Bently Nevada 330880-16-00-060-03-02 PROXPAC XL Proximity Transducer | 3300 Series Eddy-Current Sensing Platform
Engineering Background: The Bently Nevada 3300 Series has been the industry benchmark for non-contact vibration and position measurement in rotating machinery since its introduction. The PROXPAC XL package integrates the probe, extension cable, and proximitor into a single pre-calibrated assembly, eliminating field calibration errors and reducing installation time by up to 60% compared to discrete component configurations.
Product Positioning: Part number 330880-16-00-060-03-02 is a factory-configured PROXPAC XL assembly designed for critical machinery protection and condition monitoring applications. It is fully compatible with Bently Nevada 3300 Series monitoring systems and System 1 software, making it the preferred choice for procurement engineers specifying turnkey vibration monitoring solutions in power generation, oil & gas, and petrochemical industries.
Complete Technical Specifications
- Part Number: 330880-16-00-060-03-02
- Series / Platform: Bently Nevada 3300 PROXPAC XL
- Sensing Technology: Eddy-current (non-contact)
- Probe Tip Diameter: 16 mm (as encoded in part number)
- Extension Cable Length: 5 m (standard configuration)
- Proximitor Supply Voltage: –24 VDC (nominal)
- Output Signal: –2 VDC to –18 VDC linear range
- Scale Factor: 200 mV/mil (7.87 V/mm)
- Frequency Response: 0 Hz (DC) to 10 kHz (–3 dB)
- Linear Range: 0.25 mm to 2.25 mm (10 mil to 90 mil)
- Target Material: AISI 4140 steel (standard); other alloys available
- Operating Temperature: –35 °C to +177 °C (probe); –35 °C to +85 °C (proximitor)
- Ingress Protection: IP67 (probe assembly)
- Connector Type: 3-pin MIL-C-5015 (proximitor output)
- Agency Approvals: CE, FM, CSA, ATEX (consult factory for specific certifications)
- Weight: Approx. 1.0 kg (complete assembly)
- Language / Documentation: English
Proven Application Environments
- Steam and gas turbine shaft radial vibration monitoring
- Compressor rotor position and thrust measurement
- Pump and motor bearing displacement monitoring
- Gearbox eccentricity and gear mesh analysis
- Expander and blower critical speed detection
- API 670 compliant machinery protection systems
- Offshore platform and FPSO rotating equipment
Engineering Advantages
- Pre-calibrated assembly: Factory-matched probe, cable, and proximitor eliminate field calibration; plug-and-play installation.
- Wide temperature range: Probe rated to +177 °C for high-temperature turbine environments without derating.
- High EMI immunity: Differential output design rejects common-mode electrical noise in industrial environments.
- API 670 compliance: Meets the most stringent machinery protection standard for critical rotating equipment.
- System 1 integration: Native compatibility with Bently Nevada System 1 condition monitoring software for predictive maintenance workflows.
- Long service life: No moving parts; MTBF exceeds 200,000 hours in typical installations.
System Architecture & Signal Flow
The PROXPAC XL operates on the eddy-current principle. The probe tip generates a high-frequency electromagnetic field (typically 1 MHz). When a conductive target enters the field, eddy currents are induced, loading the oscillator circuit. The proximitor electronics convert this impedance change into a linear DC voltage output proportional to the gap between probe tip and target surface. The signal is then routed to a Bently Nevada 3300 Series monitor card (e.g., 3300/16, 3300/20) for alarm processing, trending, and System 1 data acquisition.
Signal path: Probe tip → Extension cable (5 m) → Proximitor oscillator/demodulator → –2 to –18 VDC output → Monitor input card → System 1 / DCS/PLC integration.
Sourcing & Quality Verification
- All units sourced from authorized Bently Nevada distribution channels or verified surplus with full traceability documentation.
- Each assembly inspected for physical integrity, connector condition, and cable continuity prior to shipment.
- Calibration certificates and original factory documentation available upon request.
- Serialized units can be cross-referenced against Bently Nevada factory records for authenticity verification.
- Konmask.com maintains a strict no-counterfeit policy; all parts are subject to incoming quality inspection (IQC).
Procurement Process
- Step 1: Confirm part number 330880-16-00-060-03-02 matches your system’s existing probe/proximitor configuration.
- Step 2: Verify target material compatibility (standard: AISI 4140 steel).
- Step 3: Add to cart and complete checkout, or contact us for bulk pricing and lead-time confirmation.
- Step 4: Receive factory-packed unit with inspection report; install per Bently Nevada TDI-8478 installation guide.
- Lead Time: In-stock units ship within 1–3 business days; EXW Xiamen, China.
- Payment: T/T, PayPal, credit card, and trade finance options available for qualified buyers.
Technical FAQ
- Q: Is 330880-16-00-060-03-02 compatible with the 3300/16 monitor?
- A: Yes. The PROXPAC XL 330880 series is designed for direct connection to all Bently Nevada 3300 Series monitor cards including the 3300/16, 3300/20, and 3300/25.
- Q: Can this transducer be used with non-steel targets?
- A: The standard calibration is for AISI 4140 steel. For other alloys (Inconel, titanium, aluminum), a target material correction factor must be applied. Contact our engineering team for recalibration options.
- Q: What is the difference between PROXPAC and PROXPAC XL?
- A: PROXPAC XL features an extended linear range and improved high-temperature performance compared to the standard PROXPAC, making it suitable for more demanding turbomachinery applications.
- Q: Do you provide a warranty?
- A: Yes. Konmask.com provides a 12-month warranty against manufacturing defects on all new units. Refurbished units carry a 6-month warranty.
- Q: Can I get a datasheet or calibration certificate?
- A: Yes. Email [email protected] with your order number or inquiry reference and we will provide the relevant documentation within 24 hours.
