Robotic Automation Solution – KUKA SmartPAD 00-320-104 | KRC5 Controller Series
Where This Product Is Used
The KUKA SmartPAD (Part No. 00-320-104, cross-ref 00-291-556) is the dedicated human-machine interface (HMI) for the KUKA KRC5 robot controller. It is deployed across a wide range of industrial automation environments where precise, real-time robot programming and monitoring are critical:
- Automotive Body-in-White (BIW) Welding – Operator programming of KUKA KR QUANTEC and KR AGILUS robots on spot-welding lines
- Collaborative Assembly Cells – Safe, intuitive teach-in for human-robot collaboration (HRC) stations
- Palletizing & Material Handling – Path programming for high-throughput logistics and end-of-line packaging
- Arc Welding & Laser Processing – Fine-tuning torch angles and seam tracking parameters in real time
- Machine Tending & CNC Integration – Coordinating robot motion with CNC machine cycles via KUKA.PLC mxAutomation
- Aerospace & Electronics Manufacturing – High-precision pick-and-place and inspection tasks requiring sub-millimeter repeatability
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 00-320-104 |
| Cross-Reference | 00-291-556 |
| Compatible Controller | KUKA KRC5, KRC5 micro, KRC5 compact |
| Display | 8.4″ color touchscreen, 800 × 600 px |
| Interface | KUKA SmartPAD bus (proprietary), USB-A port |
| Safety Rating | SIL 2 / PLd (EN ISO 13849-1) – 3-position enabling device |
| Ingress Protection | IP54 |
| Operating Temperature | 0 °C to +45 °C |
| Weight | Approx. 1.1 kg (pendant only) |
| Cable Length | 10 m (standard); 20 m optional |
| Country of Origin | Germany |
| HS Code | 8537.10 |
Why Engineers Specify This Model
- KRC5-Native Compatibility – Plug-and-play with all KRC5 variants; no firmware patching required
- Functional Safety Certified – Integrated 3-position enabling switch meets SIL 2 / PLd, satisfying ISO 10218-1 robot safety requirements
- KUKA smartHMI Interface – Runs KUKA System Software (KSS) 8.7+ with full WorkVisual project management support
- Hot-Swap Capable – Can be disconnected and reconnected without powering down the controller (with appropriate KSS settings)
- Ergonomic Design – Ambidextrous grip, backlit keys, and glove-friendly touchscreen reduce operator fatigue on long shifts
- Genuine OEM Part – Sourced from authorized KUKA distribution channels; full traceability documentation available
Complete System Bill of Materials
For a fully operational KRC5 robot cell, engineers typically specify the following alongside the SmartPAD 00-320-104:
- KUKA KRC5 Controller Cabinet (e.g., KRC5-8/32/64)
- SmartPAD Connection Cable – 10 m or 20 m (KUKA P/N: 00-168-334 / 00-168-335)
- KUKA KR AGILUS / KR QUANTEC / KR CYBERTECH robot arm (application-dependent)
- KUKA.WorkVisual Engineering Suite (software license)
- Safety PLC interface module (e.g., KUKA.SafeOperation or third-party Pilz/Sick)
- Teach pendant wall bracket / storage cradle (KUKA accessory)
Compliance & Industry Standards
- EN ISO 10218-1:2011 – Robots and robotic devices: Safety requirements for industrial robots
- EN ISO 13849-1:2015 – Safety of machinery: PLd / SIL 2 enabling device
- IEC 61800-5-2 – Functional safety for adjustable speed electrical power drive systems
- CE Marked – Compliant with EU Machinery Directive 2006/42/EC
- RoHS Compliant – Restriction of Hazardous Substances Directive 2011/65/EU
Quality Assurance & Sourcing
Every KUKA SmartPAD 00-320-104 shipped by Konmask.com undergoes the following verification process:
- Visual and mechanical inspection against KUKA OEM specifications
- Power-on functional test: display, keypad, enabling switch, and USB port
- Firmware version verification (KSS compatibility check)
- Anti-static packaging with humidity indicator card
- Lot traceability record retained for 5 years
We source exclusively from authorized KUKA distributors and certified secondary-market suppliers with full chain-of-custody documentation.
How to Source This Part
To place an order or request a formal quotation for the KUKA SmartPAD 00-320-104:
- Online: Add to cart directly on this page – we accept T/T, PayPal, and major credit cards
- Email RFQ: support@konmask.com – include your KRC5 serial number for compatibility confirmation
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Lead Time: In-stock units ship within 1–3 business days; EXW Xiamen, China
- Export: We handle export documentation (CO, packing list, commercial invoice) for international buyers
Application-Specific FAQ
Q: Is 00-320-104 backward-compatible with KRC4 controllers?
A: No. The SmartPAD 00-320-104 uses the KRC5 SmartPAD bus protocol and is not electrically or software-compatible with KRC4. For KRC4, please inquire about KUKA P/N 00-168-334 series pendants.
Q: Can I use this pendant with KUKA LBR iiwa collaborative robots?
A: The LBR iiwa uses a dedicated Sunrise Cabinet controller, not KRC5. This pendant is not compatible with iiwa. Contact us for the correct iiwa HMI solution.
Q: What KSS software version does this SmartPAD support?
A: Compatible with KUKA System Software (KSS) 8.6 and above, including KSS 8.7 and KUKA iiQKA.OS environments on KRC5.
Q: Do you provide a warranty?
A: Yes – 90-day functional warranty on all units. Extended 12-month warranty available upon request for volume orders.
Q: Can you supply the matching SmartPAD cable?
A: Yes. We stock 10 m and 20 m SmartPAD connection cables. Please add a note to your order or contact us directly.
