Vibration Monitoring Solution – Bently Nevada 330101-02-32-10-02-05 | 3300 XL Series
Where This Product Is Used
The Bently Nevada 330101-02-32-10-02-05 proximity transducer is engineered for continuous, non-contact vibration and position measurement in rotating machinery. It is widely deployed in:
- Oil & Gas: Compressor trains, gas turbines, centrifugal pumps, and pipeline booster stations where shaft radial vibration must be monitored 24/7.
- Power Generation: Steam turbines, hydro generators, and combined-cycle plants requiring API 670-compliant protection systems.
- Petrochemical & Refining: Reactor agitators, extruders, and critical rotating equipment subject to continuous process loads.
- Marine & Offshore: Propulsion shafting and auxiliary machinery where saltwater-resistant, robust sensing is mandatory.
- Pulp & Paper / Mining: High-speed fans, crushers, and mill drives operating in dusty, high-vibration environments.
Technical Specifications
- Part Number: 330101-02-32-10-02-05
- Series: Bently Nevada 3300 XL
- Type: Eddy-Current Proximity Transducer
- Probe Tip Diameter: 8 mm
- Measurement Range: 0–2 mm (linear range)
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Supply Voltage: –24 VDC (nominal)
- Output: –1 VDC to –9 VDC (proportional to gap)
- Frequency Response: DC to 10,000 Hz
- Operating Temperature: –35 °C to +121 °C
- Connector: 5-pin MIL-C-5015 style
- Weight: ~200 g
- Compliance: API 670, CE, RoHS
Why Engineers Specify This Model
- Proven 3300 XL Platform: Global industry benchmark for machinery protection, trusted in over 100,000 installations worldwide.
- Non-Contact Measurement: Eddy-current technology eliminates mechanical wear — maintenance-free over multi-year turnaround cycles.
- High Linearity: ±1% linearity across full measurement range ensures accurate alarm and trip setpoints without field recalibration.
- Wide Temperature Range: Rated to 121 °C probe tip temperature, suitable for hot-section turbine bearing housings.
- Direct System Integration: Plug-and-play with Bently Nevada 3300 and System 1 monitoring racks — no signal conditioning adapters required.
- API 670 Compliance: Meets the mandatory standard for machinery protection systems in hydrocarbon processing plants.
Complete System Bill of Materials
For a fully functional proximity measurement loop, the following components are typically required:
- Probe: 330101-02-32-10-02-05 (this item)
- Extension Cable: Bently Nevada 330130-045-00-00 (or length-matched equivalent)
- Proximitor / Signal Conditioner: Bently Nevada 330180-X1-05 (3300 XL 8 mm)
- Monitoring Rack: Bently Nevada 3500/42M or System 1 Evolution
- Mounting Hardware: Bently Nevada 02-262788-01 probe holder (application-specific)
Contact Konmask.com for complete loop pricing and compatibility verification.
Compliance & Industry Standards
- API 670 (5th Edition) – Machinery Protection Systems
- IEC 61511 – Functional Safety for Process Industry
- CE Marking – EU Electromagnetic Compatibility Directive
- RoHS Compliant – Restriction of Hazardous Substances
- ISO 10816 / ISO 20816 – Mechanical Vibration Measurement
Quality Assurance & Sourcing
Every Bently Nevada 330101-02-32-10-02-05 unit supplied by Konmask.com is:
- Sourced from authorized distributors or verified surplus channels with full traceability documentation.
- Inspected for physical integrity, connector condition, and cable continuity prior to dispatch.
- Shipped with original manufacturer packaging where available, or equivalent ESD-safe protective packaging.
- Supported by a 12-month warranty against manufacturing defects.
How to Source This Part
- In Stock: Add to cart and check out directly — most orders ship within 1–3 business days.
- Bulk / Project Quantity: Email support@konmask.com for volume pricing and lead-time confirmation.
- Urgent Requirement: Call or WhatsApp +0086 19859288691 for same-day quotation and expedited freight options.
- Cross-Reference / Substitution: Our engineers can verify compatible alternatives if this exact part number is unavailable.
Application-Specific FAQ
Q: Is the 330101-02-32-10-02-05 compatible with the Bently Nevada 3500 rack?
A: Yes. The 3300 XL 8 mm probe system is fully compatible with the 3500 series monitoring rack when paired with the correct Proximitor (330180-X1-05).
Q: What is the maximum shaft speed this transducer can monitor?
A: The 10,000 Hz frequency response supports shaft speeds well above 30,000 RPM, covering virtually all industrial rotating machinery applications.
Q: Can this probe be used for axial position (thrust) measurement?
A: Yes. With appropriate mounting orientation and a compatible monitor channel configured for position, the 330101 series supports both radial vibration and axial position measurement.
Q: What target material is required for accurate measurement?
A: The probe is calibrated for AISI 4140 steel. Other ferromagnetic or conductive target materials may require field calibration to maintain specified sensitivity.
Q: Does Konmask.com provide installation or commissioning support?
A: We provide technical documentation and remote guidance. For on-site commissioning, we can recommend qualified service partners in your region.
