Bently Nevada 4170180-01-05 – External Transducer I/O Module | 3500 Series Platform
Engineering Background: The Bently Nevada 3500 Series is the industry benchmark for continuous machinery protection monitoring, deployed across power generation, oil & gas, petrochemical, and rotating equipment facilities worldwide. The 4170180-01-05 External Transducer I/O Module extends the 3500 rack’s signal acquisition capability by providing dedicated external transducer interface channels, enabling engineers to connect proximity probes, accelerometers, and velocity sensors without occupying primary monitor card slots.
Product Positioning: Designed for procurement engineers and reliability teams requiring a certified, OEM-sourced I/O expansion component for existing 3500 Series racks. This module is a direct-fit replacement and system expansion unit, maintaining full compatibility with Bently Nevada’s System 1 software ecosystem and rack-level diagnostics.
Complete Technical Specifications
- Part Number / SKU: 4170180-01-05
- Manufacturer: Bently Nevada (Baker Hughes)
- Series / Platform: 3500 Series Machinery Protection System
- Module Type: External Transducer I/O Module
- Form Factor: 3500 Rack-Mount Card
- Signal Interface: External transducer input channels (proximity probe / accelerometer / velocity)
- Communication: Internal rack backplane bus
- Power Supply: Supplied via 3500 rack backplane (no external PSU required)
- Operating Temperature: 0°C to +60°C (standard industrial range)
- Weight: 280 g (approx.)
- Country of Origin: United States
- Compliance: CE, UL, SIL-capable (per 3500 Series system certification)
Proven Application Environments
- Gas turbine and steam turbine protection systems
- Centrifugal compressor and pump vibration monitoring
- Offshore and onshore oil & gas platforms
- Power generation (nuclear, thermal, hydro)
- Petrochemical and refinery rotating equipment
- LNG liquefaction train monitoring racks
Engineering Advantages
- Direct OEM Compatibility: Plug-and-play fit within any standard 3500 Series rack — no firmware modification required.
- Signal Integrity: Dedicated I/O path eliminates cross-channel interference, preserving measurement accuracy to API 670 standards.
- Rack Slot Efficiency: Offloads transducer connections from primary monitor cards, freeing slots for additional measurement channels.
- Reduced Downtime: Hot-swap capable within 3500 rack architecture; supports rapid field replacement during planned maintenance windows.
- System 1 Integration: Fully recognized by Bently Nevada System 1 software for real-time diagnostics, trending, and alarm management.
System Architecture & Signal Flow
The 4170180-01-05 interfaces between field-mounted transducers and the 3500 rack’s internal monitoring cards via the rack backplane. Transducer signals (raw voltage or current loop) are conditioned and routed through the module’s I/O channels to the designated monitor card, which performs gap, direct, 1X, 2X, and overall vibration measurements. The module supports both buffered output and direct rack communication, ensuring no signal degradation across the measurement chain.
Sourcing & Quality Verification
- All units sourced from authorized distributors or verified surplus channels with full traceability documentation.
- Pre-shipment inspection includes visual, label verification, and functional continuity check.
- Original OEM packaging preserved where available; anti-static ESD packaging applied for all shipments.
- Certificate of conformance (CoC) available upon request for critical-service procurement.
- Lead time: typically 3–7 business days for in-stock units; expedited options available.
Procurement Process
- Confirm part number 4170180-01-05 against your BOM or existing rack configuration.
- Submit RFQ or place order directly via Konmask.com.
- Receive order confirmation with estimated ship date within 1 business day.
- Unit ships with packing list, CoC (on request), and ESD-safe packaging.
- Post-delivery technical support available via email or phone.
Technical FAQ
Q: Is the 4170180-01-05 compatible with all 3500 Series rack configurations?
A: Yes. It is designed for standard 3500 rack backplane slots and is compatible with all current 3500 Series monitor card variants.
Q: Can this module be used as a direct replacement for a failed unit?
A: Yes. It is a direct OEM replacement. No reconfiguration of the rack or System 1 software is required beyond standard re-commissioning procedures.
Q: Do you provide a warranty?
A: All units carry a 90-day functional warranty. Extended warranty options are available — contact us for details.
Q: Can I request a Certificate of Conformance?
A: Yes. CoC documentation is available upon request at time of order for all units.
Q: What is the lead time for bulk orders?
A: Bulk orders (5+ units) are subject to availability. Contact our procurement team for volume pricing and lead time confirmation.
