eiuie CPCI-6840V – High-Performance CompactPCI Serial Processor Board | CompactPCI Serial Platform
Engineering Background
The eiuie CPCI-6840V is a CompactPCI Serial (CPCI-S.0) compliant processor board engineered for demanding industrial embedded computing environments. Designed to meet the rigorous requirements of defense, telecommunications, transportation, and industrial automation sectors, the CPCI-6840V delivers deterministic performance within a standardized, hot-swap-capable chassis ecosystem.
Product Positioning
Targeted at procurement engineers and system integrators who require a proven, long-lifecycle processor module, the CPCI-6840V occupies the high-reliability segment of the CompactPCI Serial market. It serves as a system controller (System Slot) or peripheral slot CPU in multi-board CPCI-S.0 backplane architectures, enabling scalable, modular control system design without proprietary lock-in.
Complete Technical Specifications
- Model / SKU: CPCI-6840V
- Manufacturer: eiuie
- Form Factor: CompactPCI Serial (CPCI-S.0), 3U
- Bus Standard: CompactPCI Serial (PCIe-based backplane fabric)
- Slot Compatibility: System Slot / Peripheral Slot
- Processor Architecture: x86-64 embedded processor (contact sales for current CPU variant)
- Memory: DDR SDRAM (capacity per configuration)
- Storage Interface: SATA / mSATA / CFast (configuration dependent)
- I/O Interfaces: USB, GbE LAN, RS-232/422/485 serial, GPIO
- Expansion: PMC / XMC mezzanine site (configuration dependent)
- Operating Temperature: -40°C to +85°C (extended industrial range)
- Power Supply: Supplied via CPCI-S.0 backplane connector
- Weight: 1,600 g (board + heatsink assembly)
- Compliance: PICMG CPCI-S.0, CE, RoHS
- MTBF: >100,000 hours at 25°C (Telcordia SR-332)
Proven Application Environments
- Industrial Automation & Process Control: Real-time PLC/DCS gateway processing, SCADA front-end controllers, and high-speed data acquisition in factory automation lines.
- Railway & Transportation: Onboard computing for train control management systems (TCMS), wayside monitoring units, and passenger information systems requiring EN 50155 environmental compliance.
- Defense & Aerospace: Ruggedized command-and-control subsystems, signal intelligence (SIGINT) processing nodes, and mission computer upgrades within existing CPCI chassis infrastructure.
- Telecommunications: Carrier-grade media gateways, protocol conversion platforms, and network element controllers in NEBS-compliant 19″ rack systems.
- Test & Measurement: Automated test equipment (ATE) controller boards requiring deterministic I/O timing and long-term platform availability.
Engineering Advantages
- CPCI-S.0 Serial Fabric: PCIe-based backplane interconnect delivers significantly higher bandwidth than legacy parallel CPCI, enabling multi-gigabit inter-board communication without external cabling.
- Hot-Swap Capability: Full PICMG hot-swap support allows board replacement without system shutdown, critical for 24/7 industrial and telecom deployments.
- Extended Temperature Range: -40°C to +85°C operation without derating ensures reliable deployment in outdoor enclosures, vehicle-mounted systems, and non-climate-controlled industrial cabinets.
- Long Product Lifecycle: eiuie commits to extended availability windows aligned with industrial procurement cycles, reducing obsolescence risk for 10+ year system designs.
- Mezzanine Expandability: PMC/XMC site enables field-customizable I/O expansion (FPGA, additional serial ports, analog I/O) without board redesign.
System Architecture & Signal Flow
The CPCI-6840V operates as the system controller within a CPCI-S.0 backplane. The on-board processor communicates with peripheral boards via the PCIe fabric routed through the backplane’s J1/J2 connectors. Local I/O (USB, GbE, serial) is accessible via the front panel. The board supports IPMI-compliant baseboard management for remote health monitoring, fan control, and out-of-band management via the IPMB bus on the backplane.
Signal Flow Summary: Host CPU ↔ PCIe Root Complex ↔ CPCI-S.0 Backplane Fabric ↔ Peripheral Slot Boards (I/O, FPGA, DSP) ↔ Field Devices / Sensors / Actuators
Sourcing & Quality Verification
- Origin: Sourced directly from authorized eiuie distribution channels and verified OEM supply chains.
- Inspection: Every unit undergoes incoming inspection including visual examination, functional power-on test, and serial number verification against manufacturer records.
- Authenticity: Konmask.com maintains full traceability documentation. Counterfeit-free guarantee backed by supplier audit records.
- Condition: New (factory-sealed) and refurbished (tested, warranted) options available — specify at inquiry.
- Warranty: 12-month replacement warranty on all units shipped from Konmask.com stock.
Procurement Process
- Submit RFQ: Contact [email protected] with quantity, required delivery date, and any configuration requirements.
- Quotation: Receive a formal quotation with unit price, lead time, and shipping options within 1 business day.
- Order Confirmation: Issue PO or place order directly on Konmask.com. Payment via T/T, credit card, or approved net terms.
- Inspection & Dispatch: Unit inspected, serialized, and shipped with full documentation (datasheet, test report, packing list).
- Delivery: DHL / FedEx express worldwide. Export documentation (commercial invoice, packing list, CO) provided for customs clearance.
Technical FAQ
Q: Is the CPCI-6840V compatible with legacy parallel CompactPCI backplanes?
A: No. The CPCI-6840V uses the CompactPCI Serial (CPCI-S.0) standard, which is electrically incompatible with legacy CPCI (PCI-based) backplanes. Verify your chassis specification before ordering.
Q: What operating systems are supported?
A: VxWorks, Linux (PREEMPT_RT), QNX, and Windows Embedded are validated. Contact eiuie or Konmask.com for BSP availability for your target OS.
Q: Can the board operate as a peripheral slot CPU (non-system-slot)?
A: Yes, subject to backplane topology and chassis system slot assignment. Confirm with your chassis vendor.
Q: What is the minimum order quantity (MOQ)?
A: MOQ is 1 unit. Volume pricing available for orders of 5+ units.
Q: Do you provide export licenses for restricted destinations?
A: Konmask.com complies with all applicable export control regulations. Customers in controlled destinations must provide end-user declarations prior to shipment.
