FANUC A05B-2255-C102 Teach Pendant | Replacement, Equivalent & Selection Guide
The FANUC A05B-2255-C102 is a high-performance iPendant Touch teach pendant designed for FANUC robot controllers. This guide helps engineers and procurement teams identify compatible replacements, equivalent models, and make informed selection decisions for their automation systems.
Technical Specifications
- Part Number: A05B-2255-C102
- Manufacturer: FANUC Corporation (Japan)
- Series: iPendant Touch
- Display: 8.4-inch color LCD touchscreen
- Interface: USB port, Emergency Stop button, Deadman switch
- Cable: Integrated teach pendant cable
- Compatible Controllers: R-30iB, R-30iB Plus, R-30iB Mate, R-30iB Mate Plus
- Weight: Approx. 380 g
- Country of Origin: Japan
- Condition: New / Refurbished available
Compatible Replacement & Equivalent Models
The following models are functionally equivalent or serve as direct replacements for the A05B-2255-C102 in specific controller configurations:
- A05B-2255-C100 — Standard iPendant Touch (without USB), R-30iB compatible
- A05B-2255-C101 — iPendant Touch with USB, R-30iB series
- A05B-2255-C103 — iPendant Touch Plus variant, extended functionality
- A05B-2518-C300 — iPendant for R-30iB Mate / Mate Plus controllers
- A05B-2301-C302 — Legacy iPendant for R-J3iC / R-30iA controllers (adapter required)
Note: Always verify controller firmware version and cable connector type before substituting models.
Why Choose the Original Model
- ✅ Plug-and-play compatibility with R-30iB / R-30iB Plus — no firmware modification required
- ✅ Full touchscreen support for FANUC iHMI interface and KAREL programming
- ✅ Integrated USB port for program backup, restore, and software updates
- ✅ Certified safety circuit — dual-channel Deadman switch and E-Stop compliant with ISO 10218
- ✅ FANUC OEM quality — guaranteed compatibility and long-term spare parts support
Typical Applications
- Automotive body welding and assembly lines
- Palletizing and material handling systems
- Arc welding and spot welding robots
- Machine tending and CNC integration
- Painting and coating automation
- Collaborative robot (CRX series) programming
System Compatibility
| Controller | Compatible | Notes |
|---|---|---|
| R-30iB | ✅ Yes | Native support |
| R-30iB Plus | ✅ Yes | Native support |
| R-30iB Mate | ✅ Yes | Native support |
| R-30iB Mate Plus | ✅ Yes | Native support |
| R-30iA | ⚠️ Partial | Adapter cable required |
| R-J3iC | ❌ No | Use A05B-2301-C302 instead |
Selection Guide
Use the following criteria to select the correct teach pendant for your FANUC robot system:
- Step 1 — Identify your controller model: Check the controller nameplate for R-30iB / R-30iB Plus / Mate variants.
- Step 2 — Check cable connector type: A05B-2255-C102 uses the standard 50-pin iPendant connector. Confirm your controller’s pendant port.
- Step 3 — Determine USB requirement: If you need USB for file transfer, C102 is preferred over C100.
- Step 4 — Verify firmware version: iHMI touchscreen requires V8.30 or later. Confirm with FANUC service documentation.
- Step 5 — New vs. refurbished: For production-critical lines, OEM new units are recommended. Refurbished units suit maintenance spares.
Quality Assurance & Sourcing
- 🔍 All units inspected and tested before shipment
- 📦 Anti-static packaging with full traceability documentation
- 🏭 Sourced directly from authorized FANUC distributors and certified secondary market suppliers
- 📋 Certificate of conformity available upon request
- 🔄 30-day return policy for DOA (Dead on Arrival) units
How to Order
- Add the FANUC A05B-2255-C102 to your cart and proceed to checkout.
- For bulk orders (>3 units) or urgent requirements, contact us directly for priority sourcing.
- Provide your controller model and serial number for compatibility verification if needed.
- We accept T/T bank transfer, PayPal, and major credit cards.
- Lead time: In-stock units ship within 1–3 business days; sourced units 5–15 business days.
Replacement & Compatibility FAQ
Q: Can A05B-2255-C102 replace A05B-2255-C100?
A: Yes, the C102 is a functional upgrade of C100, adding a USB port. It is backward compatible with the same controllers.
Q: Is this pendant compatible with FANUC LR Mate 200iD?
A: Yes, provided the robot uses an R-30iB or R-30iB Mate controller.
Q: Can I use a third-party teach pendant as a replacement?
A: Third-party pendants may lack full iHMI support and safety certification. We strongly recommend OEM or certified equivalent units for safety-critical applications.
Q: What is the warranty on refurbished units?
A: Refurbished units carry a 90-day functional warranty. New OEM units follow FANUC’s standard warranty terms.
Q: Do you provide installation support?
A: Yes, our technical team can provide remote guidance for pendant replacement and controller pairing.
