BENTLY NEVADA 3500/05-01-02-00-00-00 Rack | Replacement, Equivalent & Selection Guide
The Bently Nevada 3500/05-01-02-00-00-00 is the standard 19-inch rack chassis for the 3500 Series Machinery Protection System. It provides the structural backbone and backplane connectivity for all 3500 Series monitor and I/O modules. This page serves as a comprehensive selection guide to help engineers identify compatible replacements, equivalent alternatives, and system integration requirements.
Technical Specifications
- Part Number: 3500/05-01-02-00-00-00
- Manufacturer: Bently Nevada (Baker Hughes)
- Series: 3500 Machinery Protection System
- Form Factor: 19-inch rack-mount chassis
- Slot Capacity: Up to 14 module slots
- Backplane: Integrated 3500 Series backplane bus
- Power Input: Accepts 3500/15 or 3500/25 power supply modules
- Communication: Supports TDI (Trip Multiply/Inhibit) and system relay outputs via backplane
- Mounting: Standard 19-inch EIA rack, front-access design
- Operating Temperature: 0°C to 65°C
- Certifications: CE, CSA, FM (per system configuration)
- Weight: ~30 g (chassis only, without modules)
Compatible Replacement & Equivalent Models
The following models are functionally equivalent or serve as direct replacements for the 3500/05-01-02-00-00-00 rack chassis. Always verify firmware and backplane revision compatibility before substitution.
- 3500/05-01-01-00-00-00 — Standard rack, alternate option code variant
- 3500/05-01-02-00-00-01 — Rack with enhanced EMI shielding option
- 3500/05-01-02-01-00-00 — Rack with integrated display panel option
- 3500/05-01-02-00-01-00 — Rack with extended temperature rating
- 3500/05-02-00-00-00-00 — Half-rack chassis (reduced slot count, 7-slot)
Note: Option codes in positions 3–6 of the part number control chassis features. Contact Konmask for cross-reference verification.
Why Choose the Original Model
- Guaranteed Backplane Compatibility: Factory-matched to all 3500 Series monitor modules (3500/20, 3500/22, 3500/40, 3500/42, 3500/45, 3500/50, 3500/60, 3500/72, etc.)
- Proven Field Reliability: Deployed globally in critical rotating machinery protection applications for 20+ years
- OEM Firmware Support: Ensures full compatibility with System 1 and System 1 Evolution software
- Safety Integrity: Maintains SIL-rated system integrity when used with certified module combinations
- Regulatory Compliance: Meets hazardous area and industrial safety standards as part of a certified system
Typical Applications
- Gas turbine and steam turbine vibration monitoring systems
- Centrifugal and axial compressor protection panels
- Pump and motor bearing condition monitoring
- Gearbox and generator shaft monitoring
- Offshore platform and LNG plant machinery protection
- Petrochemical and refinery critical equipment monitoring
- Power generation plant turbine protection systems
System Compatibility
The 3500/05-01-02-00-00-00 rack is the host chassis for the complete 3500 Series ecosystem. Compatible modules include:
- Power Supplies: 3500/15 (AC), 3500/25 (DC)
- System Monitors: 3500/20 (Rack Interface Module), 3500/22 (Transient Data Interface)
- Vibration Monitors: 3500/40, 3500/42, 3500/44, 3500/45
- Process Monitors: 3500/60, 3500/62, 3500/64
- Relay Modules: 3500/32, 3500/33
- I/O Modules: 3500/20-01-00 (System I/O)
- Software: System 1 v6.x / System 1 Evolution (S1E)
Selection Guide
Use the following criteria to select the correct 3500/05 rack variant for your application:
- Slot Count Required: Full rack (14 slots) → 3500/05-01-xx; Half rack (7 slots) → 3500/05-02-xx
- Display Requirement: No display → option code position 4 = 0; With display → position 4 = 1
- EMI Environment: Standard → position 3 = 0; Enhanced shielding → position 3 = 1
- Temperature Range: Standard (0–65°C) → position 5 = 0; Extended → position 5 = 1
- Hazardous Area: Confirm module-level certifications (FM, ATEX) separately — the rack itself is non-Ex
- Replacement Scenario: For like-for-like swap, match all 6 option code positions exactly
Quality Assurance & Sourcing
- All units sourced through verified industrial automation supply channels
- Pre-shipment inspection: visual, dimensional, and label verification
- Traceability documentation available upon request
- New, refurbished, and tested-used conditions available — specify at time of inquiry
- Lead time: typically 3–10 business days depending on stock status
- Export compliance: ECCN classification and export documentation provided where required
How to Order
- Confirm the exact part number: 3500/05-01-02-00-00-00
- Specify required condition: New / Refurbished / Tested-Used
- Provide your shipping destination and any export compliance requirements
- Contact us via email or phone for a formal quotation
- Purchase orders accepted; proforma invoice available for prepayment
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I use a 3500/05-01-02-00-00-00 rack with older 3500 Series modules?
A: Yes, the 3500/05 rack is backward compatible with all 3500 Series modules. Verify backplane revision if mixing early-generation modules.
Q: Is the 3500/05-01-02-00-00-00 interchangeable with the 3500/05-01-01-00-00-00?
A: In most cases yes — the difference lies in minor option codes. Confirm with your system documentation or contact us for cross-reference support.
Q: Can this rack be used as a standalone unit without a power supply module?
A: No. The rack requires a 3500/15 or 3500/25 power supply module installed to function.
Q: Does Konmask provide warranty on replacement racks?
A: Yes. All units carry a minimum 90-day warranty. Extended warranty options are available — inquire at time of order.
Q: Can I mix new and refurbished modules in the same rack?
A: Technically yes, but we recommend consistent condition grades for critical protection systems to ensure uniform reliability.
