Bosch Rexroth CP6201-0001-0060 – High-Performance Industrial Panel PC | IndraControl XM22 Platform
Engineering Background: The CP6201-0001-0060 is part of Bosch Rexroth’s IndraControl XM22 series — a purpose-built industrial panel PC platform engineered for demanding automation environments. Designed to serve as the central HMI and control computing node in Rexroth’s IndraMotion and IndraLogic ecosystems, this unit bridges real-time motion control with operator visualization in a single ruggedized enclosure.
Product Positioning: Targeted at OEM machine builders, system integrators, and plant automation engineers who require a certified, field-proven computing platform with deterministic performance. The CP6201-0001-0060 is the preferred choice for press lines, packaging machinery, CNC machining centers, and process automation cells where uptime and signal integrity are non-negotiable.
Complete Technical Specifications
- Part Number: CP6201-0001-0060
- Series / Platform: IndraControl XM22 (Bosch Rexroth)
- Device Type: Industrial Panel PC / HMI Controller
- Processor: Intel® Atom™ / Core™ series (platform-dependent configuration)
- Operating System: Windows Embedded Standard / Windows 10 IoT (configuration-specific)
- Display Interface: Integrated panel PC form factor with DVI/VGA output support
- Communication Interfaces: Ethernet (RJ45 ×2), USB 2.0/3.0, RS-232/RS-485, PROFIBUS, SERCOS III
- Fieldbus Compatibility: PROFINET, EtherCAT, CANopen, SERCOS III
- Storage: CFast / SSD (solid-state, vibration-resistant)
- Supply Voltage: 24 V DC (±20%)
- Power Consumption: ≤ 40 W (typical)
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: −20 °C to +70 °C
- Relative Humidity: 5% to 95% (non-condensing)
- Protection Rating: IP65 (front panel)
- Vibration Resistance: IEC 60068-2-6 compliant
- Shock Resistance: IEC 60068-2-27 compliant
- Certifications: CE, UL, cUL, RoHS
- Country of Origin: Germany
- Weight: approx. 2.5 kg
- Mounting: Panel cut-out / VESA mount compatible
Proven Application Environments
- CNC machining centers and multi-axis motion control systems
- Injection molding and die-casting machine HMI nodes
- Packaging and labeling line supervisory controllers
- Press brake and hydraulic press automation
- Robotic cell integration with IndraMotion MLC/MLD
- Process automation panels in chemical and pharmaceutical plants
- Wind turbine pitch and yaw control systems (Rexroth ecosystem)
- Automotive assembly line control stations
Engineering Advantages
- Deterministic Real-Time Performance: Optimized for Rexroth’s IndraLogic PLC runtime with cycle times down to 1 ms, ensuring precise synchronization with servo drives and I/O modules.
- Fanless / Reduced-Maintenance Design: Solid-state storage and passive thermal management eliminate mechanical wear points, extending MTBF in dusty or vibration-prone environments.
- Seamless Rexroth Ecosystem Integration: Native compatibility with IndraWorks engineering software, IndraMotion MLC/MLD, and IndraDrive series — reducing commissioning time and integration risk.
- IP65 Front Panel: Sealed against dust and water jets, suitable for wash-down zones and harsh factory floors without additional enclosure investment.
- Wide Fieldbus Support: Single hardware platform supports PROFINET, EtherCAT, SERCOS III, and CANopen — future-proofing your control architecture.
- Compact Panel-Mount Form Factor: Minimizes cabinet footprint while consolidating HMI, PLC runtime, and motion control into one unit.
System Architecture & Signal Flow
The CP6201-0001-0060 operates as the master computing node within a Rexroth IndraControl architecture. The unit runs the IndraLogic XLC PLC runtime alongside the HMI visualization layer (WinStudio / IndraWorks HMI), communicating with IndraDrive servo drives via SERCOS III or EtherCAT at the field level. Upstream, it connects to SCADA/MES systems via Ethernet OPC-UA or PROFINET. Digital and analog I/O expansion is achieved through Rexroth’s Inline I/O modules or third-party PROFIBUS/EtherCAT slaves. The panel PC’s dual Ethernet ports enable network segmentation between the machine network and plant IT network — a critical security and performance best practice in modern IIoT deployments.
Sourcing & Quality Verification
- Source: Konmask.com sources CP6201-0001-0060 units from authorized Bosch Rexroth distribution channels and verified industrial surplus inventories.
- Inspection: Each unit undergoes visual inspection, label verification (part number, date code, country of origin), and functional power-on testing prior to shipment.
- Authenticity: We do not deal in counterfeit or remarked components. Traceability documentation is available upon request for critical applications.
- Condition: New (factory-sealed) or Refurbished (tested, cleaned, re-certified) — please specify at inquiry.
- Warranty: 12-month replacement warranty on all shipped units.
Procurement Process
- Submit Inquiry: Contact us via the product page or email [email protected] with your required quantity and delivery timeline.
- Receive Quote: We respond within 24 business hours with pricing, lead time, and stock availability confirmation.
- Order Confirmation: Place order via our secure checkout or via purchase order (PO) for qualified B2B accounts.
- Shipping: DHL Express / FedEx International with full tracking. Export documentation (commercial invoice, packing list, COO) included.
- After-Sales Support: Technical assistance available for integration questions. Replacement initiated within 48 hours for warranty claims.
Technical FAQ
Q: Is the CP6201-0001-0060 compatible with IndraWorks 14V22 and later?
A: Yes. The XM22 platform is supported by IndraWorks 12V12 through the current release. Always verify firmware compatibility with your specific IndraWorks version before commissioning.
Q: Can this unit run third-party SCADA software alongside the Rexroth PLC runtime?
A: Yes, provided the OS configuration supports concurrent applications. WinCC, iFIX, and Ignition have been validated on similar XM22 hardware. CPU and RAM headroom should be confirmed for your specific application.
Q: What is the recommended replacement for end-of-life CP6201 units?
A: Bosch Rexroth recommends migration to the IndraControl XM22 successor platforms (XM2x series). Konmask can assist with cross-reference and migration planning.
Q: Do you provide the original Bosch Rexroth documentation and software media?
A: Original manuals are available as PDF downloads from Bosch Rexroth’s documentation portal. We can provide links upon order confirmation. Licensed software must be obtained through Bosch Rexroth’s official channels.
Q: What export restrictions apply to this product?
A: The CP6201-0001-0060 may be subject to dual-use export controls (EAR/ECCN). Buyers are responsible for compliance with applicable export regulations in their jurisdiction. Konmask provides standard export documentation to facilitate customs clearance.
