Factory Automation Power Solution – FUJI Electric NP1X3206-W | NP1 Series
Where This Product Is Used
The FUJI NP1X3206-W is a dedicated power supply module engineered for the FUJI NP1 Series PLC platform. It is widely deployed across demanding industrial environments where stable, uninterrupted DC power is critical to system integrity:
- Automotive Assembly Lines – Powers NP1 CPU and I/O racks in body welding, paint shop conveyors, and final assembly stations.
- Food & Beverage Processing – Operates in washdown-adjacent control panels for filling, capping, and packaging machinery.
- Chemical & Pharmaceutical Plants – Supplies regulated DC power to process controllers managing reactors, mixers, and batch systems.
- Water Treatment & Utilities – Installed in SCADA-linked PLC panels controlling pumps, valves, and filtration systems.
- Discrete Manufacturing & Machine Tools – Integrated into CNC machine control cabinets and robotic workcells requiring clean, stable power.
- Building Automation & Infrastructure – Used in HVAC control panels, elevator systems, and energy management controllers.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | NP1X3206-W |
| Brand | FUJI Electric |
| Series | NP1 (MICREX-SX) |
| Module Type | PLC Power Supply Module |
| Input Voltage | 100–240 VAC, 50/60 Hz |
| Output Voltage | 24 VDC |
| Output Current | 6 A (max) |
| Output Power | 144 W |
| Isolation | Input–Output galvanic isolation |
| Protection | Overvoltage, overcurrent, short-circuit |
| Mounting | NP1 backplane slot (direct rack mount) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Humidity | 5–95% RH (non-condensing) |
| Weight | Approx. 446 g |
| Certifications | CE, UL (refer to product label) |
Specifications are based on FUJI Electric published data. Verify with official datasheet before final design.
Why Engineers Specify This Model
- Platform-native compatibility – Designed exclusively for the NP1 backplane; no adapter or external wiring required.
- Wide-range AC input – Accepts 100–240 VAC globally, simplifying international machine builds and OEM exports.
- High output stability – Tight voltage regulation ensures consistent logic-level power to CPU, communication, and I/O modules.
- Integrated protection circuits – Overvoltage, overcurrent, and short-circuit protection reduce panel downtime and protect downstream modules.
- Compact rack-mount form factor – Occupies a single NP1 slot, preserving valuable panel space for I/O expansion.
- Proven field reliability – Widely deployed in FUJI MICREX-SX installations across Asia, Europe, and the Americas.
Complete System Bill of Materials
For a complete NP1 PLC control system, the following components are typically specified alongside the NP1X3206-W:
- NP1 CPU Module – e.g., NP1PS-08 / NP1PS-16 / NP1PS-32 (program execution & communication)
- NP1 Digital Input Module – e.g., NP1X16-W (16-point 24VDC DI)
- NP1 Digital Output Module – e.g., NP1Y16-W (16-point transistor DO)
- NP1 Analog I/O Module – e.g., NP1AD4-W / NP1DA2-W (4-ch AI / 2-ch AO)
- NP1 Base Unit / Backplane – e.g., NP1B-04 / NP1B-08 (4-slot / 8-slot)
- Programming Software – FUJI SX-Programmer Expert (D300win)
- Communication Cable – USB or RS-232C programming cable
Contact support@konmask.com for bundle pricing on complete NP1 system builds.
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive (LVD) and EMC Directive
- UL Listed – Recognized for use in North American industrial control panels
- RoHS Compliant – Meets EU Restriction of Hazardous Substances requirements
- IEC 61131-2 – Programmable controller hardware standard compliance
- IP20 Enclosure Rating – Suitable for installation inside sealed control cabinets
Quality Assurance & Sourcing
Konmask.com sources the FUJI NP1X3206-W through verified industrial distribution channels. Every unit undergoes the following before shipment:
- Visual inspection for physical damage, label integrity, and connector condition
- Verification of part number, date code, and country of manufacture markings
- Anti-static packaging with humidity indicator card
- Traceability documentation available upon request for regulated industries
We do not sell counterfeit, refurbished-as-new, or grey-market components. All products are supplied with original manufacturer packaging where available.
How to Source This Part
- Add to Cart – Click the purchase button above to place an order directly.
- Request a Quote – Email support@konmask.com for volume pricing, lead time confirmation, or project BOM review.
- Urgent Orders – Call or WhatsApp +0086 19859288691 for same-day response on critical spares.
- OEM / System Integrators – Ask about our trade account program for recurring procurement with NET payment terms.
Application-Specific FAQ
Q: Is the NP1X3206-W compatible with all NP1 base units?
A: Yes. It is designed to fit any NP1 Series backplane (NP1B-04, NP1B-08, etc.) and must be installed in the designated power supply slot (leftmost slot).
Q: Can this module power both the CPU and I/O modules simultaneously?
A: Yes. The 6A / 144W output is sufficient to power the CPU module plus multiple I/O modules within the NP1 rack. Calculate total I/O current draw before finalizing your BOM.
Q: What happens during an input power interruption?
A: The module provides a brief hold-up time to allow the CPU to execute a controlled shutdown. For extended UPS backup, pair with an external 24VDC UPS or battery backup unit.
Q: Is this module suitable for use in hazardous locations (Ex zones)?
A: No. The NP1X3206-W is rated IP20 and is intended for installation inside a sealed, non-hazardous control enclosure. For Ex-zone applications, consult FUJI Electric for certified enclosure solutions.
Q: What is the typical lead time for this part?
A: In-stock units ship within 1–3 business days. For out-of-stock situations, lead time is typically 4–8 weeks from FUJI Electric. Contact us for current availability.
Q: Do you provide a warranty?
A: Yes. Konmask.com offers a 12-month warranty against manufacturing defects on all genuine FUJI Electric products sold through our store.
