691 for emergency procurement support. We maintain stock for critical-path orders.
Q: Can I return the part if it does not match my system?
A: Yes, within 30 days of receipt in original, unused condition. Please verify the part number against your system documentation before ordering.
