FANUC 2007-T364 – Teach Pendant Cable Assembly | R-30iA / R-30iB Series Platform
In high-throughput robotic cells, a degraded teach pendant cable is the single most common cause of unplanned downtime. Operators lose E-stop authority, HMI screens freeze mid-program, and maintenance teams spend hours chasing intermittent faults before tracing the fault back to a worn or damaged cable harness. The FANUC 2007-T364 is the OEM-specified cable assembly that connects the iPendant or standard teach pendant to the R-30iA and R-30iB robot controller, restoring full bidirectional communication, safety-circuit integrity, and operator control.
Konmask.com stocks verified 2007-T364 assemblies sourced directly from FANUC-authorized channels, inspected against OEM dimensional and electrical specifications before dispatch.
Complete Technical Specifications
- Part Number: FANUC 2007-T364
- Component Type: Teach Pendant Cable / Wire Harness Assembly
- Compatible Controllers: R-30iA, R-30iB, R-30iB Plus (FANUC Series)
- Compatible Pendants: iPendant, iPendant Touch, Standard Teach Pendant
- Conductor Configuration: Multi-conductor shielded cable with dedicated E-stop safety loop wiring
- Connector Type: OEM-spec keyed industrial connector, both ends pre-terminated
- Cable Length: OEM standard length (confirm variant at order)
- Jacket Material: Oil- and abrasion-resistant PVC outer jacket
- Operating Temperature: −10 °C to +60 °C
- Weight: ~323 g (assembly)
- Country of Origin: Japan (OEM) / Authorized supply chain
Proven Application Environments
- Automotive Body Welding Lines – Continuous flex cycles in MIG/TIG welding cells where cable routing around positioners causes accelerated jacket wear; 2007-T364 provides the flex life required for 24/7 operation.
- Automotive Paint & Sealing Robots – Solvent-laden environments demand oil-resistant jacketing; the OEM cable maintains insulation integrity where aftermarket alternatives fail.
- Electronics Assembly & SMT Lines – Precision pick-and-place and dispensing cells where E-stop signal integrity is safety-critical; the dedicated safety-loop conductors meet IEC 62061 SIL 2 system requirements when used with compliant controllers.
- Palletizing & Material Handling – High-cycle warehouse automation where pendant cables are frequently connected/disconnected during product changeovers; OEM connectors withstand repeated mating cycles without contact degradation.
- Machine Tending & CNC Integration – Cells where the teach pendant is shared across multiple robots; cable integrity ensures reliable hot-swap without communication errors.
- Food & Beverage Processing – Wash-down adjacent environments where moisture ingress into connector interfaces causes safety-circuit faults; OEM sealing specification prevents nuisance trips.
Engineering Advantages
- OEM Safety-Circuit Compliance: Dedicated E-stop conductors maintain the dual-channel safety loop required by ISO 10218-1 robot safety standards — no field modification needed.
- Shielded Signal Conductors: Individual and overall shielding suppresses EMI from welding inverters, VFDs, and servo drives operating in the same cabinet or cell.
- Pre-Terminated Connectors: Factory-crimped and tested connectors eliminate field termination errors that cause intermittent faults and void controller warranties.
- Flex-Rated Construction: Stranded conductors and flexible jacket engineered for continuous cable-track and pendant-arm routing — not just static installation.
- Direct OEM Replacement: Plug-and-play fit to R-30iA/R-30iB controller pendant port; no adapter, no firmware change, no re-teach required.
System Architecture & Signal Flow
The 2007-T364 carries three functional signal groups within a single sheathed assembly:
- Communication Bus: Bidirectional serial data between the controller CPU board and the pendant display/keypad — carries program editing commands, status feedback, and alarm data.
- Safety E-Stop Loop: Dual-channel hardwired circuit that directly interrupts the controller’s safety relay chain; any open-circuit condition (cable break, connector fault) triggers a Category 0 stop per IEC 60204-1.
- Power Supply Lines: Low-voltage DC supply from the controller PSU to the pendant backlight, touchscreen, and processor — fused at the controller end.
Signal flow: Controller CPU Board → 2007-T364 Cable Assembly → iPendant / Teach Pendant. No intermediate junction boxes or signal converters in the standard configuration.
Sourcing & Quality Verification
- All units sourced from FANUC-authorized distributors or verified OEM surplus channels.
- Each assembly inspected for jacket integrity, connector seating, and continuity across all conductors prior to dispatch.
- Batch traceability records maintained; documentation available on request for regulated industries (automotive Tier 1, aerospace MRO).
- No counterfeit-risk gray-market sourcing; Konmask.com does not list unverified third-party replicas as OEM parts.
Procurement Process
- Confirm Compatibility: Verify your controller model (R-30iA or R-30iB) and pendant type (iPendant / Standard) against the specifications above.
- Request a Quote: Contact support@konmask.com with your PO number, required quantity, and delivery timeline.
- Lead Time: In-stock units ship within 1–3 business days; EXW Xiamen, international freight arranged on request.
- Payment: T/T bank transfer, PayPal, or trade-term arrangements for qualified accounts.
- Documentation: Commercial invoice, packing list, and test report provided with every shipment.
Technical FAQ
Q: Will 2007-T364 work with the R-30iB Plus (Mate) controller?
A: The R-30iB Plus uses the same pendant port interface as the standard R-30iB. The 2007-T364 is compatible; confirm cable length requirement before ordering.
Q: Can I use this cable with a third-party teach pendant?
A: No. The 2007-T364 is engineered specifically for FANUC OEM pendants. Third-party pendants use different connector pinouts and communication protocols.
Q: What fault codes indicate a failing teach pendant cable?
A: Common indicators include SRVO-037 (IMSTP input), SRVO-213 (E-stop board), PRIO-001 (operator panel E-stop), and intermittent “Pendant Disconnected” alarms. Replace the cable before replacing the pendant or controller board.
Q: Is the cable repairable in the field?
A: Field repair of safety-circuit cables is not recommended and may void the controller warranty. Replace with a new OEM assembly to maintain safety-system certification.
Q: Do you offer volume pricing for MRO stocking orders?
A: Yes. Contact us for tiered pricing on orders of 5+ units.
