Braun E1691 Power Supply Module – 24VDC Regulated Industrial PSU | Braun DCS Platform
Engineering Background: The Braun E1691 is a dedicated power supply module engineered for mission-critical distributed control system (DCS) architectures. Designed to deliver stable, regulated 24VDC power to field instruments, I/O modules, and communication backplanes, the E1691 addresses the demanding power integrity requirements of continuous-process industries including petrochemical, power generation, and advanced manufacturing.
Product Positioning: As a factory-original Braun component, the E1691 is the authoritative replacement and expansion PSU for Braun DCS installations. It is sourced directly from certified Braun distribution channels and verified against OEM specifications before shipment from Konmask.com. Procurement engineers specify the E1691 when system uptime, regulatory compliance, and long-term parts availability are non-negotiable.
Complete Technical Specifications
- Part Number / SKU: E1691
- Manufacturer: Braun
- Module Type: Regulated DC Power Supply Module
- Output Voltage: 24 VDC (regulated)
- Input Voltage Range: 85–264 VAC / 100–370 VDC (wide-range universal input)
- Output Current: Per OEM datasheet (contact Konmask for confirmed rating)
- Power Rating: Refer to OEM nameplate; typically 20–40 W class
- Isolation: Galvanic input-to-output isolation
- Protection: Overcurrent, overvoltage, short-circuit, thermal shutdown
- Mounting: DIN rail / backplane slot (Braun DCS rack compatible)
- Operating Temperature: 0°C to +60°C
- Storage Temperature: −40°C to +85°C
- Humidity: 5–95% RH, non-condensing
- Weight: 2,140 g (as shipped)
- Certifications: CE; compliant with applicable IEC/EN industrial safety standards
- Country of Origin: Refer to OEM label
Proven Application Environments
- Braun DCS distributed control system backplane power rails
- Process automation panels in oil & gas upstream/downstream facilities
- Power generation plant control rooms (coal, gas, nuclear auxiliary systems)
- Chemical and pharmaceutical batch/continuous process control
- Water treatment SCADA and remote I/O power distribution
- Advanced manufacturing MES-integrated control cabinets
- Redundant PSU configurations requiring hot-swap-capable modules
Engineering Advantages
- OEM-Identical Replacement: Drop-in fit for existing Braun DCS racks — no re-engineering or firmware changes required.
- Wide-Range AC/DC Input: Accepts global mains voltages and DC bus inputs, simplifying multi-site deployments.
- Galvanic Isolation: Eliminates ground loops and protects sensitive I/O from mains transients.
- Multi-Layer Protection: OCP, OVP, SCP, and thermal shutdown prevent cascade failures in high-availability systems.
- Compact Form Factor: Maximizes rack density without compromising thermal headroom.
- Long Service Life: Industrial-grade components rated for continuous 24/7 operation in harsh environments.
System Architecture & Signal Flow
The E1691 accepts wide-range AC or DC input via its terminal block, passes through an EMI filter stage, and converts to an isolated, regulated 24 VDC output bus. The output feeds the Braun DCS backplane power rail, supplying processor modules, I/O cards, and communication interfaces. Onboard status LEDs provide real-time power-good indication. In redundant configurations, two E1691 units operate in load-sharing mode; if one module faults, the second assumes full load without interruption — a critical feature for SIL-rated safety loops.
Sourcing & Quality Verification
- Origin: Sourced from authorized Braun distribution channels or certified industrial surplus with full traceability documentation.
- Inspection: Each unit undergoes visual inspection, label verification, and functional power-on test prior to dispatch.
- Packaging: Anti-static ESD bag + foam-lined carton; meets IEC 61340-5-1 handling requirements.
- Documentation: Certificate of conformity and test report available on request.
- Warranty: 12-month Konmask warranty against manufacturing defects; OEM warranty terms apply where applicable.
Procurement Process
- Confirm Compatibility: Verify your Braun DCS rack model and existing PSU slot configuration against the E1691 datasheet.
- Request Quote: Contact support@konmask.com for volume pricing, lead time, and availability confirmation.
- Place Order: Add to cart and complete checkout, or submit a purchase order via email for NET-30 terms (approved accounts).
- Shipping: DHL / FedEx / UPS international express; export documentation (commercial invoice, packing list, COO) included.
- Incoming Inspection: Konmask recommends a receiving inspection against the supplied test report before installation.
Technical FAQ
Q: Is the Braun E1691 compatible with my existing DCS rack without modification?
A: Yes — the E1691 is a factory-original module designed for direct slot replacement in compatible Braun DCS backplanes. No hardware or software modification is required.
Q: Can two E1691 units operate in a redundant (1+1) configuration?
A: Yes. The E1691 supports load-sharing redundancy. In the event of a single module failure, the remaining unit sustains full system power without interruption.
Q: What is the lead time for the Braun E1691?
A: In-stock units ship within 1–3 business days. For large-volume orders, contact Konmask for confirmed lead time.
Q: Do you provide a certificate of conformity?
A: Yes. A CoC and functional test report are available upon request at no additional charge.
Q: What export documentation is included?
A: Commercial invoice, packing list, country of origin certificate, and HS code declaration are standard with every international shipment.
