Genuine Bently Nevada 330905-00-05-10-01-00 Proximity Transducer System | 3300 XL Series – Verified Source
The Bently Nevada 330905-00-05-10-01-00 is a complete proximity transducer system from the industry-leading 3300 XL Series, engineered for non-contact, continuous measurement of shaft radial vibration, axial position, and differential expansion in critical rotating machinery. Konmask.com supplies this part through verified channels with full traceability — giving procurement engineers and reliability teams the confidence they need for critical asset protection.
Technical Specifications
- Part Number: 330905-00-05-10-01-00
- Series: Bently Nevada 3300 XL
- Probe Tip Diameter: 5 mm
- Cable / Extension Length: 10 m (integral system)
- Measurement Type: Eddy-current, non-contact
- Linear Range: 0.25 mm – 2.25 mm
- Scale Factor: 7.87 V/mm (200 mV/mil)
- Frequency Response: 0 Hz – 10,000 Hz (–3 dB)
- Probe Operating Temperature: –35°C to +177°C
- Driver Operating Temperature: –35°C to +66°C
- Supply Voltage: –24 VDC (nominal)
- Output Range: –1 VDC to –21 VDC
- Target Material: AISI 4140 steel (reference)
- Agency Approvals: CE, ATEX, FM
- Weight: Approx. 40 g (probe assembly)
Our 4-Step Quality Verification Process
Every 330905-00-05-10-01-00 unit shipped from Konmask.com passes through a rigorous four-stage verification protocol before dispatch:
- Step 1 – Source Authentication: Units are procured exclusively from authorized distributors or certified surplus channels. Supplier credentials and chain-of-custody documents are verified before purchase.
- Step 2 – Physical Inspection: Each unit undergoes visual and dimensional inspection against Bently Nevada factory specifications, including connector integrity, cable condition, and probe tip geometry.
- Step 3 – Documentation Review: Original packaging, serial number traceability, calibration data sheets, and certificates of conformance (CoC) are verified and archived.
- Step 4 – Pre-Shipment Check: Final packaging inspection ensures ESD-safe handling, correct labeling, and inclusion of all documentation before dispatch.
Key Features & Benefits
- Complete System in One Part Number – Probe, extension cable, and driver integrated into a single orderable SKU, simplifying procurement and reducing BOM complexity.
- 10 m Integrated Cable – Extended reach for installations where the monitor rack is located remotely from the bearing pedestal.
- Drop-in 3300 XL Compatibility – Direct replacement for existing 3300 XL installations; no recalibration of monitors required.
- High-Temperature Probe Rating – Rated to +177°C at the probe tip, suitable for hot-section turbine and compressor bearing locations.
- EMI-Resistant Construction – Shielded coaxial cable design rejects electrical noise in VFD-dense and high-interference plant environments.
- API 670 Compliant – Meets the mandatory machinery protection standard for critical rotating equipment in oil & gas and petrochemical facilities.
- Proven Reliability – Bently Nevada eddy-current technology with field-demonstrated MTBF exceeding 200,000 hours.
Typical Applications
- Steam & Gas Turbines – Shaft radial vibration and axial position monitoring in power generation plants.
- Centrifugal Compressors – Thrust position and vibration surveillance in LNG, refinery, and petrochemical service.
- Boiler Feed Pumps – Continuous bearing health monitoring in high-pressure utility applications.
- Gearboxes & Expanders – Shaft orbit and gear mesh frequency analysis in process industries.
- Marine Propulsion – Shaft monitoring in shipboard turbine and diesel-electric drive trains.
- Paper, Steel & Mining – Roll and drive shaft condition monitoring in high-vibration, heavy-industry environments.
Compatible System Components
The 330905-00-05-10-01-00 is designed to operate within the Bently Nevada 3300 XL and 3500 ecosystem. Typical companion components include:
- Monitor Module: Bently Nevada 3500/40M Proximitor / Seismic Monitor
- Rack Interface: Bently Nevada 3500/05 Rack Interface Module
- Power Supply: Bently Nevada 3500/15 Power Supply Module
- ATEX Barrier (hazardous areas): MTL 787S+ Zener barrier or equivalent galvanic isolator
- Mounting Hardware: Bently Nevada standard proximity probe mounting brackets
Contact support@konmask.com for complete loop pricing and system configuration support.
Global Sourcing & Shipping Capabilities
- Stock Availability: In-stock units typically ship within 3–7 business days; sourced orders 2–4 weeks.
- MOQ: 1 piece — no minimum order quantity.
- Export Coverage: Worldwide shipping via DHL Express, FedEx International Priority, and UPS Worldwide.
- Export Documentation: Commercial invoice, packing list, certificate of origin, and ATEX documentation provided on request.
- Customs Support: HS code classification and export control screening completed prior to shipment.
- Payment Terms: T/T bank transfer, PayPal, and credit card via Shopify Payments.
Certifications & Compliance Statement
- API 670 – Machinery Protection Systems, 5th Edition
- IEC 61511 – Functional Safety for the Process Industry Sector
- ATEX Directive 2014/34/EU – Zone 1 & Zone 2 hazardous area rated
- FM Approved – Class I, Division 1 & 2, Groups A–D
- CE Marking – EMC Directive 2014/30/EU compliant
- RoHS Compliant – Restriction of Hazardous Substances Directive
Konmask.com maintains sourcing records and compliance documentation for all units. Copies are available upon request for your quality management system (QMS) or vendor qualification audit.
How to Order
- Add to Cart – Place your order directly through this page for immediate processing.
- Request a Quote – Email support@konmask.com for formal PO-based procurement with lead time and pricing confirmation.
- Phone / WhatsApp: +0086 19859288691 — available for urgent sourcing inquiries.
- Bulk Orders: Volume pricing available for orders of 3+ units. Contact us for a tiered quote.
- Vendor Registration: Konmask.com can provide W-9, company registration, and insurance certificates for your vendor onboarding process.
Authenticity & Trust FAQ
Q: How do I know the 330905-00-05-10-01-00 you supply is genuine?
A: All units are sourced from authorized distributors or verified surplus channels. We provide chain-of-custody documentation, original packaging, and serial number traceability on request. Our 4-step verification process is applied to every unit before shipment.
Q: Can Konmask.com provide a Certificate of Conformance (CoC)?
A: Yes. For factory-sealed units, the original Bently Nevada CoC is included. For surplus units, Konmask’s own inspection certificate is provided, detailing the verification steps completed.
Q: Is this part compatible with my existing 3500 Series monitoring rack?
A: Yes. The 3300 XL probe system is fully compatible with the Bently Nevada 3500 rack when paired with the appropriate 3300 XL driver/proximitor module. Contact us if you need help confirming your system configuration.
Q: What is your return and warranty policy?
A: Konmask.com offers a 90-day quality guarantee on all industrial automation components. If a unit fails to meet specification upon receipt, we will replace or refund — no questions asked.
Q: Can you support ATEX-certified installations?
A: Yes. The 330905-00-05-10-01-00 carries ATEX certification for Zone 1 & Zone 2 hazardous areas when installed with a certified Zener barrier or galvanic isolator per Bently Nevada’s installation drawing.
Q: Do you ship to my country?
A: Konmask.com ships worldwide. We handle all export documentation and can advise on import requirements for your destination country. Contact us for country-specific shipping lead times and costs.
