Turbine Control I/O Solution – GE DS200RTBAG2AGL | Mark VI Series
The GE DS200RTBAG2AGL is a Relay Terminal Board engineered for GE’s Mark VI turbine control platform. It serves as the critical interface layer between the Mark VI controller and field-level relay outputs, enabling reliable discrete signal switching in high-demand power generation and industrial drive environments. Engineers specify this board when they need proven, OEM-grade relay I/O with direct compatibility across the DS200 ecosystem.
Where This Product Is Used
- Gas Turbine Power Plants – Relay output control for fuel valve sequencing, ignition logic, and flame detection circuits in GE Frame 5, 6, 7, and 9 gas turbines.
- Steam Turbine Control Systems – Discrete output switching for trip solenoids, lube oil pump starters, and turning gear interlocks.
- Combined Cycle Power Plants (CCPP) – Coordinated relay I/O between HRSG bypass valves and turbine protection logic.
- Industrial Compressor Stations – Relay-driven motor starter and shutdown logic in pipeline compression applications.
- Offshore Oil & Gas Platforms – Hardened relay terminal interface for safety-critical shutdown (ESD) and fire & gas (F&G) systems.
- Mark VI Retrofit & Upgrade Projects – Drop-in replacement for aging DS200RTBA boards during Mark V to Mark VI migration programs.
Technical Specifications
- Part Number: DS200RTBAG2AGL
- Series: DS200 / Mark VI Turbine Control
- Board Type: Relay Terminal Board
- Manufacturer: GE (General Electric) – Power & Water Division
- Form Factor: PCB module with screw-terminal field wiring interface
- Weight: 680 g (approx.)
- Compatible Controllers: GE Mark VI VCMI, VCRC, VTUR, VSVO I/O packs
- Relay Output Type: Dry-contact relay outputs for discrete field devices
- Operating Environment: Industrial panel-mount; designed for continuous 24/7 operation
- Condition Available: New surplus / Tested refurbished
Why Engineers Specify This Model
- OEM Pinout Compatibility – Direct plug-and-play replacement within existing Mark VI I/O racks; no wiring modifications required.
- Proven Field Reliability – DS200 series boards are deployed across thousands of GE turbine installations globally with documented MTBF performance.
- Reduced Commissioning Risk – Identical firmware handshake with Mark VI I/O packs eliminates configuration drift during board swap.
- Long Service Life – Conformal-coated PCB construction resists humidity, vibration, and airborne contaminants common in turbine enclosures.
- Faster Outage Recovery – Stocking a spare DS200RTBAG2AGL reduces unplanned downtime from relay board failures to a single maintenance window.
Complete System Bill of Materials
The DS200RTBAG2AGL is typically deployed alongside the following Mark VI components:
- DS200TCQAG1BHF – Turbine Control Quad Board
- DS200SDCCG1AFB – System Definition & Control Card
- DS200VPBLG1AFF – VME Power Board
- IS200VCMIH2C – Mark VI VCMI I/O Pack
- IS200VTURH1BAA – Mark VI Turbine I/O Pack
- DS200RTBAG2AGL (this board) – Relay Terminal Board
Contact Konmask.com to source complete BOM kits for Mark VI panel builds or outage spares packages.
Compliance & Industry Standards
- Designed and manufactured to GE Power & Water internal engineering standards
- Compatible with IEC 61511 (Functional Safety – Safety Instrumented Systems) application architectures
- Suitable for use in NERC CIP-compliant control environments (asset owner responsibility for configuration)
- RoHS-compliant manufacturing (verify revision suffix for specific compliance documentation)
- CE marking applicable for EU import (consult datasheet for declaration of conformity)
Quality Assurance & Sourcing
- Inspection Protocol: Every unit undergoes visual inspection, board-level continuity check, and relay coil/contact verification before shipment.
- Traceability: Serial number and revision suffix (G2AGL) documented at point of sale for maintenance records.
- Packaging: Anti-static bag + foam-lined carton; meets JEDEC JESD625 ESD handling requirements.
- Warranty: 12-month replacement warranty on tested refurbished units; new surplus units carry OEM warranty terms.
- Sourcing Integrity: Konmask.com sources exclusively from authorized distributors, OEM surplus channels, and verified industrial decommission programs — no counterfeit risk.
How to Source This Part
- Submit an RFQ – Email support@konmask.com with your required quantity, delivery timeline, and condition preference (new / refurbished).
- Receive Quote – Pricing and lead time confirmed within 1 business day for in-stock units.
- Place Order – Purchase via this product page (add to cart) or via proforma invoice for B2B/wire transfer orders.
- Shipping – DHL / FedEx international express available; export documentation (commercial invoice, packing list, COO) included.
- After-Sales Support – Technical support available for installation verification and Mark VI integration questions.
Application-Specific FAQ
Q: Is the DS200RTBAG2AGL compatible with Mark V systems?
A: No. The DS200RTBAG2AGL is designed for the Mark VI platform. Mark V systems use a different terminal board architecture (e.g., DS200RTBAG1A). Confirm your controller generation before ordering.
Q: Can this board be used as a direct swap without reconfiguration?
A: Yes, provided the replacement board carries the same revision suffix (G2AGL). Revision mismatches may require a ToolboxST configuration update — contact us to verify compatibility.
Q: Do you provide test reports with the board?
A: Yes. Tested refurbished units ship with a functional test report upon request. Specify at time of order.
Q: What is the typical lead time for out-of-stock units?
A: 2–4 weeks for sourcing from our global supplier network. Emergency expedite options available — contact us directly.
Q: Can Konmask supply a complete Mark VI spare parts kit?
A: Yes. We specialize in complete BOM kits for Mark VI outage spares. Submit your full BOM list to support@konmask.com for a consolidated quote.
