Turbine Control Solution — GE DS200TCQCG1BKG | Mark V Module
Where This Product Is Used
The GE DS200TCQCG1BKG is a core control module within the GE Mark V Turbine Control System, deployed globally across power generation, oil & gas, and heavy industrial facilities. Engineers specify this board wherever mission-critical turbine sequencing, protection, and I/O management are required.
- Gas & Steam Turbine Power Plants — Primary control and protection logic for GE Frame 5, 6, 7, and 9 turbine units
- Combined Cycle Plants (CCPP) — Coordinated turbine-generator control in multi-unit configurations
- LNG & Petrochemical Facilities — Compressor train control and emergency shutdown integration
- Offshore Platforms — Turbine-driven generator sets requiring SIL-rated protection
- Industrial Cogeneration — Heat recovery and back-pressure turbine automation
- Refinery Utilities — Steam turbine-driven pump and compressor control
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | DS200TCQCG1BKG |
| Manufacturer | General Electric (GE) |
| Series | Mark V Turbine Control System |
| Module Type | TCQC — Turbine Control I/O & Communication Module |
| Form Factor | PCB Card, Mark V Rack-Mount |
| Operating Voltage | +5 VDC / ±15 VDC (rack-supplied) |
| Communication Interface | Mark V IONET / Serial I/O Bus |
| Operating Temperature | 0°C to +60°C |
| Weight | 980 g |
| Condition Available | Refurbished / Tested / New Surplus |
| Warranty | 12 Months (Konmask Standard) |
Why Engineers Specify This Model
- Drop-in Replacement — Direct hardware and firmware compatibility with existing Mark V racks; no re-engineering required
- Proven Field Reliability — Deployed in thousands of turbine control panels worldwide since the 1990s; extensive MTBF data available
- Reduced Downtime Risk — Stocking a tested spare eliminates multi-week OEM lead times during unplanned outages
- Firmware Revision Matched — Units sourced and verified against site-specific firmware revision requirements on request
- Full Functional Test — Every unit bench-tested under simulated Mark V rack conditions before shipment
- Long-term Availability — GE Mark V is legacy/discontinued; Konmask maintains dedicated inventory for lifecycle support
Complete System Bill of Materials
The DS200TCQCG1BKG operates within the GE Mark V control system. Common companion modules for a complete spare-parts strategy include:
- DS200TCDAG1A — Turbine Control Diagnostic Board
- DS200TCQAG1B — TCQA I/O Module
- DS200TCEAG1B — Turbine Control Excitation Board
- DS200TCPSG1A — Power Supply Module
- DS200SDCIG2A — Speed/Dynamics Control Interface
- IS200TREGH1B — Turbine Regulation & Emergency Governor
- DS200TCRAG1AAA — Turbine Control Relay Board
Contact Konmask for complete Mark V panel BOM audits and multi-module sourcing packages.
Compliance & Industry Standards
- IEC 61511 — Functional Safety for Process Industry Sectors (SIL-capable system)
- IEC 61508 — Functional Safety of E/E/PE Safety-related Systems
- NEMA ICS 2 — Industrial Control Devices, Controllers, and Assemblies
- CE Marking — Applicable to refurbished units re-certified for EU deployment
- RoHS Compliance — Verified on new surplus units; documentation available on request
- GE Mark V Engineering Standards — GEH-6195, GEI-100679 reference documentation supported
Quality Assurance & Sourcing
Konmask operates a structured quality process for all legacy industrial control modules:
- Visual Inspection — PCB, connectors, capacitors, and solder joints inspected under magnification
- Functional Bench Test — Module powered and tested in a Mark V-compatible rack simulator
- Firmware Verification — Revision label and EPROM content confirmed against GE documentation
- ESD-Safe Packaging — Anti-static bags, foam cushioning, and moisture barrier packaging for international shipment
- Traceability — Serial number, test date, and technician ID recorded for every unit shipped
- 12-Month Warranty — Covers functional failure under normal operating conditions; RMA process within 5 business days
How to Source This Part
- Confirm your Mark V panel revision — Check your existing module label or GE panel drawing for the exact part suffix (e.g., G1BKG)
- Request a quote — Email support@konmask.com with your part number, quantity, and required delivery timeline
- Receive test report — Konmask provides a functional test certificate with every unit
- Confirm firmware revision — If site-specific firmware is required, advise at time of order
- Place order & ship — DHL / FedEx / sea freight options available; export documentation provided for international orders
For urgent outage support, call +0086 19859288691 — we prioritize emergency sourcing requests.
Application-Specific FAQ
Q: Is the DS200TCQCG1BKG compatible with all Mark V panel configurations?
A: It is compatible with standard Mark V TMR (Triple Modular Redundant) and Simplex configurations. Confirm your panel type (TCEA, TCQC slot) before ordering.
Q: Can this module be used as a direct replacement without reprogramming?
A: In most cases, yes — provided the firmware revision matches your existing panel. Konmask can verify and match firmware on request.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. For units requiring firmware matching or additional testing, allow 5–7 business days.
Q: Do you provide export documentation for international shipments?
A: Yes. We provide commercial invoice, packing list, certificate of origin, and HS code documentation (HS: 8537.10) for all international orders.
Q: What warranty is included?
A: All units carry a 12-month functional warranty. If a unit fails under normal operating conditions, we provide a replacement or full refund within 5 business days of RMA approval.
