Genuine Bently Nevada 330103-00-12-10-02-05 Proximity Probe | 3300 XL Series — Verified Source
The Bently Nevada 330103-00-12-10-02-05 is an 8mm eddy current proximity probe from the industry-standard 3300 XL Series, engineered for continuous shaft vibration and position monitoring on critical rotating machinery. Sourced directly through verified industrial supply channels, every unit sold by Konmask.com undergoes a documented 4-step authenticity check before dispatch.
Technical Specifications
| Part Number | 330103-00-12-10-02-05 |
| Brand | Bently Nevada (Baker Hughes) |
| Series | 3300 XL 8mm Proximity Transducer System |
| Probe Type | Eddy Current (Non-contact) |
| Probe Diameter | 8 mm |
| Cable Length | 1.2 m (integral cable) |
| Extension Cable | Compatible with 330130 / 330180 series |
| Conditioner | Compatible with 3300 XL 8mm Proximitor® Sensor |
| Output | -18 VDC nominal (with matched Proximitor) |
| Temperature Range | -35°C to +121°C (probe tip) |
| Target Material | Steel / Iron (AISI 4140 reference) |
| Approvals | CE, ATEX, FM, CSA (system-level) |
| Weight | Approx. 800 g (packaged) |
| Country of Origin | USA |
Our 4-Step Quality Verification Process
Every Bently Nevada 330103-00-12-10-02-05 unit shipped from Konmask.com passes through the following verification workflow:
- Documentation Audit — Original manufacturer packaging, date codes, and batch traceability records are cross-checked against supplier declarations.
- Physical Inspection — Probe tip, connector pins, cable jacket, and label markings are inspected against OEM reference standards for dimensional and cosmetic conformance.
- Functional Pre-check — Coil impedance and insulation resistance are measured to confirm the probe is within Bently Nevada factory specification ranges.
- Secure Packaging & Serialization — Units are resealed in anti-static packaging with a Konmask verification label and shipment serial number for full traceability.
Key Features & Benefits
- Non-contact measurement eliminates mechanical wear for continuous 24/7 operation
- High sensitivity and linearity for accurate shaft displacement and vibration data
- Integral cable design reduces connector failure points in harsh environments
- Fully compatible with existing 3300 XL Proximitor® and monitoring system infrastructure
- Compact 8mm form factor fits tight bearing housing installations
- Designed for API 670 compliance in critical machinery protection systems
Typical Applications
- Steam and gas turbine shaft radial vibration monitoring
- Centrifugal compressor rotor position measurement
- Pump and motor bearing proximity sensing
- Gearbox and expander condition monitoring
- Thrust position measurement (axial displacement)
- OEM machinery protection system retrofits and replacements
Compatible System Components
| Extension Cable | Bently Nevada 330130-045-00-00 / 330180 series |
| Proximitor® Sensor | Bently Nevada 3300 XL 8mm (330180 / 330185) |
| Monitoring System | Bently Nevada 3500 Series Rack |
| I/O Module | 3500/40M, 3500/42M Proximitor® I/O |
| Keyphasor® | 3500/25 Keyphasor® Module |
Global Sourcing & Shipping Capabilities
Konmask.com maintains stocking relationships with verified industrial distributors across Asia, Europe, and North America. We support:
- Express Air Freight — DHL / FedEx / UPS door-to-door, typically 3–7 business days worldwide
- Sea Freight Consolidation — Cost-effective option for bulk orders (>10 units)
- Export Documentation — Commercial invoice, packing list, COO certificate, and MSDS available on request
- Customs Compliance — HS Code pre-classification and export licensing support for controlled destinations
Certifications & Compliance Statement
The Bently Nevada 3300 XL proximity transducer system carries the following certifications at the system level:
- CE Marking — EMC Directive 2014/30/EU
- ATEX — Zone 1 & Zone 2 hazardous area approval (system-level)
- FM & CSA — North American hazardous location approvals
- API 670 — Compliant for use in machinery protection systems per API Standard 670 (5th Edition)
Konmask.com is an independent distributor. All brand names and part numbers are the property of their respective manufacturers and are used solely for identification purposes.
How to Order
- Click Add to Cart or Buy Now to place your order online.
- For bulk orders (>3 units), RFQ pricing, or lead-time confirmation, contact us at [email protected] or +0086 19859288691.
- Provide your shipping address and preferred freight method at checkout.
- Receive order confirmation with tracking number within 1 business day of payment clearance.
Authenticity & Trust FAQ
Q: Are these genuine Bently Nevada parts?
A: Yes. All units are sourced from verified industrial supply channels with traceable documentation. We do not sell remanufactured or counterfeit components.
Q: Can you provide a certificate of conformance?
A: Yes. A Konmask inspection certificate is included with every shipment. OEM CoC availability depends on the specific batch sourced.
Q: What is your return policy?
A: We accept returns within 30 days for unused, unopened units in original packaging. Functional defects are covered under our quality guarantee.
Q: Do you support urgent / emergency orders?
A: Yes. Contact us directly for same-day quotation and priority dispatch on in-stock items.
Q: Can I verify the part before shipment?
A: Yes. We can provide pre-shipment inspection photos and measurement reports upon request for orders of 2+ units.
