CNC Analog Signal Acquisition Solution – FANUC AIF01A (A03B-0807-C011) | Series 0i I/O Module
Where This Product Is Used
The FANUC AIF01A (A03B-0807-C011) Analog Input Module is deployed across a wide range of precision manufacturing and industrial automation environments where analog signal acquisition is critical to CNC machine performance:
- CNC Machining Centers – Spindle load monitoring, thermal compensation feedback, and servo tuning via analog voltage/current signals.
- Turning & Milling Machines – Real-time analog feedback from sensors (pressure, temperature, position) integrated into FANUC Series 0i control loops.
- Injection Molding Machines – Analog pressure and flow signal acquisition for closed-loop process control.
- Robotic Welding Cells – Analog arc voltage and wire feed monitoring routed through FANUC I/O expansion racks.
- Grinding & EDM Equipment – High-resolution analog input for in-process gauging and adaptive control.
- Automated Assembly Lines – Sensor signal conditioning and acquisition in multi-axis FANUC-controlled systems.
Technical Specifications
| Part Number | AIF01A |
| FANUC Order Number | A03B-0807-C011 |
| Module Type | Analog Input Module |
| Compatible Series | FANUC Series 0i / 0i-Mate / 16i / 18i / 21i |
| Input Channels | Analog voltage / current input (refer to FANUC I/O Unit-A specification) |
| Signal Range | 0–10 V DC / 4–20 mA (configuration dependent) |
| Resolution | 12-bit A/D conversion |
| Backplane Interface | FANUC I/O Unit-A rack bus |
| Power Supply | Supplied via I/O rack backplane (24 V DC) |
| Weight | Approx. 300 g |
| Manufacturer | FANUC Corporation, Japan |
Why Engineers Specify This Model
- Native FANUC Integration – Designed exclusively for FANUC I/O Unit-A racks; no third-party adapter or signal converter required.
- Deterministic Scan Cycle – Analog data is sampled synchronously with the CNC ladder scan, eliminating timing jitter in closed-loop applications.
- Compact Slot Form Factor – Single-slot module minimizes rack space consumption in space-constrained electrical cabinets.
- Proven Field Reliability – Widely deployed in Tier-1 automotive and aerospace manufacturing lines with documented MTBF exceeding 50,000 hours.
- Direct PMC Addressability – Analog values are mapped directly to PMC data registers (D-addresses), simplifying ladder logic development.
- OEM-Equivalent Replacement – Identical form, fit, and function to factory-installed modules; no parameter re-initialization required on swap.
Complete System Bill of Materials
For a fully operational FANUC analog input expansion, the following components are typically required alongside the AIF01A:
- FANUC I/O Unit-A Base Rack (A03B-0807-C001 or compatible)
- FANUC I/O Unit-A Power Supply Module (A03B-0807-C002)
- FANUC I/O Link Cable (A66L-0001-0284 or equivalent)
- Shielded analog signal cable (twisted-pair, 0.5 mm²)
- DIN rail terminal blocks for field wiring termination
- 24 V DC panel power supply (if not sourced from existing rack PSU)
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive 2006/42/EC and EMC Directive 2014/30/EU.
- RoHS – Manufactured in accordance with RoHS 2 (2011/65/EU) restrictions on hazardous substances.
- UL/cUL – Listed for industrial control equipment per UL 508 (where applicable to OEM machine build).
- ISO 9001 – FANUC Corporation operates under ISO 9001-certified quality management systems.
- IEC 61131-2 – Module electrical characteristics conform to IEC 61131-2 programmable controller hardware standards.
Quality Assurance & Sourcing
Konmask.com specializes in verified industrial automation components for B2B buyers. Every FANUC AIF01A unit we supply undergoes the following process:
- Visual & Physical Inspection – Board-level inspection for corrosion, damaged connectors, and counterfeit indicators.
- Functional Verification – Where test fixtures are available, modules are bench-tested against FANUC I/O Unit-A rack specifications.
- Traceability Documentation – Lot codes, date codes, and sourcing chain records are maintained for each unit.
- Anti-Static Packaging – All modules are shipped in ESD-safe bags with foam cushioning and moisture barrier packaging.
- 90-Day Warranty – All units carry a 90-day warranty against defects in materials and workmanship.
How to Source This Part
To request a quote or confirm stock availability for the FANUC AIF01A (A03B-0807-C011):
- 📧 Email: support@konmask.com
- 📞 Phone / WhatsApp: +0086 19859288691
- 🌐 Web: https://konmask.com
- Lead time: Typically 3–7 business days for in-stock units; 2–4 weeks for sourced/refurbished stock.
- MOQ: 1 piece. Volume pricing available for orders of 5+ units.
Application-Specific FAQ
Q: Is the AIF01A compatible with FANUC Series 16i/18i/21i controllers?
A: Yes. The AIF01A is compatible with any FANUC controller that supports the I/O Unit-A rack architecture, including Series 0i, 16i, 18i, and 21i families.
Q: Can this module accept 4–20 mA current loop signals?
A: Yes, with appropriate jumper or parameter configuration on the I/O Unit-A rack. Consult FANUC I/O Unit-A Connection Manual (B-62163E) for wiring details.
Q: What is the difference between AIF01A and AIF02A?
A: The AIF01A (A03B-0807-C011) provides standard analog input channels. The AIF02A variant offers additional channel count or extended resolution. Confirm your channel requirements before ordering.
Q: Do you supply new or refurbished units?
A: We supply both new-surplus (unused, original packaging) and professionally refurbished units. Stock type is confirmed at time of quotation.
Q: Can Konmask.com provide a certificate of conformance?
A: Yes. A certificate of conformance (CoC) is available upon request for all units.
