EMERSON KJ3001X1-BG1 Digital Output 24 VDC Isolated | Replacement, Equivalent & Selection Guide
The EMERSON KJ3001X1-BG1 (Part No. 12P0557X162) is a Digital Output (DO) module designed for the DeltaV Distributed Control System (DCS). It provides 24 VDC isolated discrete output channels, enabling reliable field device control in process automation environments. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams.
Technical Specifications
- Manufacturer: Emerson Electric / Fisher-Rosemount
- Part Number: KJ3001X1-BG1
- Reference Number: 12P0557X162
- Module Type: Digital Output (DO)
- Output Voltage: 24 VDC
- Isolation: Galvanically isolated outputs
- Platform: Emerson DeltaV DCS
- Form Factor: DeltaV I/O card (standard carrier-mounted)
- Communication: DeltaV I/O bus
- Operating Temperature: 0°C to 60°C (typical DeltaV I/O spec)
- Weight: Approx. 200 g
- Compliance: CE, UL (subject to revision; verify with datasheet)
Compatible Replacement & Equivalent Models
The following modules are functionally equivalent or drop-in compatible replacements for the KJ3001X1-BG1 in DeltaV systems. Always verify firmware revision and carrier compatibility before substitution.
- KJ3001X1-BA1 — Earlier revision of the same DO 24 VDC isolated module; functionally equivalent in most DeltaV configurations
- KJ3001X1-BB1 — Intermediate revision; compatible with same carrier and I/O bus
- KJ3001X1-BC1 / BD1 / BE1 / BF1 — Progressive hardware revisions; same electrical specification
- KJ3002X1-BA1 — DO module with different channel count; verify channel requirements before substitution
- VE3008 (Emerson CHARM DO) — CHARM-based isolated DO for DeltaV S-series; requires CHARM I/O card infrastructure
- Third-party DeltaV-compatible DO modules — Contact Konmask for vetted alternatives
Note: Revision suffixes (BA1, BB1, BG1, etc.) indicate hardware revisions. Confirm compatibility with your DeltaV system version and I/O carrier before ordering.
Why Choose the Original Model
- Guaranteed DeltaV Compatibility: Factory-validated for seamless integration with Emerson DeltaV controllers and I/O subsystems
- Galvanic Isolation: Protects control system from field-side voltage transients and ground loops
- Proven Field Reliability: Widely deployed in oil & gas, chemical, power, and pharmaceutical process plants
- OEM Support: Eligible for Emerson lifecycle support, firmware updates, and warranty coverage
- Regulatory Compliance: Meets international safety and EMC standards for industrial control environments
Typical Applications
- Solenoid valve control in process piping systems
- Motor starter and contactor switching via DCS
- On/off control of pumps, fans, and actuators
- Alarm annunciator and indicator lamp outputs
- Discrete interlock and safety shutdown outputs
- Batch process step sequencing in pharmaceutical and food & beverage plants
System Compatibility
- DCS Platform: Emerson DeltaV (all generations supporting standard I/O cards)
- Controller Compatibility: DeltaV MD, MD Plus, MQ, PK, SD, SX controllers
- I/O Carrier: Standard 8-slot and 2-slot DeltaV I/O carriers
- Power Supply: DeltaV I/O bus powered (no separate field power required for module logic)
- Field Wiring: 24 VDC field supply required for output loads
- Not Compatible With: DeltaV CHARM I/O subsystem (requires CHARM-specific DO modules)
Selection Guide
Use the following criteria to confirm the KJ3001X1-BG1 is the correct module for your application:
- Step 1 — Output Type: Confirm discrete (on/off) output is required (not analog)
- Step 2 — Voltage: Confirm field devices operate at 24 VDC
- Step 3 — Isolation Requirement: Confirm isolated outputs are needed (vs. non-isolated DO modules)
- Step 4 — Channel Count: Verify the number of DO channels required matches this module’s specification
- Step 5 — Carrier Slot: Confirm available I/O carrier slots in your DeltaV cabinet
- Step 6 — Revision: Check your DeltaV system’s supported hardware revision list; BG1 is a later revision and may require updated firmware
- Step 7 — Spare vs. Active: For active replacement, ensure the module is commissioned and downloaded in DeltaV Explorer
Quality Assurance & Sourcing
- All modules sourced by Konmask.com are inspected for physical integrity, label authenticity, and functional condition prior to listing
- Surplus and refurbished units are clearly identified; new-in-box (NIB) units are available upon request
- Traceability documentation (original packaging, serial numbers) provided where available
- We do not sell counterfeit or grey-market parts; all inventory is sourced from verified industrial surplus channels
- Export compliance: buyers are responsible for verifying import regulations in their jurisdiction
How to Order
- Online: Add to cart directly from this page
- Email RFQ: support@konmask.com — include part number, quantity, and required delivery date
- Phone/WhatsApp: +0086 19859288691
- Lead Time: In-stock items ship within 1–3 business days; sourced items subject to availability
- Payment: T/T (wire transfer), PayPal, and other methods available — contact us for details
- Shipping: Worldwide shipping via DHL, FedEx, UPS, and EMS
Replacement & Compatibility FAQ
Q: Can I use a lower revision (e.g., BA1) to replace a BG1?
A: In most cases yes, as the electrical specification is identical. However, confirm with your DeltaV system’s hardware compatibility matrix, as some controller firmware versions may flag revision mismatches.
Q: Is the KJ3001X1-BG1 compatible with DeltaV S-series (CHARM)?
A: No. CHARM-based systems require CHARM DO modules (e.g., VE3008). The KJ3001X1-BG1 is for traditional DeltaV I/O carriers only.
Q: What is the difference between isolated and non-isolated DO modules?
A: Isolated modules provide galvanic separation between the control system and field wiring, protecting against ground loops and voltage transients. Non-isolated modules share a common ground with the field side.
Q: Can Konmask provide a test report or functional verification?
A: Yes, functional testing can be arranged for refurbished units. Contact us with your requirements.
Q: Do you offer volume discounts for multiple units?
A: Yes. Contact us via email or phone for volume pricing on orders of 3+ units.
