The Bently Nevada 86517-01-01-01-02 Acceleration Interface Module is engineered for continuous machinery protection in the most demanding industrial environments. Engineers and reliability teams specify this module across the following critical applications:
- Gas & Steam Turbines – Real-time casing acceleration monitoring to detect bearing defects, blade pass events, and structural resonance before catastrophic failure.
- Centrifugal Compressors – High-frequency vibration acquisition on compressor casings in petrochemical and LNG plants where API 670 compliance is mandatory.
- Rotating Machinery in Power Generation – Integration into 3500 Series racks at power stations for continuous online monitoring of generators and auxiliary equipment.
- Offshore & Onshore Oil & Gas Platforms – Hazardous-area-rated installations requiring certified, OEM-sourced interface modules with proven field reliability.
- Pulp & Paper and Heavy Industry – Monitoring of fans, pumps, and gearboxes where unplanned downtime carries significant production cost.
Technical Specifications
| Attribute | Value |
|---|---|
| Part Number | 86517-01-01-01-02 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Series | 3500 Machinery Protection System |
| Module Type | Acceleration Interface Module |
| Input Channels | 4 (acceleration / high-frequency vibration) |
| Sensor Compatibility | ICP® / IEPE accelerometers |
| Frequency Range | Up to 20 kHz (application-dependent) |
| Output | 4–20 mA / digital via 3500 rack backplane |
| Power Supply | Supplied via 3500 rack (no external PSU required) |
| Approvals | CE, FM, CSA (refer to OEM datasheet for full listing) |
| Weight | 580 g |
| Form Factor | Single-slot 3500 Series rack card |
Why Engineers Specify This Model
- API 670 Compliance – Designed to meet the Machinery Protection Systems standard required by EPC contractors and end-users in oil & gas.
- Seamless 3500 Rack Integration – Hot-swappable card that slots directly into any 3500 Series rack without additional wiring or configuration hardware.
- High-Frequency Acquisition – Captures acceleration data up to 20 kHz, enabling early detection of bearing defects, gear mesh frequencies, and structural resonance.
- Proven Field Reliability – Bently Nevada’s 3500 platform is the global benchmark for turbomachinery protection with decades of installed base.
- Reduced Commissioning Time – Plug-and-play compatibility with existing 3500 racks minimizes engineering hours during installation and replacement.
Complete System Bill of Materials
For a fully operational 3500 Series acceleration monitoring channel, the following components are typically required:
- 3500/20 Rack Interface Module (RIM)
- 3500/15 Power Supply Module
- 86517-01-01-01-02 Acceleration Interface Module (this item)
- Compatible ICP® / IEPE accelerometer (e.g., Bently Nevada 330400 series or equivalent)
- 3500 Series I/O Terminal Block and field wiring
- Bently Nevada System 1 software (for data acquisition and trending)
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition)
- IEC 61508 – Functional Safety of E/E/PE Safety-related Systems
- CE Marking – European conformity for industrial electrical equipment
- FM / CSA – North American hazardous location certifications (verify suffix for specific approval)
- ISO 10816 / ISO 20816 – Mechanical vibration evaluation standards
Quality Assurance & Sourcing
Konmask.com sources the Bently Nevada 86517-01-01-01-02 through verified industrial automation distributors and OEM-authorized channels. Every unit undergoes the following before dispatch:
- Visual and physical inspection against OEM specifications
- Serial number and firmware version verification
- Anti-static packaging with humidity indicator cards
- Documentation package: datasheet, test record, and certificate of conformance available on request
We do not supply counterfeit, refurbished-as-new, or grey-market components. All stock is traceable to authorized supply chains.
How to Source This Part
Ready to order or need a formal quotation for your procurement team?
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Lead Time: Contact us for current stock availability and lead time — we maintain buffer stock on high-demand 3500 Series modules.
- MOQ: 1 unit (no minimum order quantity)
- Payment: T/T, PayPal, and major credit cards accepted
- Export: Worldwide shipping with full export documentation (commercial invoice, packing list, COO)
Application-Specific FAQ
Q: Is the 86517-01-01-01-02 compatible with all 3500 Series racks?
A: Yes. It is designed as a standard single-slot card for the 3500 rack platform. Confirm your rack firmware version with Bently Nevada or contact us for compatibility guidance.
Q: Can this module replace an older acceleration interface card in an existing installation?
A: In most cases, yes — the 3500 platform is designed for backward compatibility. We recommend verifying the rack configuration file before hot-swapping in a live system.
Q: What accelerometer types are compatible?
A: The module accepts ICP® (IEPE) accelerometers. Bently Nevada 330400 series and equivalent third-party sensors with standard ICP® output are supported.
Q: Do you provide a warranty?
A: Yes. We offer a 12-month warranty against manufacturing defects. Contact support@konmask.com for warranty claims and RMA procedures.
Q: Can you supply the full 3500 Series rack system?
A: Yes. Konmask.com can source complete 3500 Series rack assemblies, individual modules, and accessories. Send your BOM to support@konmask.com for a consolidated quotation.
