Discrete Control & Machine Automation Solution – DELTA DVP16SP11R | DVP-SS2 Series
Where This Product Is Used
The DELTA DVP16SP11R is a 16-point digital I/O expansion module engineered for demanding discrete control environments. It is widely deployed across the following industrial applications:
- Packaging Machinery – Coordinating conveyor sequencing, reject gates, and label applicators requiring fast, reliable relay switching.
- Injection Molding & Plastics – Managing mold open/close signals, ejector pin control, and safety interlock circuits.
- Food & Beverage Processing – Controlling filling valves, capping heads, and washdown-rated actuators in hygienic production lines.
- HVAC & Building Automation – Interfacing with damper actuators, fan starters, and alarm annunciators in BMS panels.
- Water Treatment & Pump Stations – Switching pump contactors, level switches, and solenoid valves in remote outstations.
- Textile & Printing Equipment – Synchronizing spindle drives, tension rollers, and registration sensors on high-speed web lines.
- General Machine OEM Panels – Any application requiring cost-effective I/O expansion on a DVP-series PLC backbone.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | DVP16SP11R |
| Series | DELTA DVP-SS2 |
| I/O Configuration | 8 Digital Inputs / 8 Digital Outputs |
| Output Type | Relay (Form A, NO contact) |
| Input Voltage | 24 VDC (sink/source compatible) |
| Output Rated Voltage | 250 VAC / 30 VDC |
| Output Rated Current | 2 A per point |
| Relay Mechanical Life | 10,000,000 operations (no load) |
| Relay Electrical Life | 100,000 operations (rated load) |
| Input Response Time | ≤ 10 ms (default filter) |
| Power Consumption | ≤ 3 W (module only) |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | -25 °C to 70 °C |
| Humidity | 5 % to 95 % RH (non-condensing) |
| Mounting | DIN rail (35 mm) or panel mount |
| Dimensions (W × H × D) | Approx. 90 × 90 × 74 mm |
| Weight | Approx. 200 g |
| Protection Class | IP20 |
| Communication Interface | DVP expansion bus (right-side connector) |
| Compatible CPU Series | DVP-SS2, DVP-SE, DVP-SX2, DVP-EH3 |
Why Engineers Specify This Model
- Relay Output Versatility – Drives both AC and DC loads without external interface relays, reducing panel component count and wiring cost.
- Compact Footprint – Slim DIN-rail profile allows dense I/O expansion in space-constrained enclosures.
- Plug-and-Play Expansion – Connects directly to the DVP CPU right-side bus; no additional power supply or communication card required.
- High Noise Immunity – Optocoupler-isolated inputs withstand harsh EMI environments typical of motor-drive-heavy panels.
- Long Relay Service Life – 10 million mechanical operations ensure multi-year service without relay replacement in moderate-duty cycles.
- Wide Load Compatibility – 2 A / 250 VAC per output point handles most solenoid valves, contactors, and indicator lamps directly.
- Cost-Effective Scaling – Lower per-point cost versus integrated CPU I/O when expanding beyond the base unit’s native points.
Complete System Bill of Materials
A typical DVP-SS2 discrete control panel incorporating the DVP16SP11R may include the following components (all available at Konmask.com):
- DVP20SX211R – DVP-SS2 CPU unit (20-point, relay output) — main controller
- DVP16SP11R – This module — 16-point digital I/O expansion
- DVP04AD-S – 4-channel analog input module — process variable acquisition
- DVP02DA-S – 2-channel analog output module — control signal generation
- DVP-F232 – RS-232 communication card — HMI or SCADA interface
- WPL Soft – DELTA PLC programming software (free download)
- 24 VDC DIN Rail PSU – e.g., DELTA DRP024V060W1AZ — system power supply
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive (LVD) 2014/35/EU and EMC Directive 2014/30/EU.
- UL Listed – Recognized under UL 508 (Industrial Control Equipment) for North American markets.
- RoHS Compliant – Free of restricted hazardous substances per EU Directive 2011/65/EU.
- IEC 61131-2 – Programmable controller hardware conformance for input/output characteristics.
- IP20 Enclosure Rating – Protected against solid objects > 12 mm; suitable for installation inside control cabinets.
Quality Assurance & Sourcing
Konmask.com sources the DVP16SP11R exclusively through authorized DELTA Electronics distribution channels and verified industrial surplus networks. Every unit dispatched undergoes our internal 4-step verification protocol:
- Visual Inspection – Label authenticity, housing integrity, connector pin condition, and date-code consistency checked against DELTA factory standards.
- Functional Power-On Test – Module energized and I/O points exercised to confirm correct input response and relay actuation.
- Documentation Match – Serial number and firmware revision cross-referenced against DELTA’s product database where accessible.
- Packaging & ESD Protection – Units re-packed in anti-static bags with desiccant before shipment to prevent transit damage.
How to Source This Part
- Add to Cart – Click the purchase button above to place your order directly.
- Request a Quote – For quantities ≥ 5 units or project BOM pricing, email support@konmask.com with your required quantity and delivery timeline.
- Expedited Sourcing – If the item shows as out of stock, contact us via WhatsApp/WeChat at +0086 19859288691; we maintain relationships with multiple DELTA distributors globally and can typically source within 3–7 business days.
- Lead Time – In-stock orders ship within 1–2 business days. International express (DHL / FedEx) available to 150+ countries.
- Payment – T/T bank transfer, PayPal, credit card, and Western Union accepted.
Application-Specific FAQ
Q: Can the DVP16SP11R be used with DVP-EH3 series CPUs?
A: Yes. The DVP16SP11R is compatible with DVP-EH3, DVP-SX2, DVP-SE, and DVP-SS2 CPUs via the standard right-side expansion bus. Always verify the maximum expansion module count for your specific CPU model in the DELTA hardware manual.
Q: How many DVP16SP11R modules can be connected to one CPU?
A: The maximum number of expansion modules depends on the CPU model. For DVP-SS2 CPUs, up to 8 expansion modules are typically supported. Refer to the CPU datasheet for the exact limit and total I/O point constraints.
Q: Are the relay outputs suitable for driving 3-phase motor starters directly?
A: No. The 2 A / 250 VAC relay contacts are rated for control-circuit loads only. For motor starter coils above 2 A, interpose an auxiliary relay or contactor between the DVP16SP11R output and the motor starter coil.
Q: What is the input filter time and can it be changed?
A: The default input filter time is ≤ 10 ms. On DVP-SS2 CPUs, the filter time for specific input points can be adjusted via special data registers (D1020–D1031) in the WPL Soft program to values as low as 1 ms for high-speed sensing applications.
Q: Does Konmask provide a warranty on this module?
A: Yes. All modules sold by Konmask.com carry a 90-day functional warranty. If a unit fails under normal operating conditions within the warranty period, we will replace or refund at our discretion. Contact support@konmask.com with your order number and fault description.
Q: Can you supply the DELTA WPL Soft programming cable alongside this module?
A: Yes. We stock the DVP-USB programming cable and can bundle it with your order. Mention this in your order notes or contact us before checkout.
