Motion Control & Servo Automation Solution — ELMO 1080-01514 G-BAS3/230FEHN-A3 | Gold Series
Where This Product Is Used
The ELMO 1080-01514 G-BAS3/230FEHN-A3 servo drive is engineered for high-precision motion control in demanding industrial environments. Typical deployment scenarios include:
- Semiconductor & Electronics Manufacturing — wafer handling, pick-and-place machines, and precision stage positioning where sub-micron repeatability is critical.
- Robotics & Collaborative Arms — joint-level torque and velocity control in multi-axis robotic cells requiring real-time network synchronization.
- Medical & Laboratory Automation — surgical robots, diagnostic imaging gantries, and lab automation platforms demanding ultra-low noise and high reliability.
- Aerospace & Defense Test Rigs — flight simulator actuators, antenna positioning systems, and structural test benches operating under MIL-grade conditions.
- CNC Machining & Grinding — spindle and feed-axis drives in high-speed machining centers where thermal stability and dynamic stiffness are paramount.
- VME-Based Control Systems — legacy and modern VME backplane architectures (cross-reference: VME-7671-421000) requiring compact, high-power-density servo solutions.
Technical Specifications
- Manufacturer: ELMO Motion Control
- Primary Part Number: 1080-01514
- Model / Variant: G-BAS3/230FEHN-A3
- Series: Gold Series Servo Drive
- Cross-Reference Part Numbers: VME-7671-421000 | 605-048878-001 | 200877 | IC-KP2-2HB17-2V1D
- Drive Type: Digital Servo Drive (current/torque/velocity/position modes)
- Input Voltage: 230 V AC (as indicated by /230 suffix)
- Form Factor: Compact module, VME-compatible footprint
- Communication Interface: CANopen / EtherCAT (Gold Series standard)
- Feedback Support: Encoder, resolver, Hall sensors
- Protection Class: Short-circuit, over-voltage, over-temperature, under-voltage
- Condition: New / Refurbished / Tested — confirmed functional before shipment
Why Engineers Specify This Model
- Multi-mode operation — seamlessly switches between torque, velocity, and position control without hardware changes, reducing BOM complexity.
- High power density — the G-BAS3 Gold Series packs industry-leading continuous current output into a compact VME-compatible form factor.
- Advanced motion algorithms — ELMO’s proprietary servo algorithms deliver superior disturbance rejection and minimal following error at high speeds.
- Network-ready — native CANopen and EtherCAT support enables plug-in integration with Beckhoff, Siemens, and Rockwell master controllers.
- Proven cross-platform compatibility — validated against VME-7671-421000 and IC-KP2-2HB17-2V1D reference designs, reducing qualification risk.
- Long service life — ELMO Gold Series drives are rated for continuous industrial duty with MTBF exceeding 50,000 hours under rated conditions.
Complete System Bill of Materials
For a fully operational servo axis using this drive, engineers typically specify:
- ELMO 1080-01514 G-BAS3/230FEHN-A3 — Servo Drive (this unit)
- Compatible ELMO Gold Series servo motor (matched to drive current rating)
- Encoder cable assembly (shielded, twisted-pair, per ELMO wiring guide)
- 24 VDC logic power supply (isolated)
- 230 VAC power filter / EMC choke (per CE/UL installation requirements)
- EtherCAT or CANopen master controller (e.g., Beckhoff CX series, Siemens S7-1500T)
- ELMO Application Studio II (EASI) software — free download from ELMO website
- VME backplane chassis (if deploying in VME-7671-421000 configuration)
Compliance & Industry Standards
- CE Marking — Low Voltage Directive (LVD) 2014/35/EU & EMC Directive 2014/30/EU
- UL / cUL Listed — industrial control equipment per UL 508C
- RoHS Compliant — Directive 2011/65/EU (restriction of hazardous substances)
- IEC 61800-5-1 — adjustable speed electrical power drive systems safety requirements
- CANopen DS402 — drives and motion control device profile
- EtherCAT (IEC 61158) — real-time industrial Ethernet standard
Quality Assurance & Sourcing
At Konmask.com, every servo drive undergoes a rigorous pre-shipment process:
- Visual inspection — PCB, connectors, and housing checked for damage, corrosion, or counterfeit indicators.
- Functional power-on test — drive is energized and communication interface verified before packaging.
- Authenticity verification — part markings, date codes, and serial numbers cross-checked against manufacturer records.
- Anti-static packaging — shipped in ESD-safe bags with foam cushioning and moisture barrier.
- Traceability documentation — test report and sourcing certificate available upon request.
How to Source This Part
- Add to Cart — click the purchase button above to place your order directly.
- Request a Quote — for volume orders (>5 units) or urgent requirements, email [email protected] for a dedicated quote within 4 business hours.
- Lead Time — in-stock units ship within 1–2 business days; out-of-stock units sourced within 5–15 business days depending on origin.
- Global Shipping — DHL Express, FedEx International Priority, and UPS Worldwide available. Export documentation (commercial invoice, packing list, COO) included.
- Payment — T/T bank transfer, PayPal, credit card, and Alibaba Trade Assurance accepted.
Application-Specific FAQ
Q: Is the G-BAS3/230FEHN-A3 a direct replacement for IC-KP2-2HB17-2V1D?
A: Yes. The IC-KP2-2HB17-2V1D is a recognized cross-reference for this ELMO Gold Series drive. Verify connector pinout and firmware version compatibility before installation.
Q: Can this drive operate on 208 V AC (North American industrial standard)?
A: The /230 suffix indicates nominal 230 V AC input. Operation at 208 V is typically within tolerance; consult the ELMO G-BAS3 datasheet for exact input voltage range (usually ±10%).
Q: What software is required for commissioning?
A: ELMO Application Studio II (EASI) is the standard commissioning tool. It is available as a free download from the ELMO Motion Control website and supports all Gold Series drives.
Q: Is a warranty provided?
A: Konmask provides a 90-day functional warranty on all tested units. Extended warranty options are available — contact us for details.
Q: Can you supply the VME-7671-421000 chassis or other system components?
A: Yes. Konmask specializes in complete automation system sourcing. Contact us with your full BOM for a consolidated quote.
