Precision Motion Control Solution – ETEL DSMAX212-121C-000C | DSMAX Series
Where This Product Is Used
The ETEL DSMAX212-121C-000C is a high-performance digital servo drive module from ETEL’s DSMAX Series, engineered for demanding precision motion control applications. Engineers and system integrators specify this module across the following industries and use cases:
- Semiconductor Manufacturing Equipment – Wafer handling stages, lithography systems, and die-bonding machines requiring sub-micron positioning accuracy.
- Medical & Life Sciences Devices – Surgical robotics, diagnostic imaging platforms, and laboratory automation where smooth, repeatable motion is critical.
- Industrial Automation & Robotics – Multi-axis gantry systems, pick-and-place robots, and high-speed assembly lines.
- Metrology & Inspection Systems – Coordinate measuring machines (CMM) and optical inspection platforms demanding ultra-low velocity ripple.
- Photonics & Laser Processing – Beam steering, laser cutting, and fiber alignment systems requiring dynamic, high-bandwidth servo response.
- Aerospace & Defense Test Rigs – Structural test benches and simulation platforms with stringent reliability requirements.
Technical Specifications
| Part Number | DSMAX212-121C-000C |
| Brand / Manufacturer | ETEL |
| Series | DSMAX Series |
| Product Type | Digital Servo Drive Module |
| Drive Topology | Digital PWM Servo Amplifier |
| Motor Compatibility | ETEL Linear & Rotary Servo Motors (brushless) |
| Control Interface | EtherCAT / Proprietary ETEL Bus |
| Feedback Support | Encoder (incremental / absolute), Hall sensors |
| Protection Class | IP20 |
| Weight | 3.9 kg |
| Condition | Original / Refurbished (tested & verified) |
Note: Full electrical ratings (voltage, current, power) are available upon request. Contact our technical team for datasheet access.
Why Engineers Specify This Model
- ETEL DSMAX Series Ecosystem – Designed to integrate natively with ETEL linear motors and motion controllers, eliminating tuning complexity in multi-axis systems.
- High Bandwidth Servo Loop – Supports demanding dynamic profiles required in semiconductor and photonics applications where settling time is critical.
- Compact Module Form Factor – Rack-mountable design simplifies cabinet integration and reduces overall system footprint.
- Deterministic Real-Time Control – EtherCAT-compatible communication ensures synchronized multi-axis coordination with microsecond-level jitter.
- Proven Field Reliability – ETEL drives are specified by OEMs in tier-1 semiconductor fabs and medical device manufacturers globally.
Complete System Bill of Materials
For a complete ETEL DSMAX-based motion control system, the following components are typically required:
- ETEL DSMAX212-121C-000C – Digital Servo Drive Module (this item)
- ETEL Linear or Rotary Servo Motor (matched to drive rating)
- ETEL Motion Controller (e.g., ETEL MACRO or compatible EtherCAT master)
- Linear or Rotary Encoder (incremental or absolute, matched to feedback input)
- 24 VDC Logic Power Supply
- DC Bus Power Supply (matched to drive voltage spec)
- Shielded Motor & Encoder Cables (ETEL-specified or equivalent)
- Safety Relay / STO (Safe Torque Off) Module
- DIN Rail, Cabinet, and EMC Filtering Components
Contact support@konmask.com for BOM assistance and compatible part sourcing.
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive and Low Voltage Directive
- RoHS Compliant – Restriction of Hazardous Substances
- UL / cUL Listed (where applicable per ETEL product line)
- IEC 61800 – Adjustable Speed Electrical Power Drive Systems
- ISO 13849 / IEC 62061 – Functional Safety (STO capability)
Quality Assurance & Sourcing
At Konmask.com, every ETEL module undergoes a structured quality process before shipment:
- Visual Inspection – PCB, connectors, and housing checked for physical damage or corrosion.
- Functional Power-On Test – Drive is powered and communication interfaces are verified.
- Firmware Version Check – Firmware is documented and reported to the buyer.
- Anti-Static Packaging – Shipped in ESD-safe bags with foam cushioning and outer carton protection.
- Traceability – Serial number and test records retained for 12 months post-sale.
We source from decommissioned OEM production lines, certified industrial surplus channels, and authorized distributors. Counterfeit-free guarantee backed by our inspection process.
How to Source This Part
- Add to Cart – Click the purchase button above to place your order directly.
- Request a Quote – For volume orders (2+ units) or project BOM sourcing, email support@konmask.com with your quantity and delivery requirements.
- Lead Time – In-stock units ship within 1–3 business days. Out-of-stock units are sourced within 7–21 business days depending on availability.
- Export & Customs – We support international shipments with full commercial invoice, packing list, and HS code documentation for customs clearance.
- Payment – T/T (Bank Wire), PayPal, and major credit cards accepted. Net-30 available for qualified accounts.
Application-Specific FAQ
Q: Is the DSMAX212-121C-000C compatible with third-party motors?
A: The DSMAX Series is optimized for ETEL motors. Third-party motor compatibility depends on feedback type and electrical parameters. Contact our team for a compatibility assessment.
Q: Can this drive be used as a drop-in replacement for a failed unit?
A: Yes, provided the replacement unit carries the same part number and firmware version. We recommend verifying firmware before installation. We can assist with firmware documentation.
Q: Do you provide a warranty?
A: Yes. All units sold by Konmask.com carry a 90-day functional warranty covering defects identified during normal operation. Extended warranty options are available upon request.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days from our warehouse. Contact us for real-time stock confirmation.
Q: Can you supply the full ETEL DSMAX system including motor and controller?
A: Yes. Konmask.com specializes in complete motion control system sourcing. Share your BOM and we will provide a consolidated quote.
