Turbine Overspeed Protection Solution – GE DS200TCEAG1BSF | Mark VI Series
Where This Product Is Used
The GE DS200TCEAG1BSF Emergency Overspeed Board is a critical safety and control component deployed in GE Mark VI Turbine Control Systems. It is engineered for continuous operation in high-stakes industrial environments where turbine runaway events must be detected and arrested within milliseconds. Typical deployment sites include:
- Gas turbine power generation plants (combined-cycle and simple-cycle)
- Steam turbine installations in petrochemical and refinery facilities
- Offshore oil & gas platforms requiring SIL-rated overspeed protection
- Industrial co-generation systems with Mark VI-based DCS integration
- LNG liquefaction train turbine drivers
Technical Specifications
- Part Number: DS200TCEAG1BSF
- Series: GE Mark VI Turbine Control
- Function: Emergency Overspeed Detection & Trip Board
- Form Factor: VME-bus plug-in board
- Weight: 1,850 g (approx.)
- Speed Sensing Inputs: Triple-redundant magnetic pickup (MPU) channels
- Trip Logic: 2-out-of-3 voting architecture for fail-safe operation
- Communication: Integrated with Mark VI IONET / IONet Ethernet backbone
- Operating Temperature: 0 °C to 60 °C
- Power Supply: 28 VDC (Mark VI backplane)
- Compliance: Designed to IEC 61508 SIL 2 functional safety requirements
Why Engineers Specify This Model
- Proven 2oo3 voting logic eliminates single-point-of-failure risk in overspeed trip circuits
- Direct Mark VI backplane compatibility — no adapter or signal conditioning required
- Hardware-enforced trip operates independently of software, ensuring protection even during controller faults
- Millisecond response time meets API 670 and OEM turbine protection requirements
- Field-replaceable design minimizes planned outage duration during maintenance windows
- GE OEM-equivalent quality — sourced from verified supply chains with full traceability
Complete System Bill of Materials
The DS200TCEAG1BSF is typically installed alongside the following Mark VI components:
- DS200TCQAG1BHF – Turbine Control Quad Board
- DS200SDCCG1AFB – System DC/DC Converter Card
- DS200IOCAG1B – I/O Controller Board
- IS200TTURH1CBB – Turbine Trip Relay Board
- DS200VPBLG1AFF – VME Power Backplane
- DS200DTBCG1AAA – Terminal Board for speed inputs
Contact support@konmask.com for complete BOM sourcing and cross-reference support.
Compliance & Industry Standards
- IEC 61508 – Functional Safety of E/E/PE Safety-related Systems (SIL 2)
- API 670 – Machinery Protection Systems (5th Edition)
- NEMA ICS 2 – Industrial Control Devices, Controllers and Assemblies
- CE Marking – EMC Directive 2014/30/EU compatible design
- RoHS compliant replacement options available on request
Quality Assurance & Sourcing
Every DS200TCEAG1BSF unit offered by Konmask.com undergoes a structured inspection protocol before dispatch:
- Visual inspection: PCB integrity, connector pins, component seating
- Functional bench test against GE Mark VI signal simulation
- Firmware version verification and documentation
- Anti-static packaging with humidity indicator card
- Full traceability documentation provided upon request
Units are sourced from decommissioned plant overhauls, authorized distributors, and verified surplus channels — never counterfeit or refurbished without disclosure.
How to Source This Part
Konmask.com maintains ready stock of the GE DS200TCEAG1BSF for immediate dispatch. To place an order or request a quote:
- 📧 Email: support@konmask.com
- 📞 Phone/WhatsApp: +0086 19859288691
- 🌐 Web: https://konmask.com
Lead time: In-stock units ship within 1–3 business days. Expedited freight available for critical plant outages.
Application-Specific FAQ
Q: Is the DS200TCEAG1BSF compatible with both Mark VI and Mark VIe systems?
A: The DS200TCEAG1BSF is designed for the Mark VI platform. Mark VIe uses a different I/O architecture; please contact us to confirm compatibility with your specific controller revision.
Q: Can this board be repaired, or must it be replaced?
A: GE recommends board-level replacement for safety-critical overspeed boards. Konmask.com supplies tested replacement units to minimize downtime.
Q: What is the typical failure mode that requires replacement?
A: Common failure indicators include nuisance trips, failure to trip on test, IONet communication faults, and diagnostic alarms L3DIAG_TCEG on the HMI.
Q: Do you provide a warranty?
A: Yes. All units carry a 12-month warranty against defects in materials and workmanship under normal operating conditions.
Q: Can you supply the full Mark VI control panel or just individual boards?
A: Both. Konmask.com supplies individual boards, complete panel assemblies, and turnkey Mark VI system upgrades. Contact us for project-specific requirements.
