Precision Motion Control Solution – ETEL DSCDL332-131D-000A | DSCDL332 Series
Where This Product Is Used
The ETEL DSCDL332-131D-000A is a high-performance servo drive control board engineered for demanding industrial motion control environments. It is widely deployed in:
- CNC Machining Centers – Provides closed-loop axis control for multi-axis milling, turning, and grinding machines requiring sub-micron positioning accuracy.
- Industrial Robotics – Serves as the drive intelligence layer in articulated robot arms and SCARA systems where dynamic torque response is critical.
- Semiconductor & Flat Panel Display Equipment – Used in wafer handling stages and lithography systems demanding ultra-low vibration and high-speed trajectory control.
- Medical Imaging & Surgical Robotics – Integrated into CT gantry drives and robotic surgical platforms requiring IEC-compliant, fault-tolerant motion.
- Precision Test & Measurement Systems – Deployed in automated test equipment (ATE) and coordinate measuring machines (CMM) for repeatable, high-resolution positioning.
- Printing & Packaging Machinery – Controls web tension and registration in high-speed printing lines and form-fill-seal packaging systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | DSCDL332-131D-000A |
| Manufacturer | ETEL S.A. |
| Series | DSCDL332 |
| Product Type | Servo Drive Control Board |
| Function | Digital servo drive controller / motion control board |
| Compatible Drive Family | ETEL DSCDL / DSCL servo drive series |
| Interface | Digital fieldbus (EtherCAT / proprietary ETEL bus) |
| Axis Support | Single-axis or multi-axis configuration (system-dependent) |
| Weight | 3,900 g (approx.) |
| Condition | New / Refurbished / Tested (specify at inquiry) |
| Origin | Switzerland (ETEL S.A.) |
Note: Full electrical specifications (voltage, current rating, encoder interface) are available upon request. Contact our technical team for datasheet access.
Why Engineers Specify This Model
- ETEL Pedigree: ETEL S.A. (Switzerland) is a Heidenhain Group company renowned for direct-drive motors and precision servo systems used in the world’s most demanding motion applications.
- DSCDL332 Series Architecture: The DSCDL332 platform delivers deterministic real-time control with advanced current loop bandwidth, making it suitable for high-dynamic-response applications.
- Drop-in Replacement Compatibility: The -131D-000A variant is a direct board-level replacement for existing ETEL DSCDL332 drive systems, minimizing downtime during maintenance or repair.
- Fieldbus Flexibility: Supports integration with EtherCAT and ETEL’s proprietary communication bus, enabling seamless connection to Beckhoff, Siemens, and other PLC platforms.
- Fault Diagnostics: Onboard diagnostic LEDs and status registers enable rapid fault isolation, reducing mean time to repair (MTTR) in production environments.
Complete System Bill of Materials
For a complete ETEL servo drive system, the following components are typically required alongside the DSCDL332-131D-000A control board:
- ETEL DSCDL332 series servo drive chassis / power stage
- ETEL linear or rotary direct-drive motor (ILF / TMA / LMSP series)
- Heidenhain or ETEL encoder feedback module
- EtherCAT master controller (e.g., Beckhoff CX series IPC)
- 24 VDC logic power supply (DIN-rail mount)
- Shielded servo motor cable (ETEL-specified, application-length)
- Safety relay module (STO – Safe Torque Off, IEC 62061 compliant)
Contact support@konmask.com for bundled BOM sourcing and volume pricing.
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive 2006/42/EC and Low Voltage Directive 2014/35/EU
- IEC 61800-5-2 – Functional safety for adjustable speed electrical power drive systems
- IEC 62061 – Safety of machinery, functional safety of SIL-rated control systems
- RoHS Compliant – Restriction of Hazardous Substances Directive 2011/65/EU
- ISO 9001:2015 – ETEL manufacturing quality management system certification
Quality Assurance & Sourcing
All ETEL components listed on Konmask.com are subject to the following quality controls:
- Visual Inspection: Board-level inspection for physical damage, corrosion, and component integrity prior to listing.
- Functional Verification: Where applicable, units are bench-tested against ETEL drive system parameters before shipment.
- Traceability: Serial number and revision code documented at time of sale for full supply chain traceability.
- Secure Packaging: ESD-safe anti-static bags, foam-lined cartons, and moisture barrier packaging for international transit.
- Sourcing Transparency: Parts sourced from decommissioned OEM systems, authorized distributors, or certified industrial surplus channels.
How to Source This Part
- Submit an Inquiry: Email support@konmask.com with your application details, required quantity, and delivery timeline.
- Receive a Quote: Our team will confirm stock availability, condition grade, and pricing within 1 business day.
- Technical Consultation: For integration questions, our engineers can advise on compatibility with your existing ETEL drive system.
- Order & Ship: Secure checkout via the Konmask.com store. Global shipping available with DHL Express, FedEx, and UPS. Export documentation provided for cross-border orders.
- After-Sales Support: 30-day return window for verified non-conforming parts. Warranty terms available on request.
Application-Specific FAQ
Q: Is the DSCDL332-131D-000A compatible with my existing ETEL DSCDL332 drive chassis?
A: Yes. The -131D-000A is a board-level variant within the DSCDL332 family and is designed as a direct replacement. Confirm your chassis revision with our team before ordering.
Q: Can this control board interface with a Siemens S7 or Beckhoff TwinCAT PLC?
A: The DSCDL332 series supports EtherCAT communication, which is natively compatible with Beckhoff TwinCAT. Siemens integration typically requires an EtherCAT master gateway. Contact us for application-specific guidance.
Q: What is the lead time for this part?
A: In-stock units ship within 2–3 business days. For out-of-stock inquiries, typical sourcing lead time is 2–4 weeks depending on global availability.
Q: Do you provide a test report or certificate of conformance (CoC)?
A: Yes. A CoC and functional test report can be provided upon request for orders requiring documentation for regulated industries (medical, aerospace, semiconductor).
Q: Can I return the part if it does not fit my application?
A: Konmask.com offers a 30-day return policy for parts that are unused and in original condition. Please contact support before initiating a return.
