Factory Automation & Embedded Computing Solution – DFI EL620-C | EL620 Series
The DFI EL620-C is a compact, high-reliability industrial motherboard built on the Intel Apollo Lake platform (Celeron N3350). Engineered for 24/7 continuous operation in harsh industrial environments, it delivers stable embedded computing performance for machine control, HMI, and edge intelligence applications.
Where This Product Is Used
- Factory Automation & PLC Integration: Serves as the computing core in automated production lines, coordinating with PLCs (Siemens S7, Mitsubishi Q/FX, Allen-Bradley) via serial and Ethernet interfaces.
- HMI & Operator Panels: Powers touch-screen operator interfaces in CNC machining centers, injection molding machines, and packaging equipment.
- Machine Vision Systems: Provides the processing backbone for inline quality inspection cameras and barcode/OCR reading stations.
- Edge Computing & IoT Gateways: Deployed as an edge node for data acquisition, protocol conversion (Modbus/OPC-UA), and local analytics in smart factory environments.
- Digital Signage & Kiosk Systems: Used in industrial kiosks, self-service terminals, and information display systems requiring fanless, low-maintenance operation.
- Transportation & In-Vehicle Computing: Suitable for vehicle-mounted computing in AGVs, forklifts, and rail applications thanks to wide-voltage input support.
Technical Specifications
- Model: DFI EL620-C
- Series: EL620
- Form Factor: 3.5-inch SBC (Single Board Computer)
- Processor: Intel Celeron N3350 (Apollo Lake, dual-core, up to 2.4 GHz)
- Memory: 1× DDR3L SO-DIMM, up to 8 GB
- Storage: 1× mSATA, 1× M.2 2242 (SATA), 1× CFast slot
- Display Output: 1× VGA, 1× LVDS (dual independent display)
- Ethernet: 2× Intel GbE LAN (i211AT)
- USB: 2× USB 3.0, 4× USB 2.0
- Serial I/O: 2× RS-232/422/485 (software selectable)
- Expansion: 1× Mini PCIe (full-size), 1× SIM card slot
- GPIO: 8-bit digital I/O
- Operating Temperature: -20°C to +70°C (wide-temp)
- Power Input: DC 12V (AT/ATX mode selectable)
- Dimensions: 146 × 102 mm
- OS Support: Windows 10 IoT Enterprise, Linux (Ubuntu/Debian)
- Watchdog Timer: Yes (programmable)
- TPM: TPM 2.0 (optional)
Why Engineers Specify This Model
- Wide Operating Temperature (-20°C ~ +70°C): Handles foundry floors, cold-chain warehouses, and outdoor enclosures without active cooling.
- Fanless-Ready Design: Low TDP Apollo Lake SoC enables fully passive thermal solutions, eliminating fan failure as a maintenance concern.
- Dual Independent Display: VGA + LVDS outputs allow simultaneous operator HMI and supervisory dashboard on separate screens.
- Flexible Serial I/O: RS-232/422/485 software-selectable ports connect directly to legacy PLCs, drives, and sensors without external converters.
- Long Product Lifecycle: DFI guarantees 5+ year supply continuity — critical for OEM machine builders who cannot afford mid-cycle redesigns.
- Compact 3.5-inch Form Factor: Fits into tight control cabinet spaces while delivering full PC-class computing capability.
Complete System Bill of Materials
For a complete embedded computing system based on the EL620-C, engineers typically specify:
- DFI EL620-C — Main processing board (this item)
- DDR3L 4GB/8GB SO-DIMM module (1.35V, industrial grade)
- Industrial mSATA SSD (MLC/SLC, -40°C~+85°C rated)
- 12V DC industrial power supply (DIN-rail mount, 60W+)
- Passive heatspreader / fanless chassis (e.g., Cincoze, Axiomtek compatible)
- Mini PCIe Wi-Fi / 4G LTE module (optional, for IoT gateway use)
- Industrial-grade LVDS panel or VGA monitor
Compliance & Industry Standards
- CE Marking (EMC Directive 2014/30/EU)
- FCC Part 15 Class B
- RoHS 2 Compliant (2011/65/EU)
- BSMI (Taiwan)
- IEC 60068-2 Vibration & Shock tested
- Operating Humidity: 10% ~ 90% RH (non-condensing)
Quality Assurance & Sourcing
All DFI EL620-C units supplied by Konmask.com are sourced through authorized industrial distribution channels. Each unit undergoes incoming inspection including:
- Visual inspection for physical integrity and label verification
- Power-on POST (Power-On Self-Test) validation
- Serial number traceability against manufacturer records
- Anti-static packaging with humidity indicator cards
We do not supply grey-market, refurbished, or counterfeit components. Certificate of Conformance (CoC) available upon request.
How to Source This Part
- In-Stock Orders: Add to cart and complete checkout — ships within 1–3 business days from our warehouse.
- Bulk / OEM Procurement: Contact support@konmask.com for volume pricing, lead-time confirmation, and blanket order arrangements.
- Urgent Requirements: Call or WhatsApp +0086 19859288691 for same-day quotation on critical production line needs.
- Custom Configuration: We can assist with memory pre-installation, OS imaging, and BIOS customization for OEM deployments.
Application-Specific FAQ
Q: Can the EL620-C communicate directly with a Siemens S7-1200 PLC?
A: Yes. Use the onboard GbE port with PROFINET or S7 TCP/IP protocol libraries (e.g., Snap7). RS-485 port supports Modbus RTU to legacy S7-200 via USS protocol.
Q: Is the EL620-C suitable for a fanless enclosure?
A: Yes. The Intel Celeron N3350’s 6W TDP allows passive cooling via a heatspreader chassis. Verify thermal solution with your enclosure vendor for ambient temperatures above 50°C.
Q: What is the maximum storage capacity?
A: mSATA supports up to 2TB (SATA III), M.2 2242 supports up to 512GB. CFast slot supports industrial CFast cards up to 256GB.
Q: Does it support Windows 10 IoT Enterprise LTSC?
A: Yes. DFI provides validated BSP (Board Support Package) drivers for Windows 10 IoT Enterprise LTSC 2019 and 2021.
Q: Can I use this board in a -40°C cold storage environment?
A: The standard EL620-C is rated to -20°C. For -40°C operation, contact us regarding the extended-temp variant or conformal coating options.
