Vibration Monitoring Solution – Bently Nevada 330104-13-20-10-02-05 | 3300 XL NSv Series
Where This Product Is Used
The Bently Nevada 330104-13-20-10-02-05 Proximity Transducer System is engineered for continuous, non-contact vibration and position measurement in rotating machinery. Typical deployment environments include:
- Steam & Gas Turbines – Shaft radial vibration and axial position monitoring in power generation plants
- Centrifugal & Axial Compressors – Real-time rotor dynamics surveillance in petrochemical and LNG facilities
- Pumps & Fans – Bearing journal orbit analysis in water treatment and HVAC systems
- Gearboxes – Gear mesh frequency detection and differential expansion measurement
- Marine Propulsion Systems – Shaft monitoring in offshore platforms and vessels
Technical Specifications
| Part Number | 330104-13-20-10-02-05 |
| Series | 3300 XL NSv (Non-Standard Voltage) |
| Probe Cable Length | 13 in (330 mm) |
| Extension Cable Length | 20 ft (6.1 m) |
| Driver | 3300 XL 8mm Proximitor® Sensor |
| Measurement Range | 0 – 80 mil (0 – 2.03 mm) |
| Output Sensitivity | 200 mV/mil (7.87 V/mm) |
| Supply Voltage | -24 VDC (NSv variant) |
| Target Material | AISI 4140 steel (standard) |
| Operating Temperature | -35°C to +177°C (probe tip) |
| Connector Type | Armor-jacketed coaxial, integral |
| Approvals | FM, CSA, ATEX, IECEx |
| Weight | 300 g (approx.) |
Why Engineers Specify This Model
- NSv Non-Standard Voltage – Designed for legacy Bently Nevada systems requiring -24 VDC supply, ensuring backward compatibility without rewiring
- Pre-matched System – Probe, extension cable, and Proximitor® driver are factory-calibrated as a matched set, eliminating field calibration errors
- High-Temperature Probe Tip – Rated to 177°C, suitable for hot-section turbine bearing pedestals
- API 670 Compliant – Meets the industry standard for machinery protection systems in oil & gas
- Drop-in Replacement – Direct substitute for existing 3300 XL installations; no software reconfiguration required
Complete System Bill of Materials
This listing covers the complete proximity transducer system. For a full protection loop, engineers typically also specify:
- Bently Nevada 3500/42M Proximitor® Monitor (rack-mount I/O module)
- Bently Nevada 3500/20 Rack Power Supply
- Bently Nevada 3500/22M Transient Data Interface
- System 1® Condition Monitoring Software (GE Vernova)
- Armored conduit fittings and junction box (customer-supplied)
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition)
- IEC 61511 – Functional Safety for Process Industry
- ATEX Directive 2014/34/EU – Zone 1 & Zone 2 hazardous area use
- IECEx IEC 60079 – International explosive atmosphere certification
- FM & CSA – North American hazardous location approvals
- RoHS Compliant – Restriction of Hazardous Substances
Quality Assurance & Sourcing
Konmask.com sources the Bently Nevada 330104-13-20-10-02-05 through verified industrial automation distributors and authorized surplus channels. Every unit undergoes:
- Visual inspection for connector integrity and cable jacket condition
- Continuity and impedance verification against OEM specifications
- Serialization check and documentation review
- Anti-static packaging with humidity indicator card
Traceability documentation and test records are available upon request for critical installations.
How to Source This Part
Ready to order or need a formal quotation? Contact our industrial parts team:
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 1–3 business days; ex-stock global delivery available
- MOQ: 1 piece
- Payment: T/T, PayPal, credit card accepted
Application-Specific FAQ
Q: Can the 330104-13-20-10-02-05 replace a standard -24 VDC 3300 XL probe system?
A: Yes. The NSv designation indicates Non-Standard Voltage (-24 VDC), which is the same supply used in standard 3300 XL racks. It is a direct replacement.
Q: What shaft materials are compatible?
A: The system is calibrated for AISI 4140 steel. For other alloys (Inconel, titanium, stainless), a material correction factor must be applied per Bently Nevada calibration procedures.
Q: Is this system compatible with System 1® software?
A: Yes. The 3300 XL NSv Proximitor® output is fully compatible with GE Vernova System 1® condition monitoring and machinery management software.
Q: Can I use this probe in a Zone 1 hazardous area?
A: Yes, provided the complete installation complies with ATEX/IECEx entity parameters and the associated Proximitor® sensor is also rated for the hazardous zone.
Q: Do you provide a certificate of conformance?
A: Yes. A certificate of conformance (CoC) is available upon request at no additional charge.
