Bently Nevada 330902-00-40-10-02-CN – Non-Contact Proximity Transducer System | 3300 XL NSv Platform
Engineering Background: The Bently Nevada 3300 XL NSv series represents the industry benchmark for non-contacting shaft vibration and position measurement in rotating machinery protection systems. Engineered to meet API 670 requirements, this transducer system delivers sub-micron resolution and exceptional signal stability across demanding industrial environments.
Product Positioning: The 330902-00-40-10-02-CN is a complete proximity transducer system comprising a probe, extension cable, and Proximitor® sensor. It is purpose-built for continuous monitoring of radial vibration, axial position, and differential expansion on critical turbomachinery including steam turbines, gas turbines, compressors, and pumps.
Complete Technical Specifications
- Part Number: 330902-00-40-10-02-CN
- Series / Platform: Bently Nevada 3300 XL NSv (Non-Standard Voltage)
- System Type: Eddy-Current Proximity Transducer System (Probe + Extension Cable + Proximitor)
- Probe Length: 40 mm (standard)
- Cable Length: 10 ft (approx. 3 m) integral cable
- Output Voltage Range: -2 VDC to -18 VDC (NSv configuration)
- Scale Factor: 200 mV/mil (7.87 V/mm) nominal
- Linear Range: 80 mil (2.03 mm) typical
- Frequency Response: DC to 10,000 Hz (–3 dB)
- Operating Temperature: –35°C to +121°C (probe); –35°C to +66°C (Proximitor)
- Supply Voltage: –24 VDC nominal (–20 to –26 VDC)
- Target Material: AISI 4140 steel (standard); compatible with most ferrous alloys
- Connector: CN-type (China regional connector standard)
- Approvals / Compliance: API 670, CE, RoHS
- Weight: ~100 g (probe assembly)
Proven Application Environments
- Steam turbine radial bearing vibration monitoring
- Gas turbine axial thrust position measurement
- Centrifugal compressor shaft differential expansion
- Boiler feed pump and large motor shaft orbit analysis
- Petrochemical, power generation, and LNG plant machinery protection
- Integration with Bently Nevada 3500 Series Machinery Protection Systems
Engineering Advantages
- API 670 Compliant: Meets the most stringent international standard for machinery protection instrumentation.
- NSv Output: Non-Standard Voltage output enables direct compatibility with legacy 3300 Series monitors without signal conditioning.
- High EMI Immunity: Shielded coaxial cable construction minimizes electromagnetic interference in high-noise plant environments.
- Plug-and-Play Replacement: Direct drop-in replacement for existing 3300 XL installations — no recalibration required when replacing like-for-like.
- Extended Temperature Range: Suitable for both cryogenic and high-temperature process environments.
System Architecture & Signal Flow
The 330902-00-40-10-02-CN operates as a three-component eddy-current measurement chain:
- Probe (330902): Generates a high-frequency electromagnetic field. Eddy currents induced in the rotating target shaft attenuate the field proportionally to gap distance.
- Extension Cable: Transmits the oscillator signal between probe and Proximitor with controlled impedance to preserve measurement accuracy over distance.
- Proximitor® Sensor: Demodulates the oscillator signal and outputs a DC voltage linearly proportional to probe-to-target gap. Output feeds directly to the 3500 monitor rack or DCS analog input.
Sourcing & Quality Verification
- All units sourced from authorized distributors or verified OEM-surplus channels.
- Each unit undergoes incoming inspection: visual, dimensional, and functional verification against Bently Nevada factory specifications.
- Serialization and date codes are verified and documented prior to shipment.
- Certificate of Conformance (CoC) available upon request.
- Konmask.com maintains traceability records for all critical automation components.
Procurement Process
- Submit your RFQ via support@konmask.com or WhatsApp +0086 19859288691.
- Receive stock confirmation, lead time, and formal quotation within 24 hours.
- Issue PO — we accept T/T, PayPal, and major trade finance instruments.
- Shipment via DHL / FedEx / UPS with full tracking; export documentation (commercial invoice, packing list, CoC) included.
- Post-delivery technical support available from our automation engineering team.
Technical FAQ
Q: Is the 330902-00-40-10-02-CN compatible with the Bently Nevada 3500/42M monitor?
A: Yes. The NSv output is directly compatible with the 3500/42M Proximitor/Seismic Monitor configured for 3300 XL NSv transducers.
Q: What is the difference between the -CN and standard connector versions?
A: The -CN suffix denotes a China-regional connector configuration. Electrically and mechanically identical to the standard version; only the field connector differs.
Q: Can this transducer be used on non-ferrous targets?
A: The standard calibration is optimized for AISI 4140 steel. For non-ferrous or exotic alloy targets, a target-specific calibration factor must be applied — contact our engineering team for guidance.
Q: Do you provide calibration certificates?
A: Factory calibration data is available for new units. For recertification services, we can coordinate with accredited metrology labs.
