Vibration Monitoring Solution – Bently Nevada 330901-04-35-50-01-00 | 3300 XL NSv Series
Where This Product Is Used
The Bently Nevada 330901-04-35-50-01-00 Proximity Transducer System is engineered for continuous, non-contact vibration and position measurement in rotating machinery. Typical deployment environments include:
- Steam & Gas Turbines — shaft radial vibration monitoring per API 670
- Centrifugal & Axial Compressors — rotor dynamic displacement measurement in petrochemical plants
- Pumps & Fans — bearing journal orbit analysis in power generation facilities
- Gearboxes — gear mesh frequency and shaft position tracking
- Marine Propulsion Systems — continuous shaft monitoring in offshore platforms
- Paper & Steel Mills — roll and drive shaft eccentricity detection
Technical Specifications
- Part Number: 330901-04-35-50-01-00
- Series: 3300 XL NSv (Non-Standard voltage)
- Probe Cable Length: 4 ft (1.2 m) integral cable
- Extension Cable Length: 35 ft (10.7 m)
- Driver Cable Length: 50 ft (15.2 m)
- Probe Tip Diameter: 8 mm
- Measurement Range: 0–90 mil pp (0–2.286 mm pp)
- Sensitivity: 200 mV/mil (7.87 V/mm)
- Supply Voltage: –24 VDC (NSv variant)
- Output: –1 VDC to –17 VDC (linear range)
- Frequency Response: DC to 10,000 Hz (–3 dB)
- Temperature Range: –35°C to +177°C (probe); –35°C to +85°C (driver)
- Target Material: AISI 4140 steel (standard); other alloys available
- Approvals: CE, FM, CSA, ATEX (Zone 1/2)
Why Engineers Specify This Model
- NSv Supply Compatibility — operates on –24 VDC systems without external regulators, reducing BOM cost
- Extended Cable Configuration — 35 ft extension + 50 ft driver cable suits large turbine pedestals and remote junction boxes
- API 670 Compliant — drop-in replacement for existing 3300 XL installations without recalibration
- Hazardous Area Rated — ATEX/FM certified for Zone 1 environments in refineries and offshore platforms
- High-Temperature Probe — rated to 177°C, suitable for hot-section turbine bearing housings
- Plug-and-Play with 3500 Rack — direct interface to Bently Nevada 3500 Series monitoring system
Complete System Bill of Materials
A fully functional proximity transducer loop using this part number typically includes:
- 330901-04-35-50-01-00 — Proximity Transducer System (probe + extension + driver, this item)
- Bently Nevada 3500/40M or 3500/42M — Proximitor I/O Module
- Bently Nevada 3500/20 — Power Supply Module
- Bently Nevada 3500/22 — Transient Data Interface (optional)
- Bently Nevada 3500/01 — Rack Interface Module
- Armored conduit / cable tray — field installation hardware
- Target ring (AISI 4140) — if not already installed on shaft
Compliance & Industry Standards
- API 670 — Machinery Protection Systems (5th Edition)
- IEC 61511 — Functional Safety for Process Industry
- ATEX Directive 2014/34/EU — Zone 1, Group IIC, T4
- FM Approved — Class I, Division 1, Groups A–D
- CSA Certified — Class I, Division 1
- CE Marked — EMC Directive 2014/30/EU
- RoHS Compliant — Directive 2011/65/EU
Quality Assurance & Sourcing
Every 330901-04-35-50-01-00 unit shipped by Konmask.com undergoes the following verification process:
- Visual inspection against OEM dimensional drawings
- Functional gap voltage test at –24 VDC supply
- Sensitivity verification: 200 ± 10 mV/mil across full linear range
- Serialization check against Bently Nevada factory records where available
- Anti-static packaging with humidity indicator card
- Certificate of conformance (CoC) included with every shipment
Units are sourced from authorized distributors, OEM surplus, and verified industrial decommissions. Condition is clearly stated on each listing (New / Refurbished / Tested Used).
How to Source This Part
- In-Stock Orders: Submit your PO or inquiry via support@konmask.com — same-day quotation for stocked units
- Urgent Shutdown Support: Call +0086 19859288691 for expedited processing and air freight options
- Bulk / Project Procurement: Request a project BOM quote — volume pricing available for EPC contractors and OEMs
- Lead Time: In-stock units ship within 1–3 business days; sourced units 5–15 business days
- Export Compliance: We handle EAR99 classification and commercial invoice documentation for international shipments
Application-Specific FAQ
Q: Is the 330901-04-35-50-01-00 compatible with the Bently Nevada 3500 monitoring rack?
A: Yes. The 3300 XL NSv driver outputs a standard –24 VDC-based signal fully compatible with 3500/40M and 3500/42M Proximitor I/O modules.
Q: What is the difference between the NSv and standard 3300 XL variants?
A: NSv (Non-Standard voltage) models operate from a –24 VDC supply rather than the standard –18 VDC, providing extended linear range and improved noise immunity in high-interference environments.
Q: Can this transducer be used on non-ferrous shafts?
A: The standard calibration targets AISI 4140 steel. For stainless steel, titanium, or Inconel shafts, a material correction factor must be applied. Contact us for application-specific calibration data.
Q: What is the maximum shaft speed this system can monitor?
A: The 3300 XL NSv system has a frequency response of DC to 10,000 Hz, supporting shaft speeds up to 600,000 RPM in theory; practical limits are set by the monitoring system and application.
Q: Do you provide installation and commissioning support?
A: We provide technical documentation, wiring diagrams, and remote commissioning guidance. On-site support can be arranged through our partner network.
