Vibration Monitoring Power Solution – Bently Nevada 3500/15-04-04 114M5330-01 | 3500 Series
Where This Product Is Used
The Bently Nevada 3500/15-04-04 (P/N: 114M5330-01) is the dedicated rack power supply module for the Bently Nevada 3500 Series continuous vibration monitoring platform. It is deployed in mission-critical rotating machinery protection systems across the following industries and applications:
- Oil & Gas: Compressor trains, gas turbines, centrifugal pumps on offshore platforms and onshore processing facilities
- Power Generation: Steam turbine-generator sets, hydro turbines, and combined-cycle plant auxiliaries
- Petrochemical & Refining: Reactor feed pumps, cracked gas compressors, and critical agitators
- Pulp & Paper / Mining: Large fan drives, ball mills, and kiln drive systems requiring continuous shaft vibration surveillance
- Marine & Offshore: Propulsion shaft monitoring and FPSO machinery protection racks
Wherever a 3500 rack is installed to protect high-value rotating assets, the 3500/15 power supply is the backbone that keeps every monitor card energized and communicating.
Technical Specifications
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model / Part Number | 3500/15-04-04 / 114M5330-01 |
| Series | 3500 Machinery Protection System |
| Module Type | Rack Power Supply |
| Input Voltage Options | AC: 85–264 VAC, 47–63 Hz / DC: 18–32 VDC (option code -04-04) |
| Output | +5 VDC, ±15 VDC, +24 VDC internal rack bus |
| Redundancy | Supports dual power supply configuration (hot-swap capable) |
| Form Factor | Single-slot 3500 rack module |
| Operating Temperature | 0 °C to +65 °C |
| Approvals | CE, CSA, FM (Class I, Div 2) |
| Weight | ~60 g (module only) |
| SKU / Inventory Code | 330180-10-05 |
Why Engineers Specify This Model
- Wide-range AC/DC input (option -04-04): Accepts both AC mains and DC battery-backed supplies, eliminating the need for external converters in hybrid power environments.
- Hot-swap redundancy: A second 3500/15 can be installed in the same rack for N+1 redundancy — the failed unit is replaced without shutting down monitoring.
- Isolated outputs: Galvanically isolated DC rails prevent ground loops that would corrupt vibration signal integrity on proximity probe channels.
- Integrated health monitoring: Power supply status is reported to the 3500/20 rack interface module and visible in System 1 software, enabling predictive maintenance of the power supply itself.
- Compact single-slot footprint: Maximizes available slots for monitor cards in space-constrained 19-inch rack enclosures.
Complete System Bill of Materials
The 3500/15-04-04 is typically ordered alongside the following 3500 Series components:
- 3500/05 – Rack Interface Module (RIM)
- 3500/20 – Rack Interface I/O Module
- 3500/22M – Transient Data Interface
- 3500/25 – Enhanced Keyphasor Module
- 3500/40M – Proximitor / Seismic Monitor
- 3500/42M – Proximitor / Seismic Monitor (4-channel)
- 3500/45 – Position Monitor
- 3500/50M – Tachometer Module
- 3500/92 – Communication Gateway Module
- 330180-10-05 – 3300 XL 8mm Proximity Transducer (field sensor)
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition): The 3500 platform, powered by this module, is the reference implementation for API 670-compliant installations.
- IEC 61511 – Functional Safety (SIL): Compatible with SIL-rated safety instrumented system architectures when configured per Bently Nevada SIL documentation.
- ATEX / IECEx: Suitable for use in Zone 2 hazardous areas when installed per approved drawings (consult factory for Zone 1 barrier requirements).
- CE Marking: Compliant with EU Low Voltage Directive and EMC Directive.
- CSA / FM Class I, Division 2: Certified for North American hazardous locations.
Quality Assurance & Sourcing
- Every unit sold by Konmask.com undergoes incoming inspection including visual examination, label verification, and functional power-on test where applicable.
- Modules are sourced from authorized distributors, decommissioned plant upgrades, and verified surplus channels — never counterfeit or grey-market sources.
- Original Bently Nevada firmware and hardware configuration are preserved; no modifications are made.
- Packaging includes anti-static protection, foam cushioning, and a certificate of inspection.
- Traceability documentation (serial number, revision level) provided upon request.
How to Source This Part
To place an order or request a quote for the Bently Nevada 3500/15-04-04 114M5330-01:
- Online: Add to cart directly on this page — stock is updated in real time.
- Email RFQ: [email protected] — include your required quantity, delivery timeline, and any certification requirements.
- Phone / WhatsApp: +0086 19859288691 (Monday–Friday, 09:00–18:00 CST)
- Lead time: In-stock units ship within 1–3 business days. Out-of-stock units: 2–4 weeks sourcing lead time.
- Export: We ship worldwide with full commercial invoice and packing list documentation for customs clearance.
Application-Specific FAQ
Q: Can the 3500/15-04-04 replace an older 3500/15-02-00 in an existing rack?
A: Yes — the -04-04 option code indicates wide-range AC/DC input, which is backward compatible with standard AC-only racks. Verify your rack backplane revision supports the module before installation.
Q: How many 3500/15 modules can be installed in one rack?
A: Up to two (2) power supply modules can be installed per 3500 rack for redundancy. The rack automatically load-shares and fails over to the remaining supply if one fails.
Q: Is this module compatible with System 1 software?
A: Yes. Power supply health status is reported through the 3500/20 RIM to System 1 Evolution and System 1 (legacy) software platforms.
Q: Do you provide a warranty?
A: Konmask.com offers a 90-day functional warranty on all verified surplus modules. New/factory-sealed units carry the original Bently Nevada warranty terms.
Q: Can you supply the matching proximity transducer system (sensor + extension cable + proximitor)?
A: Yes — contact us with your gap voltage requirements and cable length to receive a matched 3300 XL or 7200 series transducer system quote.
