CNC Machine Tool I/O Solution – GE Fanuc AID16D A03B-0807-C104 | FANUC Series
Where This Product Is Used
The GE Fanuc AID16D (Part No. A03B-0807-C104) is a 16-point DC input PCB I/O module designed for integration into FANUC CNC control systems. It is widely deployed in the following industrial environments:
- CNC Machining Centers – Vertical and horizontal machining centers requiring reliable discrete input signal acquisition from proximity sensors, limit switches, and push-button stations.
- CNC Turning Centers & Lathes – Turret position feedback, chuck open/close sensing, and tailstock limit detection.
- Injection Molding Machines – Mold open/close position sensing, ejector pin detection, and safety gate interlocks.
- Robotic Work Cells – Interfacing FANUC robot controllers with peripheral tooling, conveyors, and fixture clamps via discrete DC inputs.
- Automated Assembly Lines – Part-present detection, fixture confirmation, and conveyor indexing signals routed through the FANUC I/O bus.
- Stamping & Press Lines – Die protection sensor inputs and stroke-count feedback integrated into FANUC PMC ladder logic.
Technical Specifications
| Manufacturer | GE Fanuc (FANUC Corporation) |
| Part Number | AID16D / A03B-0807-C104 |
| Module Type | PCB DC Input I/O Module |
| Input Points | 16 Points |
| Signal Type | DC Input (Discrete) |
| Form Factor | PCB (Printed Circuit Board) Module |
| Compatible Series | FANUC CNC Series (A03B-0807 I/O Unit) |
| Weight | Approx. 300 g |
| Condition | Genuine OEM / Refurbished – Tested |
Why Engineers Specify This Model
- Direct OEM Replacement – Exact form, fit, and function match for FANUC A03B-0807 I/O unit slots; no firmware reconfiguration required.
- 16-Point Density – High channel count in a compact PCB footprint reduces cabinet space and wiring complexity versus discrete relay modules.
- DC Input Compatibility – Accepts standard NPN/PNP DC sensor signals common in modern machine tool environments.
- PMC Ladder Integration – Inputs map directly to FANUC PMC (Programmable Machine Controller) addresses, enabling seamless ladder logic programming.
- Proven Field Reliability – Widely used across global machine tool fleets with a long service history in high-cycle manufacturing environments.
- Rapid Swap-Out – PCB module design allows maintenance teams to restore machine uptime in minutes without full I/O unit replacement.
Complete System Bill of Materials
The AID16D is typically used alongside the following FANUC components in a complete I/O subsystem:
- FANUC A03B-0807-C001 – I/O Unit Base
- FANUC A03B-0807-C101 / C102 – Complementary Output Modules (AOD08A / AOD16A)
- FANUC A02B-xxxx-Cxxx – CNC Main Control Unit
- FANUC A66L-0001-0284 – I/O Link Cable
- FANUC A20B-2002-0520 – Power Supply Unit
Contact Konmask for bundle pricing on complete I/O unit assemblies.
Compliance & Industry Standards
- Manufactured to FANUC OEM specifications for CNC control system integration.
- Compatible with IEC 61131-2 discrete input signal standards.
- Suitable for CE-marked machine tool installations (as part of a compliant FANUC CNC system).
- RoHS compliance status: subject to original manufacture date – consult datasheet for specific lot.
Quality Assurance & Sourcing
- Functional Test – Every unit undergoes power-on and I/O channel verification prior to shipment.
- Visual Inspection – PCB inspected for burnt components, cracked solder joints, and connector integrity.
- Genuine Parts – Sourced from decommissioned OEM equipment or authorized surplus channels; no counterfeit risk.
- Packaging – Anti-static bag + foam-padded carton to prevent ESD damage in transit.
- Warranty – 90-day replacement warranty against functional defects.
How to Source This Part
- Click Add to Cart or Contact Us for bulk/project pricing.
- Provide your machine model and FANUC CNC series for compatibility confirmation.
- Orders ship within 1–3 business days via DHL / FedEx with full tracking.
- For urgent machine-down situations, contact us directly for expedited dispatch.
📧 support@konmask.com | 📞 +0086 19859288691
Application-Specific FAQ
Q: Is the AID16D compatible with all FANUC CNC series?
A: The A03B-0807-C104 is designed for FANUC I/O units using the A03B-0807 base. Verify your I/O unit part number before ordering. Contact us for cross-reference assistance.
Q: Can this module replace a faulty AID16D without re-parameterization?
A: Yes. As a direct PCB swap, no parameter changes are required in the FANUC PMC. Simply replace the board and cycle power.
Q: What input voltage range does the AID16D accept?
A: The module accepts standard DC input signals as defined by the FANUC I/O unit specification. Consult the FANUC A03B-0807 hardware manual for exact voltage thresholds.
Q: Do you offer exchange/repair service for faulty AID16D boards?
A: Yes. Send your defective unit for evaluation. Repair or exchange pricing available on request.
Q: What is the lead time for out-of-stock units?
A: Typical sourcing lead time is 5–15 business days. Contact us to join the waitlist or discuss alternatives.
