Bently Nevada 330103-00-09-10-02-CN Proximity Transducer System – 3300 XL Series
When a critical rotating machine loses its vibration monitoring capability, the consequences are immediate and severe: undetected shaft displacement, catastrophic bearing failure, unplanned downtime, and in worst cases, irreversible damage to turbines, compressors, or pumps worth millions of dollars. The Bently Nevada 330103-00-09-10-02-CN Proximity Transducer System is the precision sensing component that stands between normal operation and disaster — continuously measuring radial shaft vibration and position with micron-level accuracy, 24 hours a day, 365 days a year.
Within the Bently Nevada 3300 XL Series — the industry’s most trusted eddy-current proximity transducer platform — the 330103-00-09-10-02-CN occupies a core position as a standard 25 mm (1-inch) probe assembly with a 9-meter (30-foot) extension cable and integral connector. This configuration is the most widely deployed variant in global power generation, oil & gas, and petrochemical facilities, making it a cornerstone of predictive maintenance programs on every continent. Its compatibility with the System 1 condition monitoring software and 3500 Series monitoring racks has cemented its role as the de facto standard for API 670-compliant machinery protection systems worldwide.
Technical Specifications
- Part Number: 330103-00-09-10-02-CN
- Series: Bently Nevada 3300 XL Proximity Transducer System
- Probe Type: Eddy-Current, Non-contacting
- Probe Tip Diameter: 25 mm (1 inch)
- Extension Cable Length: 9 m (30 ft)
- Driver/Oscillator: 3300 XL 8mm Proximitor® Sensor (sold separately)
- Measurement Range: 0.25 mm – 2.25 mm (linear range)
- Scale Factor: 7.87 V/mm (200 mV/mil)
- Frequency Response: DC to 10,000 Hz
- Temperature Range (Probe): -35°C to +177°C (-31°F to +350°F)
- Connector: Integral, CN-type
- Compliance: API 670, CE, ATEX (zone-dependent configuration)
- Target Material: AISI 4140 steel (standard); other materials require scale factor correction
Key Features & Benefits
- Non-contacting measurement: Zero mechanical wear on the probe — designed for continuous, permanent installation on rotating machinery without maintenance intervals.
- Wide frequency response (DC–10 kHz): Captures both slow-roll runout and high-frequency vibration events in a single channel, eliminating the need for multiple sensor types.
- Integral CN connector: Factory-terminated, field-proven connector design minimizes signal loss and simplifies installation in tight machinery housings.
- API 670 compliant: Meets the international standard for machinery protection systems, ensuring acceptance by EPC contractors, insurance auditors, and plant safety authorities globally.
- Plug-and-play with 3500 Series racks: Direct compatibility with Bently Nevada 3500/40M, 3500/42M, and 3500/46M monitor modules — no signal conditioning adapters required.
- Proven global installed base: Millions of units deployed in LNG trains, steam turbines, gas compressors, and hydro generators across 6 continents.
Industry & Equipment Applications
- Oil & Gas: Centrifugal compressors, gas turbines, pipeline pumping stations, LNG liquefaction trains
- Power Generation: Steam turbines, gas turbines, hydro generators, boiler feed pumps
- Petrochemical & Refining: Reactor charge pumps, cracked gas compressors, ethylene plant rotating equipment
- Pulp & Paper / Mining: Large induced draft fans, ball mills, kiln drives
- Marine & Offshore: Propulsion turbines, offshore platform compressor trains
System Integration & Compatible Parts
The 330103-00-09-10-02-CN is designed to operate as part of a complete Bently Nevada proximity transducer system. Typical compatible components include:
- Proximitor® Sensor: 330180-X1-05 / 330180-X1-CN (3300 XL 8mm driver)
- Monitor Modules: 3500/40M, 3500/42M, 3500/46M (radial vibration monitors)
- Rack: 3500/05 Rack Interface Module
- Software: System 1 Evolution condition monitoring platform
- Related Probes: 330103-00-09-10-01-CN (5 m cable), 330103-00-09-10-03-CN (14 m cable)
Contact Konmask.com to verify compatibility with your existing rack configuration before ordering.
Our Quality Assurance Process
- Source verification: All units are sourced from authorized distributors or decommissioned OEM installations with full traceability documentation.
- Visual & dimensional inspection: Probe tip, cable jacket, and connector are inspected for physical damage, corrosion, and dimensional conformance.
- Electrical continuity test: Coil resistance and cable continuity verified against OEM specifications prior to shipment.
- Packaging: Anti-static foam packaging with desiccant; probe tip protected by OEM-style plastic cap.
- Documentation: Certificate of conformance and inspection report included with every shipment.
How to Order
- Submit an inquiry via the Contact Us form on Konmask.com with your required quantity and delivery timeline.
- Our technical team will confirm part availability, lead time, and provide a formal quotation within 24 business hours.
- Upon PO confirmation, we arrange secure packaging and international freight (DHL / FedEx / sea freight) to your facility.
- Tracking information and shipping documents (commercial invoice, packing list, COC) are provided upon dispatch.
Why Choose Konmask.com?
- ✅ Industrial automation specialists — focused exclusively on PLC, DCS, and condition monitoring components from leading OEM brands.
- ✅ Global B2B supply — serving engineering firms, EPC contractors, and plant maintenance teams in 40+ countries.
- ✅ Technical pre-sales support — our engineers can assist with cross-referencing, compatibility checks, and system configuration advice.
- ✅ Competitive lead times — extensive network of verified suppliers enables fast sourcing for both standard and obsolete part numbers.
- ✅ Transparent documentation — every shipment includes full traceability and inspection records.
Frequently Asked Questions
- Q: What is the difference between 330103-00-09-10-02-CN and 330103-00-09-10-01-CN?
- A: The primary difference is cable length. The -02-CN variant includes a 9-meter (30 ft) extension cable, while the -01-CN includes a 5-meter (16 ft) cable. All other electrical specifications are identical.
- Q: Can this probe be used with a 3300 NSv Proximitor® Sensor?
- A: The 330103 probe series is optimized for use with the 3300 XL 8mm Proximitor® Sensor. Compatibility with NSv drivers should be verified with Bently Nevada or Konmask technical support before installation.
- Q: Is the 330103-00-09-10-02-CN suitable for ATEX Zone 1 hazardous areas?
- A: ATEX suitability depends on the complete system configuration including the Proximitor® Sensor and associated barriers. Please provide your hazardous area classification when submitting your inquiry so we can confirm the correct certified assembly.
- Q: Do you supply new or refurbished units?
- A: We supply both new-in-box (NIB) and inspected serviceable units depending on availability. Condition is clearly stated in the quotation. All units pass our QA inspection process regardless of condition grade.
- Q: What is the typical lead time?
- A: Standard lead time is 3–10 business days for in-stock units. For sourced items, lead time is typically 2–4 weeks. Expedited options are available — please indicate urgency in your inquiry.
