EMERSON VE4003S2B6 KJ3223X1-BA1 12P2871X042 AI 16-Channel 4-20mA HART Input Card | Replacement, Equivalent & Selection Guide
The EMERSON VE4003S2B6 (also referenced as KJ3223X1-BA1 / 12P2871X042) is a 16-channel analog input card designed for the DeltaV™ Distributed Control System. It accepts 4–20 mA signals with full HART protocol support, enabling simultaneous process variable acquisition and digital HART communication on every channel. Konmask.com supplies genuine and compatible replacement units with full traceability.
Technical Specifications
- Part Numbers: VE4003S2B6 / KJ3223X1-BA1 / 12P2871X042
- Brand / Manufacturer: Emerson (Fisher-Rosemount / DeltaV)
- Module Type: Analog Input (AI)
- Channels: 16 channels
- Signal Range: 4–20 mA
- Protocol: HART (Highway Addressable Remote Transducer)
- Resolution: 16-bit ADC
- Isolation: Channel-to-channel and channel-to-bus isolation
- Power Consumption: Supplied via DeltaV carrier/backplane
- Operating Temperature: 0 °C to 60 °C
- Mounting: DeltaV M-Series or S-Series carrier
- Certifications: CE, FM, ATEX (refer to datasheet for specific approvals)
- Weight: Approx. 120 g
Compatible Replacement & Equivalent Models
When the VE4003S2B6 is unavailable or end-of-life, the following models are commonly evaluated as replacements or equivalents. Always verify firmware compatibility and carrier slot requirements before substitution.
- VE4003S2T2 – Functionally equivalent AI 16-CH HART variant; different terminal block style
- KJ3223X1-BB1 – Revised BOM revision of the same card family
- VE4001S2T2B2 – 8-CH AI HART card; use two units to replace one 16-CH card
- VE4005S2B2 – AI 16-CH non-HART variant; suitable where HART is not required
- Third-party DeltaV-compatible AI modules – Contact Konmask for validated alternatives
Note: Cross-referencing part numbers does not guarantee drop-in compatibility. Consult Emerson documentation or contact our engineers before ordering a replacement.
Why Choose the Original Model
- Full HART Pass-Through: Simultaneous 4-20 mA process value and HART digital communication on all 16 channels without multiplexing delays
- Native DeltaV Integration: Plug-and-play with DeltaV M-Series and S-Series carriers; auto-recognized by DeltaV Explorer
- High Channel Density: 16 channels per slot reduces carrier space and wiring cost vs. 8-CH alternatives
- Proven Field Reliability: Widely deployed in oil & gas, chemical, and power generation facilities globally
- Emerson Lifecycle Support: Firmware updates, spare parts, and technical support available through Emerson’s global service network
Typical Applications
- Oil & gas upstream/midstream/downstream process control
- Chemical and petrochemical plant DCS integration
- Power generation boiler and turbine control loops
- Pharmaceutical batch process monitoring
- Water and wastewater treatment plant automation
- Pulp and paper mill process control
System Compatibility
- DCS Platform: Emerson DeltaV™ (M-Series, S-Series, MD-Series controllers)
- Carrier Types: 2-wide, 4-wide, 8-wide DeltaV I/O carriers
- DeltaV Software: Compatible with DeltaV v11.x and later (verify with Emerson for legacy versions)
- HART Version: HART 5 and HART 7 field devices
- Not Compatible With: Ovation™, PLC-based systems, or non-DeltaV carrier backplanes
Selection Guide
Use the table below to select the right AI card for your DeltaV system:
- Need 16 CH + HART? → VE4003S2B6 (this model) ✓
- Need 16 CH, no HART? → VE4005S2B2
- Need 8 CH + HART? → VE4001S2T2B2
- Need intrinsically safe (IS) channels? → VE4003S2T2 with IS barriers
- Need redundant AI? → Pair with DeltaV redundant carrier; contact Konmask for configuration
Not sure which model fits your system? Email our engineers with your DeltaV controller model and I/O carrier part number for a free selection recommendation.
Quality Assurance & Sourcing
- Genuine Parts: Sourced from authorized distributors and verified Emerson supply chains
- Inspection: Each unit undergoes visual inspection, label verification, and functional pre-check before shipment
- Traceability: Full lot traceability documentation available on request
- Warranty: 12-month warranty against manufacturing defects
- Anti-Counterfeit: Holographic labels and serial number verification provided
How to Order
- Online: Add to cart directly on this page at Konmask.com
- Email RFQ: [email protected] — include quantity, required delivery date, and destination country
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 1–3 business days; sourced units 5–15 business days
- Shipping: DHL, FedEx, UPS worldwide; export documentation included
- Payment: T/T, PayPal, credit card, and LC accepted
Replacement & Compatibility FAQ
Q: Can VE4003S2B6 replace KJ3223X1-BA1 directly?
A: Yes — VE4003S2B6 and KJ3223X1-BA1 are cross-reference part numbers for the same card. They are interchangeable.
Q: Is 12P2871X042 the same as VE4003S2B6?
A: Yes — 12P2871X042 is the Emerson internal manufacturing part number. All three numbers refer to the same physical module.
Q: Can I use this card in a non-DeltaV system?
A: No. This card is designed exclusively for the DeltaV I/O bus architecture and will not function in other DCS or PLC platforms.
Q: Does this card support HART 7?
A: Yes, with appropriate DeltaV firmware version. Confirm your DeltaV version supports HART 7 pass-through before installation.
Q: What is the difference between VE4003S2B6 and VE4003S2T2?
A: The primary difference is the terminal block connector style (B = barrier strip, T = spring-clamp terminal). Functionality and channel count are identical.
